Projecta INVCHRD-BT Quick Start Manual page 4

DETAIL LED DISPLAY INFORMATION OF BATTERY SOC
Battery Status SOC
SOC=100%
80%≤SOC < 100%
60%≤SOC < 80%
Charging
40%≤SOC < 60%
20%≤SOC < 40%
0%≤SOC < 20%
80%≤SOC ≤ 100%
60%≤SOC < 80%
40%≤SOC < 60%
Discharge
20%≤SOC < 40%
0%≤SOC < 20%
SOC=0
DISPLAY INFORMATION VALUE AREA
Display Information
Battery
AC Output
AC Input
Solar
CONFIGURATION ITEMS AND SETTING VALUES
Display Information
V
Battery
V
A
V
AC Output
Hz
AC Input A
Buzzer Alarms
Enable SOC Display
Enable Screen Off Function
NOTE: Once the Screen Off function is enabled, the screen will automatically go off if there is no key operation for three
minutes. If the inverter status changes or an alarm occurs, it will be restarted keep the screen on for three minutes.
LED 1
Illuminate
Illuminate
Illuminate
Illuminate
Illuminate
Flash
Illuminate
Illuminate
Illuminate
Illuminate
Illuminate
Off
Item
V Battery voltage
A Battery current
kW AC output power
Hz AC output frequency
V AC output voltage
A AC output current
kW AC Input power
Hz AC Input frequency
V AC Input voltage
A AC Input current
kW PV power
V PV voltage
Configuration Item
Absorption Voltage,
Float Voltage, Flashing
Max Charge Current
Output Voltage
Output Frequency
AC Input Rating
Buzzer ON or OFF
SOC lights and battery back-
ground lights are all flash
Power lights and battery back-
ground lights are all flash
LED 2 LED 3
Illuminate Illuminate
Illuminate Illuminate
Illuminate Illuminate
Illuminate Flash
Flash Off
Off Off
Illuminate Illuminate
Illuminate Illuminate
Illuminate Illuminate
Illuminate Off
Off Off
Off Off
Note: Solar is for the INVCHR3-48V
with built in MPPT
Default Setting and Setting Step
Step: 0.1V, Default: 14.1V
ON
Step: 0.1V, Default: 13.6V
Step: 1A, Default: 30A
Step: 10V, Default: 240V
Default: 50/60Hz
Step: 1A, Default: 32A
Default: ON
ON: Enable SOC display
OFF: Disable SOC display
Default: ON
ON: Enable the Screen Off Function
OFF: Disable the Screen Off Function
Default: OFF
LED 4 LED 5
Illuminate Illuminate
Illuminate Flash
Flash Off
Off Off
Off Off
Off Off
Illuminate Illuminate
Illuminate Off
Off Off
Off Off
Off Off
Off Off
