Duke TSC Installation Instructions Manual
Hide thumbs Also See for TSC:

Advertisement

Quick Links

TSC - TSCM Retrofit
KIT
#600531
Control Replacement
Humidity Probe Replacement
CAUTION:
Please read this manual completely before attempting
to install, operate or service this equipment
This manual is Copyright © 2018 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Duke Manufacturing Co.
St. Louis, MO 63102
Phone: 314-231-1130
Toll Free: 1-800-735-3853
www.dukemfg.com
Installation Instructions
2305 N. Broadway
Fax: 314-231-5074
P/N 514158
REV B 4/12/2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TSC and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Duke TSC

  • Page 1 Please read this manual completely before attempting to install, operate or service this equipment This manual is Copyright © 2018 Duke Manufacturing Co. All rights reserved. Reproduction without written permission is prohibited. Duke is a registered trademark of the Duke Manufacturing Co.
  • Page 2: Table Of Contents

    Installation and Operation of: TSC - TSCM Retrofit TABLE OF CONTENTS Safety Instructions ..............................2 Tools Needed and Parts Included ........................4 Removal of Old Control Panel ..........................5 Installation of New Control Panel ........................6 Humidity Probe Replacement ........................... 8 Installing new Sensor ............................
  • Page 3 Installation and Operation of: TSC - TSCM Retrofit In addition to the warnings and cautions in this manual, use the following guidelines for safe operation of the unit. • Read all instructions before using equipment. • For your safety, the equipment is furnished with a properly grounded cord connector. Do not attempt to remove or disconnect the grounded connector.
  • Page 4: Tools Needed And Parts Included

    Installation and Operation of: TSC - TSCM Retrofit TOOLS NEEDED FOR INSTALLATION Phillips Screw Driver Needle Nose Pliers 11/32 Socket and Rachet Corless Drill PARTS INCLUDED IN KIT 155680 512418 ESD Wrist Strap 120179 Control Assembly 512009 Asembly RH 512014...
  • Page 5: Removal Of Old Control Panel

    Installation and Operation of: TSC - TSCM Retrofit GETTING STARTED TURN OFF LINE SUPPLY POWER TO THE TSC OVEN AT MAINS SUPPLY CIRCUIT BREAKER. FOLLOW LOCK OUT / TAG OUT PROCEDURES. An ESD Wrist Strap is required when coming in contact with Touchpad Controller.
  • Page 6: Installation Of New Control Panel

    Installation and Operation of: TSC - TSCM Retrofit REMOVAL OF OLD CONTROL PANEL - continued Step 8 Step 9 Remove two white wires from the left side of the Remove two wires from the beeper in the upper left relay on the back wall of the control cavity. Cut re- corner of the control cavity.
  • Page 7 Installation and Operation of: TSC - TSCM Retrofit INSTALLATION OF NEW PANEL - continued Step 6 Main power harness From the new control board connect the two white Step 4 wires to the relay on the back wall of the control Connect the main power harness to the control cavity.
  • Page 8: Humidity Probe Replacement

    Installation and Operation of: TSC - TSCM Retrofit HUMIDITY PROBE REPLACEMENT Step 4 PREPING UNIT FOR NEW SENSOR Remove the other eighteen (18) screws holding the back panel in place and set panel aside. Step 1 Verify line power to the unit is disconnected and arrange for access to the rear of the unit.
  • Page 9: Installing New Sensor

    Installation and Operation of: TSC - TSCM Retrofit HUMIDITY PROBE REPLACEMENT - continued Step 7 Step 6 Remove the old RH sensor assembly from the unit Next align drill template 512018 to the upper by removing the two Keps nuts with a 11/32 socket.
  • Page 10 Installation and Operation of: TSC - TSCM Retrofit HUMIDITY PROBE REPLACEMENT - continued Step 3 Route the three pin connector end of the new RH Assembly through the lower wiring feed and through the rear wall of the controls section to the Step 2 front of the TSC Oven control cavity.
  • Page 11: Closing Up Unit

    Installation and Operation of: TSC - TSCM Retrofit CLOSING UP UNIT Step 1 Step 4 Install right side panel with screws. Replace false Replace back electrical panel shield with three (3) bottom tray and shelving. screws INSTALL INSTALL Step 5 In front control panel bundle any old unused wires and secure inside control cavity.
  • Page 12: Operating Instructions

    Installation and Operation of: TSC - TSCM Retrofit OPERATING INSTRUCTIONS Touch Screen Definitions * Screen Sleep Button only Main Tool Bar available when Screen Sleep Button* Info Button Oven and Proofer are off Oven Recipe Information Bar Recipe Recipe Temp...
  • Page 13 Installation and Operation of: TSC - TSCM Retrofit OPERATING INSTRUCTIONS - continued DAILY OVEN/PROOFER START-UP PROOFER OPERATING INSTRUCTIONS 1. Turn power on to the unit with the power switch on the left side of the unit. Boot Screen is displayed 1.
  • Page 14 Installation and Operation of: TSC - TSCM Retrofit OPERATING INSTRUCTIONS - continued 3. Once a Proofer recipe has been selected (i.e. 7. Load the first proofer section with dough and ) and the display has changed to touch UPPER, MIDDLE or LOWER Start Timer...
  • Page 15 Installation and Operation of: TSC - TSCM Retrofit OPERATING INSTRUCTIONS - continued 9. You can add 5 minutes to proofing time by 1. Allow the oven to preheat 20–30 minutes and touching the button adjacent to any of the keep the oven door closed, except during respective count down timers.
  • Page 16 Installation and Operation of: TSC - TSCM Retrofit OPERATING INSTRUCTIONS - continued 1. When the bake is complete, an alarm will beep BAKING TIPS to alert the operator. Touch the Timer • Always select the oven recipe and allow preheat open the oven door to cancel the alarm.
  • Page 17: Care And Cleaning

    Installation and Operation of: TSC - TSCM Retrofit CARE AND CLEANING WARNING PROOFER OVEN INTERIOR AND RACKS ARE VERY HOT AND COOL SLOWLY. ALLOW TO COOL BEFORE HANDLING. CAUTION Figure: Proofer Main Screen ELECTRICAL SHOCK HAZARD: • Follow instructions given on screen after DRY OUT DO NOT WASH WITH WATER JET OR HOSE.
  • Page 18: Programming Controls

    Installation and Operation of: TSC - TSCM Retrofit PROGRAMMING CONTROLS 3. To edit Time, Temperature or Humidity (Proofer To access the SPECIAL FUNCTIONS, touch Only), touch the button adjacent to button on the Main Tool Bar. the field you want to change. Touch the button to save the changes.
  • Page 19 Installation and Operation of: TSC - TSCM Retrofit PROGRAMMING CONTROLS - continued CONFIG (CONFIGURATIONS) 1. Touch the button and then enter pin code 2 3 4 5 and Touch the button when prompted. 2. Touch the button for the setting you want to edit.
  • Page 20 Installation and Operation of: TSC - TSCM Retrofit PROGRAMMING CONTROLS - continued FILES (FILE MANAGEMENT) 3. Select file operation from list and follow instruction on the display screen. 1. Touch the button and then enter pin code 3 4 5 6 and Touch the button when prompted.
  • Page 21: Troubleshooting

    Installation and Operation of: TSC - TSCM Retrofit TROUBLESHOOTING PROBLEM 1. Oven does not heat with oven switch in the ON position and Oven Temperature not set at 0°. a. Are oven indicator lights on? Observe Oven Fan. Go to “b”.
  • Page 22: Wire Diagram

    Installation and Operation of: TSC - TSCM Retrofit WIRE DIAGRAM...
  • Page 23 Installation and Operation of: TSC - TSCM Retrofit NOTES...
  • Page 24 Installation and Operation of: TSC - TSCM Retrofit Duke Manufacturing Co. 2305 N. Broadway St. Louis, MO 63102 Phone: 314-231-1130 Toll Free: 1-800-735-3853 Fax: 314-231-5074 www.dukemfg.com...
