CAUTION! Moving parts, such as the seat, can crush and cut. Keep hands clear of the slid-
ing rail during use!

ADJUSTMENT GUIDE

ADJUSTING THE RESISTANCE
Rotate the Tension Control Knob (No. 45) clockwise to
increase the level of resistance. Rotate the tension control
knob counter-clockwise to decrease the level of resistance.
MOVING THE ROWER
To move the rower, lift the rear support until the
transportation wheels on the front stabilizer touch the
ground. With the wheels on the ground, you can transport
the rower to the desired location with ease.
PEDAL STRAP ADJUSTMENT
The pedal strap is adjustable and can be personalized to fit
the user's foot size.
REPLACE THE BATTERIES
Two AA batteries are included in Computer (No. 48). To
replace the batteries, remove Computer (No. 48) from Main
Frame (No. 49), and disconnect the Trunk Wire 1 (No. 51)
and the wire of Computer (No. 48). Replace both batteries.
Do not mix battery types and do not mix old and new
batteries.
After the replacement, connect Trunk Wire 1 (No. 51) to the
computer wire and put Computer (No. 48) back onto the
Main Frame (No. 49). Dispose or recycle batteries
according to your state and local rules.
