Service Manual

CASTON

CASTON SERVICE MANUAL

(CASTON II & CASTON III & CASTON III PLUS)

5/13/201420

Table of Contents

Need help?

Do you have a question about the CASTON II and is the answer not in the manual?

Questions and answers

Summary of Contents for CAS CASTON II

Page 1 Service Manual CASTON CASTON SERVICE MANUAL (CASTON II & CASTON III & CASTON III PLUS) 5/13/201420...
Page 2: Table Of Contents
Service Manual CASTON < Table of Contents > Classification ............................4 1.1. Preface ........................... 4 1.2. Precaution ..........................4 1.3. Specification .......................... 6 1.4. Sealing Method ........................9 Classification .............................13 2.1. Overall View.........................13 2.2. Display & Key Functions .....................14 2.3. Options ..........................15 2.3.1.
Page 3 Service Manual CASTON 5.1.2. SPAN Calibration Setting (C-3) ..................31 5.1.3. Gravity Constant Value Setting (C-9) ................31 5.1.4. Calibration factor Setting (C-10) ................32 5.1.5. Displaying Real A/D Value (C-5) ................33 5.1.6. Input Function Key Code (C-6) ..................33 5.1.7. Percent Calibration (C-7) ....................33 5.1.8.
Page 4: Classification
Classification 1.1. Preface Thank you for purchasing of our CAS scale. This scale has been designed with CAS reliability, under rigid quality control and with outstanding performance. WE hope that your departments enjoy with high quality of CAS product. This manual will help you with proper operations and care of the CASTON series.
Page 5 Service Manual CASTON 5/13/201420...
Page 6: Specification
Service Manual CASTON 1.3. Specification -CASTON II CASTON II Capacity / 500 / 0.2 1000 / 0.5 2000 / 1 3000 / 2 5000 / 2 Division(kg) Internal 1 / 60,000 Resolution MAX External 1 / 3,000 Resolution Display Four LEDs with 5 digit(1.2 inch)
Page 7 Service Manual CASTON -CASTON III CASTON III Capacity / 1000 2000 3000 5000 10000 15000 20000 30000 Division(kg) /0.2 /0.5 Internal 1 / 60,000 Resolution MAX External 1 / 3,000 Resolution Display Four LEDs with 5 digit(1.5 inch) POWER 12V/7AH(PB BATTERY) Keys ON/OFF, *(STAR), ZERO, TARE, HOLD Weighing...
Page 8 Service Manual CASTON -CASTON III PLUS CASTON III PLUS Capacity / 2000 3000 5000 10000 15000 20000 Division(kg) Internal 1 / 60,000 Resolution MAX External 1 / 3,000 Resolution Display Four LEDs with 5 digit(1.5 inch) POWER 12V/7AH(PB BATTERY) Keys ON/OFF, *(STAR), ZERO, TARE, HOLD Weighing AUTO POWER OFF...
Page 9: Sealing Method
Service Manual CASTON 1.4. Sealing Method -CASTON II 5/13/201420...
Page 10 Service Manual CASTON -CASTON III 5/13/201420...
Page 11 Service Manual CASTON -CASTON III PLUS 5/13/201420...
Page 12 Service Manual CASTON 5/13/201420...
Page 13: Classification
Service Manual CASTON Classification 2.1. Overall View -CASTON II -CASTON III 5/13/201420...
Page 14: Display & Key Functions
Service Manual CASTON -CASTON III PLUS EYE BOLT DISPLAY LOW BATTERY KEYBOARD LAMP LOAD HOUSING HOOK 2.2. Display & Key Functions ■ DISPLAY WEIGHT DISPLAY: Displays weight or messages (5 Digit). ZERO LAMP: Indicates that scale is stable and at zero. NET LAMP: Indicates that scale is currently using a tare.
Page 15: Options
Service Manual CASTON 2.3. Options Please refer to handy terminal TW-100 B manual of CASTON-III B (Crane Scale : Bluetooth Type) 1. TW-100 Specification Frequency 2400~2483.5 MHz Channel interval 1 MHz Channel 78 channel Communication GFSK(Gaussian Frequency Shift Keying) Type Communication 9600 Speed...
Page 16: Remote Control
Service Manual CASTON 2.3.1. Remote Control ■ ON/OFF: Button to operate power on/off. ■ ZERO: Button to correct zero value. ■ TARE: Used to tare value memorizing. ■ HOLD: Used to weigh moving thing. ■ CLEAR : Used to clear summing weight. ■...
Page 17 Service Manual CASTON 2.3.2. TW-100 (Option) Please refer to handy terminal TW-100 B manual of CASTON-III B (Crane Scale : Bluetooth Type) (1). TW-100 Specification Frequency 2400~2483.5 MHz Channel interval 1 Mhz Channel 78 channel Communication GFSK(Gaussina Frequency Shift Keying) Type Communication 9600...
Page 18: Twn (Option)
Service Manual CASTON 2.3.3. TWN (Option) Please refer to handy terminal TWN manual of CASTON Series 1. TWN Specification Frequency 2.4GHz Communication ZIGBEE (BLUETOOTH) methods Baud Rate 9600 Effective distance Maximum about 50 ~ 100M for communications Display 320*240 TFT LCD Display below zero “-”...
Page 19: Battery Usage
Service Manual CASTON 2.4. Battery Usage - CASTON II ■ Couple connector in main body with connector in battery portion. ■ Insert battery portion to the main body and turn fixing bolt to the right to fix. ■ If the battery is neglected for a long time or not use without charging, it may effect on battery life.
Page 20 Service Manual CASTON -CASTON III ■ Open the battery lid located in back of the scale and turn main switch off. ■ Separate the battery connector and take out the discharged battery. ■ Put a charged battery in rear and connect the battery connector. Turn main power switch on and cover the battery lid.
Page 21: Use Of Battery Charger
■ Turn ON the switch on the battery charger, charging will start with Yellow lamp (CHARGE) turn on. ■ When the charging is completed, GREEN lamp (FULL) turns on. ■ Estimated time for charging is 6 hours (CASTON II). Estimated time for charging is 10 hours (CASTON III).
Page 22: Getting Started
Service Manual CASTON Getting Started - USER’S MENU MODE & USER’S SETTING METHOD. FUNCTION & DESCRIPTIONS ■ Press the ON key located in real panel of the scale. (While the power is off, the ON/OFF key on the remote control wouldn't operate.) ■...
Page 23: Ap Mode
Service Manual CASTON ■ Auto Hold (HL -> 0) - Press the HOLD key before weighing an unstable item - “AHold” will display and then, HOLD lamp is on. - The averaged value of the weight fluctuation will be displayed after few seconds. ■...
Page 24: Ba Mode
Service Manual CASTON ■ Setting Menu. DISPLAY FUNCTION Sb-00 Sleep mode is deactivated. Sb-20 Sleep mode is activated after 20 seconds. Sb-40 Sleep mode is activated after 40 seconds. Sb-60 Sleep mode is activated after 1 minute. 3.3. BA MODE Press ON key while ZERO key is pressed and Press ZERO Again, then you can enter into ‘bA’...
Page 25: Id Mode
Service Manual CASTON CO-St Use RS-232 stream. 3.5. ID MODE Press ON key while ZERO key is pressed and Press ZERO Again, then you can enter into ‘ID’ mode. (‘ID’ means ‘Device ID’.) ■ Key Usage STAR KEY Used to change the input value Used to save the input value and Return to Normal Mode HOLD KEY ■...
Page 26: Panid Mode
Service Manual CASTON Used to increase the input value STAR KEY HOLD KEY Used to save the input value ■ Setting Menu DISPLAY FUNCTION (from11 to 26) CH-11 Set ZIGBEE Channel 11 CH-26 Set ZIGBEE Channel 26 Notice : When using multiple ZIGBEE communication, Set up ‘CHANNEL’ & ‘PANID’ different for using. 3.9.
Page 27: Caston Iii Command Mode Protocol
Service Manual CASTON HL-03 Average Hold use Notice : While using the HOLD function, the weight displayed may be not exact. CASTON III Command Mode Protocol CAS Protocol (22 bytes) – ASCII Code ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ...
Page 28 Service Manual CASTON Command Mode Protocol Command (ASCII code) Description State Key Tare Value Read / Write Current Weight Read Operating like the ZERO key Read Operating like the TARE key Read Operating like the ENTER key Read Operating like the PRINT key Read Read Device ID...
Page 29: Calibration
Service Manual CASTON Calibration 5.1. General Calibration Pressing and holding calibration switch press [POWER] key to go to calibration mode. User can move to other mode by using [ZERO] key in the calibration mode. User also moves to other sub-modes for each mode by using [TARE] key. Please simply follow below procedure to move to other mode.
Page 30 Service Manual CASTON CAL 8 Battery calibration CAL 9 Gravity constant Set calibration factor “Unit”  [ZERO]  select 0, 1 (0:lb, 1: kg)  [HOLD] “CAPA”  [ZERO]  select capacity  [HOLD] “MCAPA”  [ZERO]  select mid-capacity  [HOLD] CAL 10 “W-dP”...
Page 31: C4 Setting
Service Manual CASTON < Modes > 5.1.1. C4 Setting 5.1.1.1. C4-1 Setting BIT 6~7 Initial Zero range BIT5 BIT4 (+), (-) Direction successive Tare (-) Direction successive Tare Successive tare BIT 2~3 (+) Direction successive Tare One Time tare BIT1 BIT0 5.1.1.2.
Page 32: Calibration Factor Setting (C-10)
Service Manual CASTON (1) Pressing and holding “Calibration Switch” press [POWER] key. (2) After “CAL” message blinks three times and shows the version of scale, it displays “CAL-1” message. (3) Press [ZERO] / [TARE] to display “C-9”. (4) Press [HOLD] key, and then “G-1“message and “9.7994” will be shown. The first digit,”9”...
Page 33: Displaying Real A/D Value (C-5)
Service Manual CASTON 5.1.5. Displaying Real A/D Value (C-5) Display Raw AD 5.1.6. Input Function Key Code (C-6) NOT USE 5.1.7. Percent Calibration (C-7) * Please Check the C-10 “MID” Value and Set 0. (1) Pressing and holding “Calibration Switch” press [POWER] key. After “CAL”...
Page 34: The Schematics And Diagram
Service Manual CASTON The Schematics and Diagram 6.1. System Block Diagram (1)CASTON II 5/13/201420...
Page 35 Service Manual CASTON (1)CASTON III 5/13/201420...
Page 36: Circuit Diagram
Service Manual CASTON 6.2. Circuit Diagram A. CASTON II (MAIN & POWER) 5/13/201420...
Page 37 Service Manual CASTON B. CASTON II (KEY & DISPLAY) 5/13/201420...
Page 38 Service Manual CASTON C. CASTON II (Remote control & CASTON II (KEY & DISPLAY) OPTION) 5/13/201420...
Page 39 Service Manual CASTON A. CASTON III (MAIN & POWER) 5/13/201420...
Page 40 Service Manual CASTON B. CASTON III (KEY & DISPLAY) 5/13/201420...
Page 41 Service Manual CASTON C. CASTON III (Remote control & OPTION) 5/13/201420...
Page 42: Exploded View
Service Manual CASTON Exploded View - CASTON II 5/13/201420...
Page 43 Service Manual CASTON - CASTON III (0.5 ~ 5ton) 5/13/201420...
Page 44 Service Manual CASTON - CASTON III (10 ~ 20ton) 5/13/201420...
Page 45 Service Manual CASTON - CASTON III PLUS (FRONT CASE) 5/13/201420...
Page 46 Service Manual CASTON - CASTON III PLUS (REAR CASE) 5/13/201420...
Page 47 Service Manual CASTON - CASTON III PLUS (MAIN PCB ASS’Y) 5/13/201420...
Page 48 Service Manual CASTON - CASTON III PLUS (BATTERY ASS’Y) 5/13/201420...
Page 49 Service Manual CASTON - CASTON III PLUS (2ton) 5/13/201420...
Page 50 Service Manual CASTON - CASTON III PLUS (3ton) 5/13/201420...
Page 51 Service Manual CASTON - CASTON III PLUS (10~20ton) 5/13/201420...
Page 52 Service Manual CASTON - CASTON III PLUS (10ton) 5/13/201420...
Page 53 Service Manual CASTON - CASTON III PLUS (15ton) 5/13/201420...
Page 54 Service Manual CASTON - CASTON III PLUS (20ton) 5/13/201420...
Page 55: Part Location
Service Manual CASTON Part Location -CASTON III MAIN TOP 5/13/201420...
Page 56 Service Manual CASTON -CASTON III MAIN BOTTOM 5/13/201420...
Page 57 Service Manual CASTON -CASTON II MAIN TOP -CASTON II MAIN BOTTOM 5/13/201420...
Page 58 Service Manual CASTON -CASTON II DISPLAY MAIN -CASTON II DISPLAY BOTTOM 5/13/201420...
Page 60: Error Messages & Solution
Solution on Display Remove unstable facts. "Err 0" The "Err 0" occurs when scale is not stable. Please call your CAS The "Err 1" occurs when a current zero point has "Err 1" dealer. shifted from the last span calibration.
Page 61: Part List (Common Part)
Service Manual CASTON Part List (Common Part) CASTON II Part List Display PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6110PC20911C PCB-DISPLAY 6110-PC2-0911-B(C-2)_OneM 6236IS00573A IC(C MOS) 74HC573D (LP-II) 6236IS020030 IC(DRIVER) ULN2003AD 6236IS062780 IC(DRIVER) TD62783AF 6527ID010000 RESISTOR-CHIP 1/10W RR1220P-101D(100Ω) 6527ID010000 RESISTOR-CHIP 1/10W RR1220P-101D(100Ω)
Page 62 Service Manual CASTON 6527ID300220 RESISTOR-CHIP 1/10W RR1220P-222D(2.2K) 6527ID300470 RESISTOR-CHIP 1/10W RR1220P-472D(4.7 ㏀) 6527ID303000 RESISTOR-CHIP 1/10W RR1220P-303D(30 ㏀) 6527ID303900 RESISTOR-CHIP 1/10W RR1220P-393D(39K) 6527ID310000 RESISTOR-CHIP 1/10W RR1220P-104D(100K) 6527ID600100 RESISTOR-CHIP 1/10W RR1220P-105D(1M) 6550M0901030 RESISTOR-NETWORK M9-1-103J(LP-7) 6670T0200100 INDUCTANCE 10uH 6670T0200470 INDUCTANCE 47uH 6704C2501000 CONDENSER-ELECTRIC 100uF/25V 6704C2502200 CONDENSER-ELECTRIC...
Page 63 Service Manual CASTON 6515CJ301000 RESISTOR 1/4W CFR 10K (±5%) 6704C1600470 CONDENSER-ELECTRIC 47uF/16V 6710CAPP1010 CONDENSER-CERAMIC 100PF/50V 6802F0004550 CERAMIC FILTER CSB 455 E 7232D0003000 LED LAMP CLL30231(BVL-300E5G) 7235D0089250 IR-LED OSI-8925(C-2,3) 7240DRM35420 REMOCON MODULE 354HF2 HOUSING ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 1035A0000370 HOOK-ALLOY LATCH...
Page 64 Service Manual CASTON CASTON III Part List KEY PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 2090H0000110 LED HOLDER STD-110BLK(1mm) 6130PC309070 PCB-KEY ONE-MODULE 6704C2502200 CONDENSER-ELECTRIC 10uF/50V 7232DR00005A LED LAMP ø5-RED 7240DRM35420 REMOCON MODULE 354HF2 7600STA12120 TACT S/W 12*12(SKHK)DJTA-1103E 7840W0015100 CONNECTOR WIRE 15P*100m/m(CASTON-3) MAIN PCB ASS'Y...
Page 65 Service Manual CASTON 6527ID310000 RESISTOR-CHIP 1/10W RR1220P-104D(100K) 6527ID600100 RESISTOR-CHIP 1/10W RR1220P-105D(1M) 6550M0901030 RESISTOR-NETWORK M9-1-103J(LP-7) 6670T0200100 INDUCTANCE 10uH 6670T0200470 INDUCTANCE 47uH 6704C2501000 CONDENSER-ELECTRIC 100uF/25V 6704C2502200 CONDENSER-ELECTRIC 10uF/50V 6704C5000100 CONDENSER-ELECTRIC 10uF/50V 6710CAPP102B CONDENSER-CERAMIC 1000PF/1KV(102K) 6712CHP01020 CONDENSER-CHIP CL21B 102KBNC 6712CHP01040 CONDENSER-CHIP CL21F 104KBNC 6PA0A0000000 PCB-ONEMODULE INSERT 61A0-A00-0000-0(ER JR,SW,EB)
Page 66 Service Manual CASTON HOUSING ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 1035A0000370 HOOK-ALLOY LATCH 2T-5TON 1095A0000490 THRUST WASHER #WC30 DUN(0.5~5THD) 1135A0000370 HOOK 0.5~5TON(CASTON-Ⅲ,Ⅳ공용) 1215A0000080 HOUSING UPPER ø100*91(5THD) 1215A000008B HOUSING LOWER ø100*86(CASTON-Ⅲ 공용) 1215A000016A LOAD PIN ø29.5*97(5THD) 1265A000006B HOOK NUT ø56*28(C-3,4 0.5~5TON 공용) 1502A0004300 SCREW-MACHINE(PH)
Page 67 Service Manual CASTON CASTON III PLUS Part List ＭＡＩＮ PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6100-PC6-1000-0 PCB MAIN PCB-MAIN CASTON-III PLUS 6PA0-A00-0001-0 PCB-ONEMODULE INSERT 61A0-A00-0000-0(ER PLUS) 6200-IPU-0676-0 IC(CPU) PIC16F676 6220-ISO-C502-A IC(REGULATOR) XC6204C502PR(SOT89-5) 6220-IS0-C502-0 IC(REGULATOR) XC6204C502MR(5.0V) 6220-I00-7809-0 IC(REGULATOR) MC7809CT 6236-IS0-0573-A IC(C MOS)
Page 68 Service Manual CASTON 6527-ID0-0100-0 RESISTOR-CHIP 1/10W RR1220P-100D(10Ω) 6527-ID0-0470-0 RESISTOR-CHIP 1/10W RR1220P-470D(47Ω) 6527-ID0-1000-0 RESISTOR-CHIP 1/10W RR1220P-101D(100Ω) 6527-ID0-6800-0 RESISTOR-CHIP 1/10W RR1220P-681D(680Ω) 6527-ID3-0010-0 RESISTOR-CHIP 1/10W RR1220P-102D(1K) 6527-ID3-0047-0 RESISTOR-CHIP 1/10W RR1220P-472D(4.7 ㏀) 6527-ID3-1000-0 RESISTOR-CHIP 1/10W RR1220P-104D(100K) 6527-ID6-0010-0 RESISTOR-CHIP 1/10W RR1220P-105D(1M) 6712-CHP-0104-0 CONDENSER-CHIP CL21F 104KBNC 6706-C25-0220-0 CONDENSER-ELECTRIC CHIP 220uF/25V (ø8)
Page 69 Service Manual CASTON ＤＩＳＰＬＡＹ PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6110-PC6-1000-0 PCB DISPLAY PCB-DISPLAY CASTON-III PLUS 7230-D00-1511-0 SC15-11SRWA(1.5inch,Cathode) 7002-Z00-0110-0 PIEZO BUZZER 23C2912P(SL1I-12FsP) 7600-SDP-0002-1 DIP S/W KSD-02S(SMT)(NT-300) 7600-SLD-0002-0 SLIDE S/W INCA-2(DJMM-12V) 7801-CLW-0002-0 CONNECTOR(WAFER) LW0640-02 (LPH01-02) 7804-CCN-7302-0 CONNECTOR(WAFER) 5273-02 (LPH03-02) 7804-CCN-7315-0 CONNECTOR(WAFER) 5273-15 (LPH03-15)
Page 70 Service Manual CASTON ＯＰＴＩＯＮ PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6180-PC6-1000-A PCB OPTION 6180-PC6-1000-A(CASTON Option) 6232-IS0-3232-0 IC(INTERFACE) SP3232ECY(3.3V) 6220-IS0-C332-0 IC(REGULATOR) XC6204C332MR(3.3V) 6281-I00-2222-0 TRANSISTOR CHIP 2N2222AS 6712-CHP-0104-0 CONDENSER-CHIP CL21F 104KBNC 6706-C16-0100-0 CONDENSER-ELECTRIC CHIP 100uF/16V ø6.3 6527-ID0-1000-0 RESISTOR-CHIP 1/10W RR1220P-101D(100Ω) 6527-ID3-0100-0 RESISTOR-CHIP 1/10W...
Page 71 Service Manual CASTON CAL PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6151-PC6-1000-0 PCB CAL 6151-PC6-0000-0(CASTON CAL) 7600-SLD-0002-0 SLIDE S/W INCA-2(DJMM-12V) 7840-PD6-0500-0 CONNECTOR WIRE 2P*500mm (CASTON-III PLUS) 5/13/2014...
Page 72 Service Manual CASTON KEY PCB ASS'Y Part Code Parts Name DESCRIPTION Unit Q'ty 6130-PC6-1000-0 PCB-KEY 6130-PC6-1000-0(CASTON KEY) 6704-C25-0222-0 CONDENSER-ELECTRIC 220uF/25V 7232-DR0-0005-A LED LAMP ø5-RED 2090-H00-0001-0 LED HOLDER STD-110BLK(3mm) 사각 7240-DRM-3542-0 REMOCON MODULE 354HF2 7600-STA-1212-0 TACT S/W 12*12(SKHK)DJTA-1103E 7840-PD6-0150-0 CONNECTOR WIRE 15P*15P*100mm(CASTON-III PLUS) 7804-CCN-7315-0 CONNECTOR (WAFER)
Page 73 Service Manual CASTON C/T ASS'Y Image Part Code Parts Name DESCRIPTION Unit Q'ty 7524-PC6-1000-0 BATTERY-CHARGER ASS'Y 12V 1A DC Jack (내수) 7560-PAC-0039-0 POWER CORD CL5000,ER (내수) 7840-PC6-0700-0 CONNECTOR WIRE ASS'Y 2P*700*PUSH_SW_LOCK(RED) 5/13/2014...
Page 74 Service Manual CASTON ※ FRONT CASE ASS'Y IMAGE CODE PART NAME SPEC Q'TY 1100-A00-0120-0 FRONT CASE C-III PLUS 276*220*110.5 2006-A00-0007-0 DISPLAY FILTER C-III PLUS 190*70*2T 2000-A00-0165-0 PCB MOLDING CASE C-III PLUS 133*82.5*22.6(MAIN PCB) 2600-A00-0107-0 CASTON RING C-III PLUS 269.8*213.8*8 2600-A00-0108-0 ANTENNA CAP C-III PLUS Ø22*30.6 1300-A00-0033-0...
Page 75 Service Manual CASTON 1502-A00-0306-0 SCREW-MACHINE(PH) M3*6 1535-MSU-0630-0 BOLT-WRENCH(WA) M6*30-SUS 1530-MSU-0308-0 BOLT-WRENCH M3*0.7*8-SUS 1030-A00-0475-0 SUNLIGHT CAP C-III PLUS 233.5*100*97(2T) 1502-MSU-0408-0 SCREW-MACHINE(PH) M4*8-SUS 2631-A00-0136-0 PCB CUSION C-III Ø14*Ø3.5*3t 1575-A00-1215-A GORE MEMBRANE VENTS M12*1.5(POV,BLACK) 1551-MSU-0600-0 WASHER(SPR) Ø6 2600-A00-0115-0 ANTENNA HOLE CAP C-III PLUS Ø22*3.5*1.5t 5/13/2014...
Page 76 Service Manual CASTON ※ REAR CASE ASS'Y IMAGE CODE PART NAME SPEC Q'TY 1100-A00-0121-0 REAR CASE C-III PLUS 276*220*126.5 2600-A00-0107-0 CASTON RING C-III PLUS 269.8*213.8*8 2600-A00-0110-0 BATTERY RING C-III PLUS 187.6*134.6*3 2000-A00-0349-0 BATT BRACKET C-III PLUS 100*35*8.5 2000-A00-0346-0 BATTERY COVER C-III PLUS 187.5*147*28 1210-A00-0113-0 HANDLE BOLT...
Page 77 Service Manual CASTON 1210-A00-0112-0 HINGE SHAFT C-III PLUS Ø6*122L 1530-MSU-0415-0 BOLT-WRENCH M4*15-SUS 1005-A00-0125-0 BATTERY SPRING -1 C-III PLU 34.5*12*9.5(0.7T) 1512-A00-0306-0 SCREW-TAPPING(PH)-2 M3*6 1510-A00-0266-0 SCREW-TAPPING(PH)-1 M2.6*6 1550-A00-0308-0 WASHER(FLAT) ø3*ø8*0.5 1070-A00-0004-0 MAGNET CL5000-H(SUS) @15*4*@6.5 1501-MSU-0306-0 SCREW-MACHINE(FH) M3*6-SUS 2600-A00-0112-0 POWER S/W CAP C-III PLUS 16.4*9.6*0.7T 5/13/2014...
Page 78 Service Manual CASTON 1563-A00-0308-0 RIVET Ø3.2*8 1030-A00-0472-0 SEAL PLATE C-III PLUS 34*17*1T(아연) 1535-MSU-0630-0 BOLT-WRENCH(WA) M6*30-SUS 1260-A00-0001-0 BOLT-SEALING M4*6(S-2000) 1502-A00-0306-0 SCREW-MACHINE(PH) M3*6 1502-A00-0406-0 SCREW-MACHINE(PH) M4*6 1005-A00-0129-0 HINGE STOPPER-1 C-III PLUS 29*15*10.2*1.5t SUS 1005-A00-0130-0 HINGE STOPPER-2 C-III PLUS 29*32*10.2*1.5t SUS 1551-MSU-0600-0 WASHER(SPR) Ø6 5/13/2014...
Page 79 Service Manual CASTON ※ BATTERY PACK ASS'Y IMAGE CODE PART NAME SPEC Q'TY 2000-A00-0347-0 BATT CASE (LOWER) C-III PLUS 162*108*58 2000-A00-0348-0 BATT CASE (UPPER) C-III PLUS 162*108*51.5 1005-A00-0126-0 BATTERY SPRING -2 C-III PLUS 24*12*24(0.7T) 1005-A00-0232-0 MAGNETIC PLATE C-III PLUS 65*32*2(1T) 2631-A00-0137-0 BATTERY SPRING CUSHION C-III PLUS 14*12*3T(EVA)
Page 80 Service Manual CASTON ※ BODY ASS'Y (2~3ton) IMAGE CODE PART NAME SPEC Q'TY 1115-A00-0053-0 BODY CASE (2~5ton) C-III PLUS 276*224*152 2605-A00-0013-0 LOAD RUBBER ø29*ø40*1T(C-2,3) 1530-MSU-0625-0 BOLT-WRENCH M6*25-SUS 2605-A00-0015-A RUBBER TUBE ø132*32.5(CASTON-Ⅲ) 1215-A00-0029-A RUBBER RING ø132*8(CASTON-Ⅲ) NI 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1530-MSU-0515-0 BOLT-WRENCH M5*15-SUS 7642-A00-0060-0 METAL CLAMP...
Page 81 Service Manual CASTON ※ BODY ASS'Y (5ton) IMAGE CODE PART NAME SPEC Q'TY 1115-A00-0053-0 BODY CASE (2~5ton) C-III PLUS 276*224*152 2605-A00-0013-0 LOAD RUBBER ø29*ø40*1T(C-2,3) 1530-MSU-0625-0 BOLT-WRENCH M6*25-SUS 2605-A00-0015-A RUBBER TUBE ø132*32.5(CASTON-Ⅲ) 1215-A00-0029-A RUBBER RING ø132*8(CASTON-Ⅲ) NI 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1530-MSU-0515-0 BOLT-WRENCH M5*15-SUS 7642-A00-0060-0 METAL CLAMP...
Page 82 Service Manual CASTON ※ BODY ASS'Y (10ton) IMAGE CODE PART NAME SPEC Q'TY 1115-A00-0054-0 BODY CASE (10~20ton) C-III PLUS 276*220*152 1030-A00-0476-0 UPPER PLATE (10ton) C-III PLUS 138*117*44*2T(BLACK) 2605-A00-0017-0 UPPER GASKET ø116*137 C-3(10THD) 2605-A00-0016-B RUBBER TUBE C-3 PLUS 139*164 (10T-15T) 1030-A00-0474-0 LOWER PLATE (10~20ton) C-III PLUS 164*139*3T(BLACK) 1095-A00-0006-0...
Page 83 Service Manual CASTON ※ BODY ASS'Y (15ton) IMAGE CODE PART NAME SPEC Q'TY 1115-A00-0054-0 BODY CASE (10~20ton) C-III PLUS 276*220*152 1030-A00-0477-0 UPPER PLATE (15ton) C-III PLUS 138*117*60*2T(BLACK) 2605-A00-0017-0 UPPER GASKET ø116*137 C-3(10THD) 2605-A00-0016-B RUBBER TUBE C-3 PLUS 139*164 (10T-15T) 1030-A00-0474-0 LOWER PLATE (10~20ton) C-III PLUS 164*139*3T(BLACK) 1095-A00-0006-0...
Page 84 Service Manual CASTON ※ BODY ASS'Y (20ton) IMAGE CODE PART NAME SPEC Q'TY 1115-A00-0054-0 BODY CASE (10~20ton) C-III PLUS 276*220*152 1030-A00-0473-0 UPPER PLATE (20ton) C-III PLUS 138*117*71*2T(BLACK) 2605-A00-0017-0 UPPER GASKET ø116*137 C-3(10THD) 2605-A00-0016-0 RUBBER TUBE ø139*164 C-3(10THD) 1030-A00-0474-0 LOWER PLATE (10~20ton) C-III PLUS 164*139*3T(BLACK) 1095-A00-0006-0 STEEL BAND...
Page 85 Service Manual CASTON ※ HOOK ASS'Y (2~3ton) IMAGE CODE PART NAME SPEC Q'TY 1135-A00-0040-0 EYE BOLT 기존공용5ton(신규로드셀 2~3TON) 1530-MSU-0625-0 BOLT-WRENCH M6*25-SUS 1215-A00-0010-0 HOUSING UPPER ø100*81(2-3THD)(III,IV-2~5T) 1215-A00-0008-B HOUSING LOWER ø100*86(CASTON-Ⅲ 공용) 1215-A00-0014-0 LOAD PIN ø19.8*97(2-3THD) 1560-A00-1900-0 SNAP RING 호칭-19(내경ø17.5) 1265-A00-0006-B HOOK NUT ø56*28(C-3,4 0.5~5TON공용) 1135-A00-0037-0 HOOK...
Page 86 Service Manual CASTON 1035-A00-0037-0 HOOK-ALLOY LATCH 2T-5TON 1095-A00-0049-0 THRUST WASHER #WC30 DUN(0.5~5THD) ※ HOOK ASS'Y (5ton) IMAGE CODE PART NAME SPEC Q'TY 1135-A00-0045-0 EYE BOLT 5TON (CASTON 공용 로드셀적용) 1530-MSU-0625-0 BOLT-WRENCH M6*25-SUS 1215-A00-0008-0 HOUSING UPPER ø100*91(5THD) 1215-A00-0008-B HOUSING LOWER ø100*86(CASTON-Ⅲ 공용) 1215-A00-0016-A LOAD PIN ø29.5*97(5THD)
Page 87 Service Manual CASTON 1135-A00-0037-0 HOOK 0.5~5TON(CASTON-Ⅲ,Ⅳ공용) 1595-A00-0002-0 HOOK SPRING ø1.2(L) 1035-A00-0037-0 HOOK-ALLOY LATCH 2T-5TON 1095-A00-0049-0 THRUST WASHER #WC30 DUN(0.5~5THD) ※ HOOK ASS'Y (10ton) IMAGE CODE PART NAME SPEC Q'TY 1095-A00-0034-0 ALLOY LATCH KITS SS-4055 7 1/2-10TON 1215-A00-0071-A HOUSING UPPER ø106*154(10THD) NI 1215-A00-0062-B HOUSING LOWER ø106*94.5(10THD) NI...
Page 88 Service Manual CASTON 1095-MS0-0046-0 HOOK PAINT 10THD 1215-A00-0068-0 BOLT-LOAD M38*P3.0*136.5(10THD) 1215-A00-0081-0 LOAD NUT M36*P3.0(10THD) 1095-A00-0043-0 THRUST WASHER #WC35 DUN(10THD) 9205-BPE-0002-A POLY ETHYLENE BOX 570*340*300(10THD) 1532-A00-0608-0 BOLT-WRENCH(ST) M6*8 1532-A00-0610-0 BOLT-WRENCH(ST) M6*10 ※ HOOK ASS'Y (15ton) IMAGE CODE PART NAME SPEC Q'TY 1095-A00-0035-0 ALLOY LATCH KITS SS-4055 15TON-22TON...
Page 89 Service Manual CASTON 1215-A00-0063-B HOUSING LOWER ø119*102(15THD) NI 1095-A00-0048-0 SPLIT PIN ø4.5*70(15~20THD) 1215-A00-0066-A HOOK NUT ø68*39(15THD) 1095-MS0-0029-0 HOOK PAINT 15THD 1215-A00-0069-0 BOLT-LOAD M42*P3.0*152(15THD) 1215-A00-0082-0 LOAD NUT M42*P3.0*34(15THD) 1095-A00-0044-0 THRUST WASHER #WC40 DUN(15THD) 9205-BPE-0001-A POLY ETHYLENE BOX 570*340*300(15THD) 1532-A00-0608-0 BOLT-WRENCH(ST) M6*8 1532-A00-0610-0 BOLT-WRENCH(ST) M6*10...
Page 90 Service Manual CASTON ※ HOOK ASS'Y (20ton) IMAGE CODE PART NAME SPEC Q'TY 1095-A00-0035-0 ALLOY LATCH KITS SS-4055 15TON-22TON 1215-A00-0073-A HOUSING UPPER ø149*180(20THD) NI 1215-A00-0064-B HOUSING LOWER ø158*129(20THD) NI 1095-A00-0048-0 SPLIT PIN ø4.5*70(15~20THD) 1215-A00-0067-A HOOK NUT ø77*44.5(20THD) NI 1135-A00-0006-0 HOOK PAINT 20THD 1215-A00-0070-0 BOLT-LOAD...
Page 91 Service Manual CASTON 9106-CT3-0130-0 C/T BOX 640*345*390(20THD) 9206-BPE-0004-A POLY ETHYLENE BOX 630*380*340 (20THD) 1532-A00-0608-0 BOLT-WRENCH(ST) M6*8 1532-A00-0610-0 BOLT-WRENCH(ST) M6*10 ※ HOOK ASS'Y (10ton) IMAGE CODE PART NAME SPEC Q'TY 1135-A00-0007-A SHAKLE SHBB-007 (1-1/4, 12T) ※ HOOK ASS'Y (15ton) IMAGE CODE PART NAME SPEC Q'TY...
Page 92 Service Manual CASTON ※ IMAGE ASSY IMAGE CODE PART NAME SPEC Q'TY 2200-A00-0006-0 KEY BOARD PAD (TOOL) C-III PLUS 203.5*44.6*1.5 1800-A00-0005-0 NAME PLATE (TOOL) C-III PLUS 150.8*16.3*0.5 1815-A00-0017-0 CAPA PLATE (TOOL) C-III PLUS 204*20*0.3 8902-A00-0002-0 PREPARATION PLATE (TOOL) C-III PLUS 133.6*78.6*1.5 1810-A00-0007-0 SPEC PLATE (TOOL) C-III PLUS 86*26*0.5T...
Page 93 Service Manual CASTON ※ C/T BOX ASSY IMAGE CODE PART NAME SPEC Q'TY 1090-A00-0001-0 L-WRENCH ø5(PD-1용) 9005-CT2-0000-7 MANUAL C-III PLUS USER(국문)-ONEMODULE 9100-CT3-0140-0 C/T BOX C-III PLUS 620*500*415(공용) 9206-APE-0009-0 POLY ETHYLENE BOX C-III PLUS 610*490*400(하판) 9206-APE-0010-0 POLY ETHYLENE BOX C-III PLUS 610*490*400(상판) 9301-A00-0003-0 POLY BAG 170*250*0.05T(MANUAL) 9307-A00-0003-B POLY BAG...
Page 94: Part List (Etc Part)
Service Manual CASTON Part List (ETC Part) PARTS NAME : REMOCON CASE ASS'Y (Common) 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA) 7620-S00-5000-0 FUSE 5A/250(ø5*20m/m) 9005-CT3-BT00-0 MANUAL CASTON-III(B) 내수 9100-CT3-0130-0 C/T BOX 620*500*415(DW-4종)(C-3) 9206-APE-0001-0 POLY ETHYLENE BOX 610*490*400(CASTON-3) 9300-A00-0002-0 POLY BAG 90*150*0.05T(FUSE)
Page 95 Service Manual CASTON 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1095-A00-0049-0 THRUST WASHER #WC30DUN(0.5~5THD) 1115-A00-0009-B BODY 280*220*150(C-Ⅲ) 1115-A00-0012-B FRONT COVER 280*220*105(C-III)TACT 1115-A00-0014-B REAR COVER 280*212*31(C-Ⅲ) 1115-A00-0016-B BATTERY COVER 214*187*53.8(C-Ⅲ) 1135-A00-0037-0 HOOK 0.5~5TON(CASTON-Ⅲ,Ⅳ공용) 1135-A00-0038-0 LIFT EYE BOLT 0.5~1TON(CASTON-Ⅱ,Ⅲ, 1215-A00-0008-B HOUSING LOWER ø100*86(CASTON-Ⅲ 공용) 1215-A00-0012-0 HOUSING UPPER ø100*120(0.5-1THD) 1215-A00-0029-0 RUBBER RING ø132*8(CASTON-Ⅲ)
Page 96 Service Manual CASTON 1532-A00-0608-0 WRENCH BOLT(ST) M6*8 1533-MIS-0620-0 WRENCH BOLT(FH) M6*20-BLACK착색 1540-A00-0400-0 NUT(HEX) M4*0.7 1551-MSU-0400-0 WASHER(SPR) φ4*φ6.9*1-SUS 1551-MSU-0600-0 WASHER(SPR) φ6-SUS 1560-A00-1900-0 SNAP RING 호칭-19(내경 φ17.5) 1595-A00-0002-0 HOOK SPRING φ1.2(L) 1595-A00-0008-0 HELI COIL 6*1.09*1.5D 1805-CT3-0033-0 NAME PLATE CASTON-Ⅲ(영공) 1815-CT3-0033-1 SPEC PLATE CASTON-3(영공) 1815-CT3-0033-2 CAPACITY PLATE CASTON-Ⅲ(영공)
Page 97 7870-WGN-0220-0 LEAD WIRE 0.18*20C*110M/M(GRN) 8700-LA0-0050-0 SILICONE SEALANTE KE-45 0.05 8800-LA0-0030-0 SHRINKABLE TUBE ø3 0.08 9020-A00-0033-0 SITCKER PASSED CAS 영공(확인) 9020-A00-0033-1 STICKER SAFETY STICKER 영공 9020-CTN-0033-0 WARNING STICKER CASTON-SERIES (영공) 9025-A00-0034-0 STICKER THA,THD (ON/OFF) 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01...
Page 98 Service Manual CASTON PARTS NAME : C/T BOX ASS'Y 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA) 7620-S00-5000-0 FUSE 5A/250(ø5*20m/m) 9005-CT3-BT00-0 MANUAL CASTON-III(B) 내수 9100-CT3-0130-0 C/T BOX 620*500*415(DW-4종)(C-3) 9206-APE-0001-0 POLY ETHYLENE BOX 610*490*400(CASTON-3) 9300-A00-0002-0 POLY BAG 90*150*0.05T(FUSE) 9301-A00-0003-0 POLY BAG 170*250*0.05T(MANUAL) 9307-A00-0003-B POLY BAG...
Page 99 Service Manual CASTON - CASTON III(1 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0037-0 SAFETY LATCH 2T-5TON 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1095-A00-0049-0 THRUST WASHER #WC30DUN(0.5~5THD) 1115-A00-0009-B BODY 280*220*150(C-Ⅲ)
Page 100 Service Manual CASTON 1502-MSU-0408-0 MACHINE SCREW(PH) M4*8-SUS 1503-A00-0410-0 MACHINE SCREW(WPH) M4*10 1505-MPN-0306-0 MACHINE SCREW(TH) M3*6-NI 1506-MSU-0410-0 MACHINE SCREW(OVH) M4*0.7*10-SUS 1507-A00-0305-0 CONNECTOR BOLT M3*5 (C-III) 1530-MSU-0620-0 WRENCH BOLT M6*20-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1531-A00-0515-0 WRENCH BOLT(MHO) M5*15 1531-A00-0630-0 WRENCH BOLT(MHO) M6*30 1532-A00-0608-0 WRENCH BOLT(ST) M6*8 1533-MIS-0620-0 WRENCH BOLT(FH)
Page 101 2P*370m/m (C-3,) 7840-W00-0248-0 CONNECTOR WIRE 2P*480m/m(CASTON-3) 7840-W00-3219-A CONNECTOR WIRE XLR-4-32C*195mm(C-3) 7870-WGN-0220-0 LEAD WIRE 0.18*20C*110M/M(GRN) 8700-LA0-0050-0 SILICONE SEALANTE KE-45 0.05 8800-LA0-0030-0 SHRINKABLE TUBE ø3 0.08 9020-A00-0033-0 SITCKER PASSED CAS 영공(확인) 9020-A00-0033-1 STICKER SAFETY STICKER 영공 9020-CTN-0033-0 WARNING STICKER CASTON-SERIES (영공) 5/13/2014...
Page 102 Service Manual CASTON 9025-A00-0034-0 STICKER THA,THD (ON/OFF) 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.003 7840-W00-1217-0 CONNECTOR WIRE 12P*150m/m(BT) 1CN2 7840-W00-1107-0 CABLE ASS'Y 400mm/ESD PARTS NAME : C/T BOX ASS'Y 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY...
Page 103 Service Manual CASTON - CASTON III(2 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0037-0 SAFETY LATCH 2T-5TON 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1095-A00-0049-0 THRUST WASHER #WC30DUN(0.5~5THD) 1115-A00-0009-B BODY 280*220*150(C-Ⅲ)
Page 104 Service Manual CASTON 1502-MSU-0408-0 MACHINE SCREW(PH) M4*8-SUS 1503-A00-0410-0 MACHINE SCREW(WPH) M4*10 1505-MPN-0306-0 MACHINE SCREW(TH) M3*6-NI 1506-MSU-0410-0 MACHINE SCREW(OVH) M4*0.7*10-SUS 1507-A00-0305-0 CONNECTOR BOLT M3*5 (C-III) 1530-MSU-0620-0 WRENCH BOLT M6*20-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1531-A00-0515-0 WRENCH BOLT(MHO) M5*15 1531-A00-0630-0 WRENCH BOLT(MHO) M6*30 1532-A00-0608-0 WRENCH BOLT(ST) M6*8 1533-MIS-0620-0 WRENCH BOLT(FH)
Page 105 Service Manual CASTON 2605-A00-0052-0 RUBBER STOPPER ￠15*￠12*10T(NBR)(CASTON-Ⅲ)EA 2605-A00-0067-0 FRONT GASKET 274*214*2.0t (C-III) 2605-A00-0068-0 REAR GASKET 274*214*2.0t (C-III) 2605-A00-0069-0 BATTERY GASKET 210*149*2.0t (C-III) 2631-A00-0001-0 VFD CUSHION 30*20*2T 2632-A00-0011-0 DISPLAY COVER TAPE 185*65(CASTON-3) 7520-P00-0010-0 NI-CD BATTERY ES7-12V/7A(SP-1 BF) 7600-SJA-0500-0 JACK S/W HS-500->SM2020(CASTON-3) 7600-SPB-0103-0 PUSH BUTTON S/W MSP103C(CASTON-3,CI) 7620-S00-5000-0 FUSE...
Page 106 Service Manual CASTON 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.00336 7840-W00-1217-0 CONNECTOR WIRE 12P*150m/m(BT) 1CN2 7840-W00-1107-0 CABLE ASS'Y 400mm/ESD PARTS NAME : C/T BOX ASS'Y 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA)
Page 107 Service Manual CASTON - CASTON III(3 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0037-0 SAFETY LATCH 2T-5TON 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1095-A00-0049-0 THRUST WASHER #WC30DUN(0.5~5THD) 1115-A00-0009-B BODY 280*220*150(C-Ⅲ)
Page 108 Service Manual CASTON 1502-MSU-0408-0 MACHINE SCREW(PH) M4*8-SUS 1503-A00-0410-0 MACHINE SCREW(WPH) M4*10 1505-MPN-0306-0 MACHINE SCREW(TH) M3*6-NI 1506-MSU-0410-0 MACHINE SCREW(OVH) M4*0.7*10-SUS 1507-A00-0305-0 CONNECTOR BOLT M3*5 (C-III) 1530-MSU-0620-0 WRENCH BOLT M6*20-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1531-A00-0515-0 WRENCH BOLT(MHO) M5*15 1531-A00-0630-0 WRENCH BOLT(MHO) M6*30 1532-A00-0608-0 WRENCH BOLT(ST) M6*8 1533-MIS-0620-0 WRENCH BOLT(FH)
Page 109 Service Manual CASTON 2605-A00-0052-0 RUBBER STOPPER ￠15*￠12*10T(NBR)(CASTON-Ⅲ)EA 2605-A00-0067-0 FRONT GASKET 274*214*2.0t (C-III) 2605-A00-0068-0 REAR GASKET 274*214*2.0t (C-III) 2605-A00-0069-0 BATTERY GASKET 210*149*2.0t (C-III) 2631-A00-0001-0 VFD CUSHION 30*20*2T 2632-A00-0011-0 DISPLAY COVER TAPE 185*65(CASTON-3) 7520-P00-0010-0 NI-CD BATTERY ES7-12V/7A(SP-1 BF) 7600-SJA-0500-0 JACK S/W HS-500->SM2020(CASTON-3) 7600-SPB-0103-0 PUSH BUTTON S/W MSP103C(CASTON-3,CI) 7620-S00-5000-0 FUSE...
Page 110 Service Manual CASTON 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.00336 7840-W00-1217-0 CONNECTOR WIRE 12P*150m/m(BT) 1CN2 7840-W00-1107-0 CABLE ASS'Y 400mm/ESD PARTS NAME : C/T BOX ASS'Y 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA)
Page 111 Service Manual CASTON - CASTON III(5 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0037-0 SAFETY LATCH 2T-5TON 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1095-A00-0049-0 THRUST WASHER #WC30DUN(0.5~5THD) 1115-A00-0009-B BODY 280*220*150(C-Ⅲ)
Page 112 Service Manual CASTON 1502-MSU-0408-0 MACHINE SCREW(PH) M4*8-SUS 1503-A00-0410-0 MACHINE SCREW(WPH) M4*10 1505-MPN-0306-0 MACHINE SCREW(TH) M3*6-NI 1506-MSU-0410-0 MACHINE SCREW(OVH) M4*0.7*10-SUS 1507-A00-0305-0 CONNECTOR BOLT M3*5 (C-III) 1530-MSU-0620-0 WRENCH BOLT M6*20-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1531-A00-0515-0 WRENCH BOLT(MHO) M5*15 1531-A00-0630-0 WRENCH BOLT(MHO) M6*30 1532-A00-0608-0 WRENCH BOLT(ST) M6*8 1533-MIS-0620-0 WRENCH BOLT(FH)
Page 113 Service Manual CASTON 2605-A00-0052-0 RUBBER STOPPER ￠15*￠12*10T(NBR)(CASTON-Ⅲ)EA 2605-A00-0067-0 FRONT GASKET 274*214*2.0t (C-III) 2605-A00-0068-0 REAR GASKET 274*214*2.0t (C-III) 2605-A00-0069-0 BATTERY GASKET 210*149*2.0t (C-III) 2631-A00-0001-0 VFD CUSHION 30*20*2T 2632-A00-0011-0 DISPLAY COVER TAPE 185*65(CASTON-3) 7520-P00-0010-0 NI-CD BATTERY ES7-12V/7A(SP-1 BF) 7600-SJA-0500-0 JACK S/W HS-500->SM2020(CASTON-3) 7600-SPB-0103-0 PUSH BUTTON S/W MSP103C(CASTON-3,CI) 7620-S00-5000-0 FUSE...
Page 114 Service Manual CASTON 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.00336 7840-W00-1217-0 CONNECTOR WIRE 12P*150m/m(BT) 1CN2 7840-W00-1107-0 CABLE ASS'Y 400mm/ESD PARTS NAME : C/T BOX ASS'Y 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA)
Page 115 Service Manual CASTON - CASTON III(10 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0038-0 UPPER PLATE ø138*117*3T(10-20THD) 1035-A00-0039-0 LOWER PLATE 164*139*3T(10-20THD) 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ 1095-A00-0006-0 STEEL BAND ø108.5-706R(CASTON-Ⅳ) 1115-A00-0010-A BODY 280*220*150(C-Ⅲ)(10THD)
Page 116 Service Manual CASTON 1551-MSU-0400-0 WASHER(SPR) φ4*φ6.9*1-SUS 1551-MSU-0600-0 WASHER(SPR) φ6-SUS 1595-A00-0008-0 HELI COIL 6*1.09*1.5D 1805-CT3-0033-0 NAME PLATE CASTON-Ⅲ(영공) 1815-CT3-0033-1 SPEC PLATE CASTON-3(영공) 1815-CT3-1033-0 CAPACITY PLATE CASTON-Ⅲ(영공,1/2000) 2015-A00-0005-0 DISPLAY COVER 184.5*64*2T(C-3 일반사양) 2205-CT3-0033-4 KEY BOARD PAD CASTON-III (Bluetooth) 2600-A00-0027-0 BUMPON SJ-5023(5523) 2605-A00-0016-0 RUBBER TUBE ø139*164 C-3(10THD) 2605-A00-0017-0 UPPER GASKET ø116*137 C-3(10THD)
Page 117 XLR-4-32C*195mm(C-3) 7870-WGN-0220-0 LEAD WIRE 0.18*20C*110M/M(GRN) 8700-LA0-0050-0 SILICONE SEALANTE KE-45 0.05 8800-LA0-0030-0 SHRINKABLE TUBE ø3 0.08 9020-A00-0033-0 SITCKER PASSED CAS 영공(확인) 9020-CTN-0033-0 WARNING STICKER CASTON-SERIES (영공) 9025-A00-0034-0 STICKER THA,THD (ON/OFF) 9025-CT3-0033-1 BATTERY WARNING STICKER CT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02...
Page 118 Service Manual CASTON 9206-APE-0001-0 POLY ETHYLENE BOX 610*490*400(CASTON-3) 9300-A00-0002-0 POLY BAG 90*150*0.05T(FUSE) 9301-A00-0003-0 POLY BAG 170*250*0.05T(MANUAL) 9307-A00-0003-B POLY BAG 700*750*0.04T(SET,HD) 9400-A00-0046-0 SILICAGEL 9505-A00-0025-0 STUB-ANT STUB-100M PARTS NAME : HOOK ASS'Y 1095-A00-0034-0 ALLOY LATCH KITS SS-4055 7 1/2-10TON 1095-A00-0043-0 THRUST WASHER #WC35 DUN(10THD) 1095-A00-0046-0 ALLOY SHANK HOOKS S-319-A(11 TON,C-3 10TON용)
Page 119 Service Manual CASTON PARTS NAME : LOAD CELL LLASSS106G000000 SS-10 저울 - CASTON III(15 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-A BATTERY CASE SET 157.4*113.4*12(C-3)일반 1035-A00-0038-0 UPPER PLATE ø138*117*3T(10-20THD) 1035-A00-0039-0 LOWER PLATE 164*139*3T(10-20THD) 1075-A00-0001-0 MAGNET ø25*5T(C-3) 1095-A00-0001-0 LATCH C-Ⅲ...
Page 120 Service Manual CASTON 1520-MSU-1045-0 HEXAGON BOLT M10*1.0*45-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1530-MSU-0630-0 WRENCH BOLT M6*30-SUS 1551-MSU-0400-0 WASHER(SPR) φ4*φ6.9*1-SUS 1551-MSU-0600-0 WASHER(SPR) φ6-SUS 1595-A00-0008-0 HELI COIL 6*1.09*1.5D 1805-CT3-0033-0 NAME PLATE CASTON-Ⅲ(영공) 1815-CT3-0033-1 SPEC PLATE CASTON-3(영공) 1815-CT3-1533-0 CAPACITY PLATE CASTON-Ⅲ(영공) 2015-A00-0005-0 DISPLAY COVER 184.5*64*2T(C-3 일반사양) 2205-CT3-0033-4 KEY BOARD PAD CASTON-III (Bluetooth)
Page 121 XLR-4-32C*195mm(C-3) 7870-WGN-0220-0 LEAD WIRE 0.18*20C*110M/M(GRN) 8700-LA0-0050-0 SILICONE SEALANTE KE-45 0.05 8800-LA0-0030-0 SHRINKABLE TUBE ø3 0.08 9020-A00-0033-0 SITCKER PASSED CAS 영공(확인) 9020-CTN-0033-0 WARNING STICKER CASTON-SERIES (영공) 9025-A00-0034-0 STICKER THA,THD (ON/OFF) 9025-CT3-0033-1 BATTERY WARNING STICKER CT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02...
Page 122 Service Manual CASTON 7620-S00-5000-0 FUSE 5A/250(ø5*20m/m) 9005-CT3-BT00-0 MANUAL CASTON-III(B) 내수 9100-CT3-0130-0 C/T BOX 620*500*415(DW-4종)(C-3) 9206-APE-0001-0 POLY ETHYLENE BOX 610*490*400(CASTON-3) 9300-A00-0002-0 POLY BAG 90*150*0.05T(FUSE) 9301-A00-0003-0 POLY BAG 170*250*0.05T(MANUAL) 9307-A00-0003-B POLY BAG 700*750*0.04T(SET,HD) 9400-A00-0046-0 SILICAGEL 9505-A00-0025-0 STUB-ANT STUB-100M PARTS NAME : HOOK ASS'Y 1095-A00-0035-0 ALLOY LATCH KITS SS-4055 15TON-22TON 1095-A00-0029-0 ALLOY SHANK HOOKS...
Page 123 Service Manual CASTON 9307-A00-0003-B POLY BAG 700*750*0.04T(SET,HD) 9400-A00-0046-0 SILICAGEL 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.00336 PARTS NAME : LOAD CELL LLASSS156G000000 SS-15 저울 - CASTON III(20 ton) PARTS NAME : BODY ASS'Y 1005-A00-0007-0 HINGE SUS129*91*1T(C-3) 1005-A00-0019-0 LATCH CASTON-3 1035-A00-0005-B BATTERY CASE SET 157.4*113.4*12(C-3)일반...
Page 124 Service Manual CASTON 1505-MPN-0306-0 MACHINE SCREW(TH) M3*6-NI 1506-MSU-0410-0 MACHINE SCREW(OVH) M4*0.7*10-SUS 1507-A00-0305-0 CONNECTOR BOLT M3*5 (C-III) 1520-MSU-1045-0 HEXAGON BOLT M10*1.0*45-SUS 1530-MSU-0625-0 WRENCH BOLT M6*25-SUS 1530-MSU-0630-0 WRENCH BOLT M6*30-SUS 1551-MSU-0400-0 WASHER(SPR) φ4*φ6.9*1-SUS 1551-MSU-0600-0 WASHER(SPR) φ6-SUS 1595-A00-0008-0 HELI COIL 6*1.09*1.5D 1805-CT3-0033-0 NAME PLATE CASTON-Ⅲ(영공) 1815-CT3-0033-1 SPEC PLATE CASTON-3(영공)
Page 125 XLR-4-32C*195mm(C-3) 7870-WGN-0220-0 LEAD WIRE 0.18*20C*110M/M(GRN) 8700-LA0-0050-0 SILICONE SEALANTE KE-45 0.05 8800-LA0-0030-0 SHRINKABLE TUBE ø3 0.08 9020-A00-0033-0 SITCKER PASSED CAS 영공(확인) 9020-CTN-0033-0 WARNING STICKER CASTON-SERIES (영공) 9025-A00-0034-0 STICKER THA,THD (ON/OFF) 9025-CT3-0033-1 BATTERY WARNING STICKERCT-3(영공)12V용 9800-A00-0001-A 순간본드 ALTECO-EE(20g) 0.01 9800-A00-0003-0 BOND #575 180ml 0.02...
Page 126 Service Manual CASTON 1090-A00-0005-0 L-WRENCH ￠6 7520-P00-0030-0 Mn BATTERY R6-1.5V-AAM(REMOCON) 7524-PC3-1280-0 BATTERY CHARGER CK-2112800CR(12V/800mA) 7620-S00-5000-0 FUSE 5A/250(ø5*20m/m) 9005-CT3-BT00-0 MANUAL CASTON-III(B) 내수 9100-CT3-0130-0 C/T BOX 620*500*415(DW-4종)(C-3) 9206-APE-0001-0 POLY ETHYLENE BOX 610*490*400(CASTON-3) 9300-A00-0002-0 POLY BAG 90*150*0.05T(FUSE) 9301-A00-0003-0 POLY BAG 170*250*0.05T(MANUAL) 9307-A00-0003-B POLY BAG 700*750*0.04T(SET,HD) 9400-A00-0046-0 SILICAGEL 9505-A00-0025-0 STUB-ANT...
Page 127 Service Manual CASTON 9020-A00-0033-1 STICKER SAFETY STICKER 영공 9100-CT3-0130-A C/T BOX 345*640*390(20THD) 9206-BPE-0004-0 POLY ETHYLENE BOX 630*380*340 (20THD) 9307-A00-0003-B POLY BAG 700*750*0.04T(SET,HD) 9400-A00-0046-0 SILICAGEL 9800-A00-0019-0 LOCKING PAINT LOC-638(250ml)LP(RED) 0.00336 PARTS NAME : LOAD CELL LLASSS206G000000SS-20 저울 5/13/2014...
Page 128 Service Manual CASTON - CASTON II(0.5 ton) PARTS NAME : BODY ASS'Y 1030CT300001 BATTERY-CHARGER CASE CASTON(BODY CASE) 1030CT300002 BATTERY-CHARGER CASE CASTON(COVER CASE) 1030MS000001 BATTERY-CHARGER PAINT CASTON(BODY,BLACK,인쇄포함) 1030MS000002 BATTERY-CHARGER PAINT CASTON(COVER,IVORY) 1035A000007C BATTERY CASE 204*125.8*80(C-2) 1035A0000360 SAFETY LATCH 0.5-1TON 1060A0000150 P.C.B CONTACT(-)
Page 129 Service Manual CASTON 1532A0006080 BOLT-WRENCH(ST) M6*8 1532MSU08100 BOLT-WRENCH(ST) M8*10-SUS 1533MIS04120 BOLT-WRENCH(FH) M4*12착색 EA 10 1533MIS06150 BOLT-WRENCH(FH) M6*15착색 1554A0006000 WASHER(FIB) ø6 1561MSU05000 E-RING ø5*ø11*0.6-SUS 1564A0002060 RIVET TWIST ø2.6*6 1590A0000320 BATTERY SPRING A ø9*ø0.6*3(MW-Ⅱ) 1595A0000030 HOOK SPRING ø0.8(S) 1595A0000080 HELI COIL 6*1.09*1.5D 1815CT200330 SPEC PLATE CASTON-II(영공)
Page 130 Service Manual CASTON 9025CT205330 STICKER CASTON-II 영공(소진후 불용) PARTS NAME : C/T BOX ASS'Y 9007CT000330 MANUAL CASTON안전메뉴얼(영문) 9007CT200333 MANUAL CASTON-ll공용(영문) 9020A0000331 STICKER SAFETY STICKER 영공 9020CTN00330 STICKER-WARNING CASTON-SERIES (영공) 9100CT201300 C/T BOX 510*430*370(C-2) 9100CT20W300 C/T BOX 635*565*505(C-2 W) 9205APE00150 P.E BOX (상) 500*430*120(THB) 9205APE00160 P.E BOX (하)
Page 131 Service Manual CASTON - CASTON II(1 ton) PARTS NAME : BODY ASS'Y 1030CT300001 BATTERY-CHARGER CASE CASTON(BODY CASE) 1030CT300002 BATTERY-CHARGER CASE CASTON(COVER CASE) 1030MS000001 BATTERY-CHARGER PAINT CASTON(BODY,BLACK,인쇄포함) 1030MS000002 BATTERY-CHARGER PAINT CASTON(COVER,IVORY) 1035A000007C BATTERY CASE 204*125.8*80(C-2) 1035A0000360 SAFETY LATCH 0.5-1TON 1060A0000150 P.C.B CONTACT(-)
Page 132 Service Manual CASTON 1532A0006080 BOLT-WRENCH(ST) M6*8 1532MSU08100 BOLT-WRENCH(ST) M8*10-SUS 1533MIS04120 BOLT-WRENCH(FH) M4*12착색 EA 10 1533MIS06150 BOLT-WRENCH(FH) M6*15착색 1554A0006000 WASHER(FIB) ø6 1561MSU05000 E-RING ø5*ø11*0.6-SUS 1564A0002060 RIVET TWIST ø2.6*6 1590A0000320 BATTERY SPRING A ø9*ø0.6*3(MW-Ⅱ) 1595A0000030 HOOK SPRING ø0.8(S) 1595A0000080 HELI COIL 6*1.09*1.5D 1815CT200330 SPEC PLATE CASTON-II(영공)
Page 133 Service Manual CASTON 9025CT210330 STICKER CASTON-II 영공(소진 불용) PARTS NAME : C/T BOX ASS'Y 9007CT000330 MANUAL CASTON안전메뉴얼(영문) 9007CT200333 MANUAL CASTON-ll공용(영문) 9020A0000331 STICKER SAFETY STICKER 영공 9020CTN00330 STICKER-WARNING CASTON-SERIES (영공) 9100CT201300 C/T BOX 510*430*370(C-2) 9100CT20W300 C/T BOX 635*565*505(C-2 W) 9205APE00150 P.E BOX (상) 500*430*120(THB) 9205APE00160 P.E BOX (하)
Page 134 Service Manual CASTON - CASTON II(2 ton) PARTS NAME : BODY ASS'Y 1030CT300001 BATTERY-CHARGER CASE CASTON(BODY CASE) 1030CT300002 BATTERY-CHARGER CASE CASTON(COVER CASE) 1030MS000001 BATTERY-CHARGER PAINT CASTON(BODY,BLACK,인쇄포함) 1030MS000002 BATTERY-CHARGER PAINT CASTON(COVER,IVORY) 1035A000007C BATTERY CASE 204*125.8*80(C-2) 1035A0000370 SAFETY LATCH 2T-5TON 1060A0000150 P.C.B CONTACT(-)
Page 135 Service Manual CASTON 1532MSU08100 BOLT-WRENCH(ST) M8*10-SUS 1533MIS04120 BOLT-WRENCH(FH) M4*12착색 EA 10 1533MIS06150 BOLT-WRENCH(FH) M6*15착색 1554A0006000 WASHER(FIB) ø6 1561MSU05000 E-RING ø5*ø11*0.6-SUS 1564A0002060 RIVET TWIST ø2.6*6 1590A0000320 BATTERY SPRING A ø9*ø0.6*3(MW-Ⅱ) 1595A0000020 HOOK SPRING ø1.2(L) 1595A0000080 HELI COIL 6*1.09*1.5D 1815CT200330 SPEC PLATE CASTON-II(영공) 2005A000022B FRONT COVER...
Page 136 Service Manual CASTON PARTS NAME : C/T BOX ASS'Y 9007CT000330 MANUAL CASTON안전메뉴얼(영문) 9007CT200333 MANUAL CASTON-ll공용(영문) 9020A0000331 STICKER SAFETY STICKER 영공 9020CTN00330 STICKER-WARNING CASTON-SERIES (영공) 9100CT201300 C/T BOX 510*430*370(C-2) 9100CT20W300 C/T BOX 635*565*505(C-2 W) 9205APE00150 P.E BOX (상) 500*430*120(THB) 9205APE00160 P.E BOX (하) 500*430*230(THB) 9300A0000020 POLY BAG...
Page 137 Service Manual CASTON - CASTON II(3 ton) PARTS NAME : BODY ASS'Y 1030CT300001 BATTERY-CHARGER CASE CASTON(BODY CASE) 1030CT300002 BATTERY-CHARGER CASE CASTON(COVER CASE) 1030MS000001 BATTERY-CHARGER PAINT CASTON(BODY,BLACK,인쇄포함) 1030MS000002 BATTERY-CHARGER PAINT CASTON(COVER,IVORY) 1035A000007C BATTERY CASE 204*125.8*80(C-2) 1035A0000370 SAFETY LATCH 2T-5TON 1060A0000150 P.C.B CONTACT(-)
Page 138 Service Manual CASTON 1532MSU08100 BOLT-WRENCH(ST) M8*10-SUS 1533MIS04120 BOLT-WRENCH(FH) M4*12착색 EA 10 1533MIS06150 BOLT-WRENCH(FH) M6*15착색 1554A0006000 WASHER(FIB) ø6 1561MSU05000 E-RING ø5*ø11*0.6-SUS 1564A0002060 RIVET TWIST ø2.6*6 1590A0000320 BATTERY SPRING A ø9*ø0.6*3(MW-Ⅱ) 1595A0000020 HOOK SPRING ø1.2(L) 1595A0000080 HELI COIL 6*1.09*1.5D 1815CT200330 SPEC PLATE CASTON-II(영공) 2005A000022B FRONT COVER...
Page 139 Service Manual CASTON PARTS NAME : C/T BOX ASS'Y 9007CT000330 MANUAL CASTON안전메뉴얼(영문) 9007CT200333 MANUAL CASTON-ll공용(영문) 9020A0000331 STICKER SAFETY STICKER 영공 9020CTN00330 STICKER-WARNING CASTON-SERIES (영공) 9100CT201300 C/T BOX 510*430*370(C-2) 9205APE00150 P.E BOX (상) 500*430*120(THB) 9205APE00160 P.E BOX (하) 500*430*230(THB) 9300A0000020 POLY BAG 90*150*0.05T(FUSE) 9301A0000030 POLY BAG...
Page 140 Service Manual CASTON - CASTON II(5 ton) PARTS NAME : BODY ASS'Y 1030CT300001 BATTERY-CHARGER CASE CASTON(BODY CASE) 1030CT300002 BATTERY-CHARGER CASE CASTON(COVER CASE) 1030MS000001 BATTERY-CHARGER PAINT CASTON(BODY,BLACK,인쇄포함) 1030MS000002 BATTERY-CHARGER PAINT CASTON(COVER,IVORY) 1035A000007C BATTERY CASE 204*125.8*80(C-2) 1035A0000370 SAFETY LATCH 2T-5TON 1060A0000150 P.C.B CONTACT(-)
Page 141 Service Manual CASTON 1531A0006250 BOLT-WRENCH(MHO) M6*25 1532A0006080 BOLT-WRENCH(ST) M6*8 1532MSU08100 BOLT-WRENCH(ST) M8*10-SUS 1533MIS04120 BOLT-WRENCH(FH) M4*12착색 EA 10 1533MIS06150 BOLT-WRENCH(FH) M6*15착색 1554A0006000 WASHER(FIB) ø6 1561MSU05000 E-RING ø5*ø11*0.6-SUS 1564A0002060 RIVET TWIST ø2.6*6 1590A0000320 BATTERY SPRING A ø9*ø0.6*3(MW-Ⅱ) 1595A0000020 HOOK SPRING ø1.2(L) 1595A0000080 HELI COIL 6*1.09*1.5D 1815CT200330...
Page 142 Service Manual CASTON 7840W003230A CONNECTOR WIRE GXR-3-11*2P*300(CASTON-2 전용) 9025CT200330 WARNING BATTERY STICKER CASTON-II(영공) PARTS NAME : C/T BOX ASS'Y 9025CT200330 WARNING BATTERY STICKER CASTON-II(영공) 9007CT000330 MANUAL CASTON안전메뉴얼(영문) 9007CT200333 MANUAL CASTON-ll공용(영문) 9020A0000331 STICKER SAFETY STICKER 영공 9020CTN00330 STICKER-WARNING CASTON-SERIES (영공) 9100CT201300 C/T BOX 510*430*370(C-2) 9205APE00150...
Page 143 Service Manual CASTON 5/13/2014...

This manual is also suitable for:

Caston iii Caston iii plus

CAS CASTON II Service Manual

Quick Links

Need help?

Questions and answers

Related Manuals for CAS CASTON II

Summary of Contents for CAS CASTON II

This manual is also suitable for:

Table of Contents
