  • Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instruc�ons before star�ng Clear a flat covered space to assemble We recommend two people for assembly Note that hardware required is provided for every step Pay a�en�on to orienta�on Le�er of the part corresponds to a s�cker on the product Number of the hardware corresponds to its number in the package Helpful hints provided along the way MAINTENANCE:...
  • Page 3 PARTS LIST Bottom Side Frame Upper Side Frame Shelf Top Shelf HARDWARE LIST Phillips Screw Allen Bolt Phillips Screw Allen Bolt Adjuster Screw Cap Washer Wall Strap Wall Plug Phillips Screw Allen Wrench Phillips head screw Driver HELPFUL HINTS • Separate parts before starting...
  • Page 4 STEP 1 Insert Adjuster (4) into Bottom Side Frame (A). Attach Upper Side Frame (B) to Bottom Side Frame (A) with Phillips Screw (2). Fully tighten. Please pay attention to the direction of the metal plate. Assembled View: STEP 2 Attach Shelf (C) to Side Frame assembled in Step 1 with Allen Bolt (1).
  • Page 5 STEP 3 Attach the other Side Frame assembled in Step 1 to Shelf (C) with Allen Bolt (1). Assembled View: STEP 4 Attach Top Shelf (D) to the Frame assembled in Step 3 with Allen Bolt (3). Fully tighten. Assembled View:...
  • Page 6 STEP 5 Place Screw Cap (5) onto Allen Bolt (1) and firmly press into place. To prevent serious injury or death, this product is equipped with a wall anchoring system. Before this product can be used, the wall anchoring system must be installed as directed in the assembly instructions.
