DWR-2410 / DWR-2400 Operation manual Detachable Antenna Digital Receiver D W R -2410 Digital Wireless Receiver 2480 M H z FREQ CHIAYO ELECTRONICS CO., LTD. - Page 2 DWR-2410 / DWR-2400 Detachable Antenna Digital Receiver Detachable Antenna Dual Channel Digital Receiver Thank you for choosing CHIAYO digital wireless microphone system! For more details, please take a few moments to read this operating manual for thorough understanding of the function and operation of both transmitter and receiver.
- Page 3 Instructions Changing CHANNEL / FREQUENCY Press-release ▲(UP) or ▼(DOWN) button until the below channel icon appears. SYNC 2407 M Hz Press and hold SET button until the channel number flashes to denote readiness for setting. SYNC 2407 M Hz Press-release ▲(UP) or ▼(DOWN) button to select a new channel. SYNC 2437 M Hz...
- Page 4 DWR-2410 / DWR-2400 Detachable Antenna Digital Receiver Detachable Antenna Dual Channel Digital Receiver CHANNEL scanning For an interference- free operation, a cleaner channel might be necessary if the current one receives too much interference. Before scanning, the transmitter must be switched off.
- Page 5 Instructions CHANNEL SYNCHRONIZING of the receiver and transmitter Press and hold the transmitter’s synchronizing button until LINK flashes on the LCD. CH :0 00 L I N K FREQ Press and hold the receiver’s SYNC button until the frequency icon appears.
- Page 6 DWR-2410 / DWR-2400 Detachable Antenna Digital Receiver Detachable Antenna Dual Channel Digital Receiver CHANNEL GROUP setting GROUP CH081 includes 81 selectable frequencies from CH1 to CH81. GROUP CH189 includes 189 selectable frequencies from CH1 to CH189. Press-release ▲(UP) or ▼(DOWN) button until the below group icon appears.
- Page 7 Instructions Fig 1: Rack mount of one receiver Fig 2: Rack mount of two receivers Audio output connection Balanced output: XLR connector provides balanced audio output signal from this jack to the mixer/amplifier. Use an audio output cable with “XLR” or “Cannon” connector, connect one end to the balanced output jack of the receiver, and the other end to the “MIC IN”...
- Page 8 Detachable Antenna Dual Channel Digital Receiver CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw ｜ Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 ｜ Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 ｜ Fax: 886-5-5767611...
