Summary of Contents for real living BQ092-1320
-
Page 2: Maintenance
GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to being Two people are recommended for assembly. Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its number in the package Helpful hints provided along the way WARNINGS:... -
Page 3: Parts List
PARTS LIST DESCRIPTION Top Panel Divider Shelf Panel 2pcs Top Metal Frame Left Metal Leg Right Metal Leg 2pcs Short Metal Bar 2pcs Long Metal Bar HARDWARE LIST PARTS DESCRIPTION 18pcs Cam Bolt 18pcs Cam Lock 2pcs Wooden Dowel 2pcs Screw 12pcs Bolt(6×10mm) -
Page 4: Helpful Hints
HARDWARE LIST PARTS DESCRIPTION Nut(6×15mm) 4pcs Nut(6×20mm) Nut(6×5mm) Allen Wrench HELPFUL HINTS • A Phillips Screwdriver and a flat head screwdriver will be needed for assembly and are not provided. • Separate parts before starting. HOW TO INSTALL THE CAM BOLT AND CAM LOCK 1. - Page 5 Insert Cam Bolt (1) into Top Metal Frame (D) and fully tighten using Phillips screwdriver (not provided). 1 x 16 1. Align the Cam Bolt (1) in Top Metal Frame (D) with the holes in the edge of Top Panel (A) and Shelf Panel (C) and slide into place. 2.
- Page 6 Attach Left Metal Leg (E) and Right Metal Leg (F) to Top Metal Frame (D) with Bolt (5) using Allen Wrench (9). Fully tighten bolts. 5 x 8 9 x 1 1. Insert the Bolt (6) into the holes on one end of every Short Metal Bars (G) and Long Metal Bars (H) as shown in the diagram.
