- Page 2 GENERAL BEST PRACTICES FOR ASSEMBLY: Read all instructions before starting Clear a flat covered space to begin Two adults are recommended for assembly Note that hardware required is provided for every step Pay attention to orientation Letter of the part corresponds to a sticker on the product Number of the hardware corresponds to its number in the package Helpful hints provided along the way WARNINGS:...
- Page 3 PARTS LIST DESCRIPTION 2pcs Large Shelf Panel Small Shelf Panel 2pcs Metal Plate 2pcs Bottom Metal Leg Front Upper Frame Back Upper Frame Front L Shape Tube Back L Shape Tube Front Bottom Frame Back Bottom Frame Page 3 of 8...
- Page 4 HARDWARE LIST PARTS DESCRIPTION Cam Bolt 20pcs 20pcs Cam Lock 8pcs Bolt(6×10mm) 8pcs Bolt(6×35mm) Screw(4×35mm) 4pcs Screw(4×12mm) 4pcs 2pcs Anchor Bracket 4pcs Plastic Plug Allen Wrench 2pcs Plastic Lock Strap 4pcs Rubber Feet Sticker HELPFUL HINTS • A Phillips Screwdriver and a flat head screwdriver will be needed for assembly and are not provided. •...
- Page 5 1. Carefully place the Frames (E, F, I and J) on their back as shown in the diagram. 2. Insert Front Upper Frame (E) into Front Bottom Frame (I), Back Upper Frame (F) into Back Bottom Frame (J) as shown in the diagram. Tip: the Bolt holes on the Frames (E, F, I and J) need to be facing the same direction.
- Page 6 Insert Cam Bolt (1) into Assembled Front and Back Frame. Fully tighten using Phillips screwdriver (not provided). 1 x 20 Attach Metal Plate (C) to the Back of Large Shelf Panel (A) with Screw (6) using using Phillips screwdriver (not provided). Fully tighten bolts. 6 x 4 1.
- Page 7 1. Align Cam Bolt (1) in Front Upper Frame (E), Front Bottom Frame (I) and Front L Shape Tube (G) with the holes in the edge of Large Shelf Panel (A) and Small Shelf Panel (B) and slide into place. 2 x 10 TIP: Metal Plate (C) should fully insert into the groove on Front Upper Frame (E) and Front Bottom Frame (I)
- Page 8 step 1 5 x 4 7 x 2 8 x 4 10 x 2 step 2 step 3 step 4 1. Place the assembled Console in the desired position. Mark where the Console meet the wall. step 5 Remove the Console. 2.
