Parts List - Linear Technology DC1587 Demo Manual

DEMO MANUAL DC1587

PARTS LIST

ITEM QUANTITY
Required Circuit Components
1
2
3
4
5
6
7
8
9
10
Additional Circuit Components
1
2
3
4
5
6
7
8
9
10
11
12
13
Hardware
1
2
3
4
5
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
REFERENCE
1 C1
1 C3
1 C5
1 C8
1 L1
1 R1
1 R4
1 R6
1 R10
1 U1
0 C2
1 C4
1 C6
1 C7
1 C10
1 R2
1 R3
1 R5
1 R7
1 R8
1 R9
1 R11
1 R12
12 E1-E12
2 JP4 JP5
,
1 JP2
2 JP1 JP3
,
5 JP1-JP5
PART DESCRIPTION
Capacitor, X5R, 10μF , 6.3V, 10%, 0805
Capacitor, X5R, 10μF , 16V, 10%, 0805
Capacitor, NPO, 33pF , 25V, 5%, 0402
Capacitor, X5R, 1μF , 16V, 10%, 0603
Inductor, 10μH
Resistor, Chip, 392k, 1/16W, 1%, 0402
Resistor, Chip, 499k, 1/16W, 1%, 0402
Resistor, Chip, 40.2k, 1/16W, 1%, 0402
Resistor, Chip, 100k, 1/16W, 1%, 0402
IC, LTC3105EDD, 3mm × 3mm DFN
Tantalum, OPT
Capacitor, X5R, 1μF , 16V, 10%, 0805
Capacitor, NPO, 33pF , 25V, 5%, 0402
Capacitor, X5R, 4.7μF , 16V, 10%, 0805
Capacitor, X7R, 10nF , 50V, 10%, 0603
Resistor, Chip, 750k, 1/16W, 1%, 0402
Resistor, Chip, 845k, 1/16W, 1%, 0402
Resistor, Chip, 0, 0402
Resistor, Chip, 200k, 1/16W, 1%, 0402
Resistor, Chip, 402k, 1/16W, 1%, 0402
Resistor, Chip, 549k, 1/16W, 1%, 0402
Resistor, Chip, 274k, 1/16W, 1%, 0402
Resistor, Chip, 1.1M, 1/16W, 1%, 0402
Testpoint, Turret, 0.095"
0.079 Single Row Header, 3-Pin
2mm Double Row Header 4mm × 2mm
2mm Double Row Header 2mm × 3mm
Shunt
MANUFACTURER, PART NUMBER
AVX, 08056D106KAT2A
Taiyo Yuden, EMK212BJ106KG-T
AVX, 04023A330JAT2A
AVX, 0603YD105KAT2A
Sumida, CDRH3D18NP-100N
Vishay, CRCW0402392KFKED
Vishay, CRCW0402499KFKED
Vishay, CRCW040240K2FKED
Vishay, CRCW0402100KFKED
Linear Technology, LTC3105EDD
AVX, 0805YD105KAT2A
AVX, 04023A330JAT2A
Taiyo Yuden, EMK212BJ475MG-T
AVX, 06035C103KAT2A
Vishay, CRCW0402750KFKED
Vishay, CRCW0402845KFKED
Vishay, CRCW04020000JKED
Vishay, CRCW0402200KFKED
Vishay, CRCW0402402KFKED
Vishay, CRCW0402549KFKED
Vishay, CRCW0402274KFKED
Vishay, CRCW04021M10FKED
Mill-Max, 2501-2-00-80-00-00-07-0
Samtec, TMM-103-02-L-S
Samtec, TMM-104-02-L-D
Samtec, TMM-103-02-L-D
Samtec, 2SN-BK-G
