SDR-5900
Operation manual
Dual-Channel 2-Way Sync True
Diversity Receiver
CHIAYO ELECTRONICS CO., LTD.

Advertisement

loading
Need help?

Need help?

Do you have a question about the SDR-5900 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Chiayo SDR-5900

  • Page 1 SDR-5900 Operation manual Dual-Channel 2-Way Sync True Diversity Receiver CHIAYO ELECTRONICS CO., LTD.
  • Page 2 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver Thank you for choosing this wireless microphone system! For more details, please take a few moments to read this operating manual to have a thorough understanding of the function and operation of both transmitter and receiver.
  • Page 3: Parts And Functions

    Instructions Parts and functions 11 12 13 3 4 5 MENU MENU MENU MENU ►front panel M H z M H z S D R - 5 9 0 0 S D R - 5 9 0 0 FR EQ FR EQ TRUE DIVERSITY RECEIVER TRUE DIVERSITY RECEIVER...
  • Page 4 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver CHANNEL scanning For an interference- free operation, a cleaner channel might be necessary if the current one receives too much interference. To operate the scanning: Press MENU button to make the frequency icon appear on the bottom.
  • Page 5 Instructions Channel synchronizing between receiver and transmitter Align infrared areas of the receiver and transmitter within 10~30cm. MENU MENU 10~30cm M H z FREQ ENTER ENTER SYNC SYNC Changing the receiver’s channel Press the synchronizing button of the transmitter. The transmitter's LED will glow to denote synchronizing signal transmitted.
  • Page 6 SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver SQUELCH (SQ) adjusting When interference is encountered try reducing the sensitivity of the receiver, thus less susceptible to interference. To operate the squelch setting: Press MENU button to turn to the squelch setting page.
  • Page 7: Audio Output Connection

    Instructions Audio output connection There are three audio outputs on the back of the receiver, Mic-level balanced (channel 1 and channel 2), and Line-level unbalanced (mixed). Use shielded audio cable for the connection between the receiver and the amplifier/mixer. If the amplifier/mixer has a 1/4"(6.3mm) phone jack, connect a cable from the 1/4"(6.3mm) unbalanced audio output from the receiver to the amplifier/mixer.
  • Page 8 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw | Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan Tel: 886-2-27415741 | Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan Tel: 886-5-2711000 | Fax: 886-5-5767611...
