Summary of Contents for Chiayo SDR-5900

  • Page 1 SDR-5900 Operation manual Dual-Channel 2-Way Sync True Diversity Receiver CHIAYO ELECTRONICS CO., LTD.
  • Page 2 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver Important safety instructions ◼ READ, KEEP and HEED these instructions. ◼ CLEAN ONLY with dry cloth. ◼ DO NOT block any ventilation openings. Allow sufficient distances for adequate ventilation and install in accordance with the manufacturer’s instructions.
  • Page 3 Instructions Thank you for choosing CHIAYO wireless microphone system! For more details, please take a few moments to read this operating manual for thorough understanding of the function and operation of both transmitter and receiver. In the box SDR-5900 receiver...
  • Page 4 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver Parts and functions CH-1 CH-1 CH-2 CH-2 UP▲ IR sensor CH-1 UP▲ IR sensor CH-2 DOWN▼ DOWN▼ IrDA sync Volume control IrDA sync Volume control MENU MENU MENU MENU M H z M H z...
  • Page 5 Instructions Receiver installation 1. The receiver should be at least 1m above the ground and 1m away from a wall or metal surface to minimize reflections. 2. The transmitter should also be at least 1m away from a wall or metal surface to minimize reflections.
  • Page 6 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver Channel synchronizing between receiver and transmitter Align infrared areas of the receiver and transmitter within 10~30cm. MENU MENU 10~30cm M H z FREQ ENTER ENTER SYNC SYNC Changing the receiver’s channel Press the synchronizing button of the transmitter.
  • Page 7 Instructions Channel scanning For an interference- free operation, a cleaner channel might be necessary if the current one receives too much interference. To operate the scanning: Press MENU button to make the frequency icon appear on the bottom. MENU MENU 650.250 ...
  • Page 8 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver Squelch (SQ) setting You may adjust the SQUELCH (SQ) when strong RF interference is encountered. When the transmitter is turned off but the receiver still has audio output, it is apparent that there is RF interference.
  • Page 9 LIN E M IC LIN E LINE 1 LINE 2 MIC 1 MIC 2 MIXED OUT MIXED OUT SDR-5900 amplifier SDR-5900 amplifier ◼ Individual balanced audio output XLR connector provides balanced audio output signal from this jack to the mixer/amplifier.
  • Page 10 IrDA is the abbreviation of Infrared Data Association. It is a standard for the equipment which use infrared for short-distance transmission. (i.e. computers, PDAs and mobile phones) CHIAYO is the first company to apply this technology to wireless microphone products.
  • Page 11 CHIAYO ELECTRONICS CO., LTD. Http://www.chiayo.com.tw | Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 | Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 | Fax: 886-5-5767611...
