Summary of Contents for real living BL-VY-B-SM-3A
-
Page 2: Maintenance
GENERAL BEST PRACTICES FOR ASSEMBLY: GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a fat covered space to being You will need two adults to assemble this item Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its number in the package... -
Page 3: Parts List
PARTS LIST Drawer Front Top Panel Table Legs Drawer Back Drawer Left Side Drawer Right Side Mirror Frame Drawer Bottom Stool Cushion Stool Legs... -
Page 4: Hardware List
HARDWARE LIST Ø1/4 x 2" Ø1/4" x Ø19 Ø1/4 x 1-1/2" Allen Bolt Flat Washer Allen Bolt Ø1/4" x Ø11 Ø30" x Ø30 x 32mm Ø5/32 x 30mm Spring Washer Knob Bolt #8 x 25mm 4 x 60mm Ø1/4" x Ø1 Screw Allen Key Flat Washer... -
Page 5: Helpful Hints
HELPFUL HINTS CARE AND CLEANING Treat uphostered surfaces with care. Clean any spills immediately using a clean, slightly dampened cloth and dabbing the area until the spill is removed. DO Not use any chemical cleaners. Hardware may loosen over time. Periodically check all bolts and fully tighten any that are loose. Check all bolts and fully tighten any that are loose. - Page 6 STEP 1 Carefully place the Top Panel (A) upside down on a soft smooth surface to avoid scratching the surface. Attach Table Legs (B) to Top Panel (A) with Allen Bolt (1), Spring Washer (4) and Flat Washer (3) using Allen Key (7). Ensure the legs are straight and fully tighten the bolts.
- Page 7 STEP 2 Attach the Drawer Right Side (D) and Drawer Left Side (E) to the Drawer Front (C) with Screw (8) using Phillips screwdriver (not included). Fully tighten screws. Insert the Drawer Bottom (F) into the groove of Drawer Right Side (D) and Drawer Left Side (E) until fully inserted into the groove of Drawer Front (C) .
- Page 8 STEP 3 Attach the Knob (5) to Drawer Front (C) with Bolt (6) using Phillips screwdriver (not included) and fully tighten. Screwdriver (Not included) Assembled View: Page 7 of 12...
- Page 9 STEP 4 With assistance from the other adult, return the assembled table to the upright position. Insert the assembled drawer into the table. Assembled View:...
- Page 10 STEP 5 Attach the Assembled irror (G) to the Table Top with Allen Bolt (2) Spring Washer (4) and Flat asher (9) using Allen Key (7). Fully tighten all bolts. Assembled View: Page 9 of 12...
- Page 11 STEP 6 Place the Stool Cushion (H) upside down. Attach Stool Legs (I) to Stool Cushion (H) with Allen Bolt (1), Spring Washer (4) and Flat Washer (3) using Allen Key (7). Ensure Legs are straight and fully tighten all bolts. Assembled View: Page 10 of 12...
- Page 12 STEP 7 Install the Anti-tipping Kit (10) to secure the vanity to the wall and prevent tip over. HH510 Install one bracket in the top center of the table back using X1 Bag one of the provided screws. Place the vanity in the desired location and mark where the installed bracket meet the wall.
- Page 13 STEP 8 Page 12 of 12...
