LAUNCH
3
Volume +/-
4
Speakers
5
Front Camera
USB/Charging
6
Port
7
Reset hole
8
Rear Camera
9
Adjustable stand
1.3.2 VCI Connector (Only for Passenger Vehicle Configuration)
The VCI works as a vehicle communication interface device, which is used to
connect to the vehicle's DLC (Data Link Connector) socket directly or via OBD II
extension cable to read the vehicle data and then send it to the tablet via
Bluetooth.
It is pre-installed in the docking slot on the back of the display tablet. Use the
hand to press the VCI once, it will automatically ejected from the docking slot.
When it is not in use, please insert it into the slot to avoid loss.
Press it once to activate the LCD if the LCD is
off.
Press it once to turn off the LCD if the LCD
lights up.
Press and hold it for 3 seconds to turn it off.
Press and hold it for 8 seconds to perform
forced shutdown.
Adjusts the system volume.
To connect to AC outlet for charging.
To connect to PC for data exchange.
Flip it out to any angle and work comfortable at
your desk, or hang it on steering wheel.
5
X-431 PRO3 V4.0 User Manual
