DEMO MANUAL DC416

parts List

ITEM QTY REFERENCE
1 15 C1, C4-C6, C10, C11, C13-C20, C23
2 1 C2
3 2 C3, C12
4 2 C7,C9
5 1 C8
6 2 C21, C22
7 9 E1-E9
8 5 JP1, JP2, JP3, JP4, JP5
9 2 JP6, JP7
10 2 JP8, JP9
11 9 SHUNTS FOR JP1-JP9
12 3 J1-J3
13 1 J4
14 1 RN1
15 2 R1, R2
16 2 R3, R4
17 2 R5, R6
18 1 R7
19 1 R8
20 1 R9
21 1 R10
22 1 U1
23 0 U2
24 1 U3
25 2 U4, U5
26 2 U6, U7
27 1 U8
28 1 U9
29 1 U10
30 1 U11
31 1 U12
32 1 U13
33 4 MTGS AT 4 CORNERS
34 4 MTGS AT 4 CORNERS
NOTES: UNLESS OTHERWISE SPECIFIED
1. ALL RESISTORS ARE IN OHMS.
2. INSTALL SHUNTS ON JP1, JP3-JP7 PIN 1 AND 2;
ON JP8 AND JP9 PIN 2 AND 4, PIN 3 AND 5.
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP., X7R, 0.1µF, 16V
CAP., X7R, 1µF, 10V, 20%
CAP., X5R, 10µF, 6.3V, 20%, 1206
CAP., NPO, 100PF, 50V, 1206
CAP., NPO, 470PF, 100V,1206
CAP., NPO, 47PF, 50V
TP, TURRET, .094"
JMP, 1 × 2 .079CC
JMP, 1 × 3 .079CC
JMP, 2 × 3 .079CC
SHUNT, .079" CENTER
CONN, BNC 50Ω, PCB-VERTICADTL
CON, HDR, .1 × .1 CNTRS, 40PIN
RES 2 × 4 ARRAY, CHIP, 330Ω, ISO
RES, CHIP 100, 1/16W, 5%, 1206
RES, CHIP 2, 1/16W, 5%, 0603
RES, CHIP 402, 1/16W, 1%,0603
RES, CHIP 20k, 1/16W, 5%,0603
RES, CHIP 15k, 1/16W, 5%,0603
RES, CHIP 51, 1/16W, 5%,0603
RES POT3321H, POT-3321H-MURATA
IC, LT1021DCS8-5, SO8
IC, OP AMP, SO8
IC, LTC1864AIMS8, MSOP8
IC, MC74HC595ADT, TSSOP16
IC, MC74HC163AD, SO16
IC, MC74AC14DTR2, TSSOP14
IC, MC74AC00DTR2, TSSOP14
IC, LTC1799, SOT23-5
IC, LT1121CST-5, SOT223
IC, MC74AC109DR2, SO16
IC, MC74AC32DTR2, TSSOP14
SCREW, #4-40, 1/4"
STANDOFF, NYLON HEX #4-40 1/2"
MANUFACTURER/PART NUMBER
AVX, 0603YC104MAT1A
AVX, 0805ZC105MAT1T
TAIYO YUDEN JMK316BJ106MLT
VITRAMON, VJ1206A101JXB
AVX, 12061A471JAT
AVX, 06035A470MAT1A
MILL-MAX, 2501-2
COMM-CON, 2802S-02-G1
COMM-CON, 2802S-03-G1
COMM-CON, 2202S-06-G2
COMM-CON, CCIJ2MM-138G
CONNEX, 112404
COMMCON, 3201S-40G1
CTS, 742-C083-331JTR-ND
AAC, CR18-101JM
AAC, CR16-2R0JM
AAC, CR16-4020FM
AAC, CR16-203JM
AAC, CR16-153JM
AAC, CR16-510JM
MURATA, POT3321H-1-103
LINEAR TECH., LT1021DCS8-5
TBD
LINEAR TECH., LTC1864AIMS8
MOTOROLA, MC74HC595ADT
MOTOROLA, MC74HC163AD
ON SEMI., MC74AC14DTR2
ON SEMI., MC74AC00DTR2
LINEAR TECH., LTC1799
LINEAR TECH., LT1121CST-5
ON SEMI., MC74AC109DR2
ON SEMI., MC74AC32DTR2
ANY
MICRO PLASTICS 14HTSP003
dc416f
