Introduction

The SMB Series transmitters are the product of many
years of engineering and experience in professional
audio markets. The unique design provides several
distinct features for professional applications:
• Superb, compandor-free audio quality
• Ultra-lightweight, corrosion resistant housing
• Water resistant seals for use in damp environ-
ments
• Programmable compatibility modes for use with
a wide variety of different receivers
The Digital Hybrid Wireless
7,225,135) combines 24-bit digital audio with analog
FM resulting in a system that has the same operating
range as analog systems, the same spectral efficiency
as analog systems, the same long battery life as analog
systems, plus the excellent audio fidelity typical of pure
digital systems.
The transmitters feature the unique servo bias input
circuitry with a standard TA5M type input jack for use
with electret lavaliere mics, dynamic mics, or line level
signals. A water resistant control panel with LCD, mem-
brane switches and multi-color LEDs make input gain
adjustments, frequency and compatibility mode selec-
tion quick and accurate, without having to view the
receiver. The battery compartment accepts AA lithium
or rechargeable batteries. The housings are machined
from solid aluminum blocks to provide an extremely
lightweight and rugged package. A special non-corro-
sive finish resists salt water exposure and perspiration
in extreme environments.
The DSP-based design works with Euro version Digital
Hybrid and IFB receivers.
The SMB/E01 and SMDB/E01 may be operated in:
AT BE BG
DE DK EE
HU IE IS
MT NL NO
SI SK UK
The use of these transmittters requires a license and is
subject to national restrictions on frequency selection
and channel spacing.
Rio Rancho, NM
design (US Patent
®
CH CY CZ
FI FR GR
LT LU LV
PT RO SE
Super-Minature Belt Pack Transmitters
