Convert voice into an electrical signal.
7. Charging LED
It illuminates red while the tablet is charging. Once charging is finished, it will illuminate solid green.
8. Ambient Light Sensor
Sense the amount of the ambient light present.
9. Front Camera
Snapshot the view ahead the screen.
10. Touch Screen
Indicate the test results.
11. Camera Flash
Produce a flash of artificial light.
12. Rear Camera
Snapshot the view in front of the tablet.
13. Audio Speaker
Convert an electrical audio signal into a corresponding sound.
14. Charging Slot
Align it with the charging slot on the docking station to charge the tablet. Refer to Chapter 1.3.3.
15. Adjustable Kickstand
Flip out it to any angle and work comfortable at your desk, or hang it on automotive part.

1.3.2 VCI

The SmartLink C V2.0 device features powerful functions and it can be applied in the following situations:
1). When as a VCI (Vehicle Communication Interface), it needs to work in conjunction with the Diagnose module of the
tablet, which is used to obtain vehicle data, and then send it to the tablet for analysis wirelessly or via data cable.
2). When as a SmartLink C (Customer) dongle, it does not communicate with the tablet, but it needs to work together
with the SmartLink module of the tablet. The tablet is mainly used to issue remote diagnostic requests, and the
SmartLink C dongle is networked to receive and execute commands from the remote SmartLink B (Business).
Note: For detailed operations, please refer to Chapter 5.3.1.
3). When as a local J2534 PassThru device, it can be used in conjunction with the PC installed with OEM diagnostic
software.
Note: For detailed operations, please refer to Chapter 10.
