FlexBake 5 Error Code
& Trouble Shooting Guide
This equipment should be serviced by qualified personnel only.
Contact the nearest Duke authorized service facility for adjustment or repair.
WARNING for CA residents: go to www.dukemfg.com/prop65 for prop 65 warning
This manual is Copyright © 2020 Duke Manufacturing Co. All rights reserved.
Reproduction without written permission is prohibited. Duke is a registered
trademark of the Duke Manufacturing Co.
Instruction Sheet
REV A 10/19/2020
P/N 529311
