Summary of Contents for Chiayo NDR-2120
-
Page 1: Operation Manual
NDR-2120 Operation manual VHF Dual Channel Auto Sync Receiver NDR-2120 W IR ELESS RECEIVER M IN M A X SY N C SY N C M IN PW R M AX CHIAYO ELECTRONICS CO.,LTD. - Page 2 NDR-2120 VHF Dual Channel Auto Sync Receiver Thank you for choosing this wireless microphone system! For more details, please take a few moments to read this operating manual to have a thorough understanding of the function and operation of both transmitter and receiver.
-
Page 3: Parts And Functions
Instructions Parts and functions Antennas (fixed) Power/Volume control Channel indicator NDR-2120 W IR ELESS RECEIVER M A X M IN PW R M AX M IN SY N C SY N C Channel scan button Channel synchronization button IR sensor LED... -
Page 4: Adjusting Volume Level
NDR-2120 VHF Dual Channel Auto Sync Receiver Function settings on NDR-2120 Adjusting VOLUME level Both channel’s volume level can be adjusted separately by rotating its designated volume knob. NDR-2110 WIRELESS RECEIVER SYNC MIN PWR MAX Scanning & Changing CHANNEL First turn on main power switch, the 7-segment display LED will show current channel number. -
Page 5: Adjusting Squelch Level
If this still does not solve the problem it means this frequency is not suitable. Adjust the squelch back to where it was and use the scan function to locate a clear channel. NDR-2120 WIRELESS RECEIVER MIN PWR MAX... -
Page 6: Receiver Placement
NDR-2120 VHF Dual Channel Auto Sync Receiver Audio output connection Unbalanced output: ¼” PHONE PLUG connector provides unbalanced audio output signal from this jack to the mixer/amplifier. Use an audio output cable with ¼” PHONE PLUG connectors. Connect one end from the unbalanced output jack of the receiver, and the other end to the “LINE IN”... -
Page 7: Rack Mounting
Instructions Rack mounting The slide rail structure on both sides of the receiver is designed to facilitate the user to connect the two receivers in parallel and quickly install onto the cabinet. ► Rack mount of two receivers Rack mount of single receiver... - Page 8 CHIAYO ELECTRONICS CO.,LTD. Http://www.chiayo.com.tw｜Email: sales@chiayo.com.tw Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan｜Tel: 886-2-27415741｜Fax: 886-2-27525242 Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan｜Tel: 886-5-2711000｜Fax: 886-5-5767611...
