GENERAL BEST PRACTICES FOR ASSEMBLY: Determine you have adequate space for assembly. Assembly by two adults is recommended. Assemble on soft surfaces to prevent damage to product finish. Keep children away during assembly. This item contains small parts which can be swallowed by children.
PARTS LIST Top panel Left Side Panel Left Middle Panel x 1 pc x 1 pc x 1 pc Right Middle Panel Right Side Panel Left Door x 1 pc x 1 pc x 1 pc Right Door Side Back Panel Center Back Panel x 1 pc x 2 pcs...
Page 4
PARTS LIST Center Adjustable Shelves Side Adjustable Shelves Bottom Panel x 2 pcs x 2 pcs x 1 pc Bottom Crossbar Connect Wood x 1 pc x 8 pcs Page 3 of 13...
HARDWARE LIST Allen Bolt Ø1/4"*32mmL Spring Washer Ø1/4"*1mmT Flat Washer Ø1/4"*16mmW*1mmT x 36 pcs x 36 pcs x 40 pcs Allen Key 4mm Wood Dowel Ø8*30mmL Plastic Block 30*14*8mm x 1 pc x 16 pcs x 8 pcs Hinge Hinge Screw Ø7*16mmL Screw Ø7*19mmL x 4 pcs x 24 pcs...
Page 6
STEP 1 Hardware needed With assistance, place the Bottom Panel (L) upside down on a smooth surface. Attach the Bottom Crossbar (M) to Bottom Panel (L) with Flat Washer (3), Spring Washer (2) and Allen Bolt (1) using Allen Key (4). Fully tighten all bolts.
Page 7
STEP 2 Hardware needed Place the Left Side Panel (B) upside down on a smooth surface. Align the holes in Connect Wood (N) with the holes in Left Side Panel (B) as shown. Secure Connect Wood (N) to Left Side Panel (B) with Flat Washer (3), Spring Washer (2) and Allen Bolt (1) using Allen Key (4).
Page 8
STEP 3 Hardware needed Insert Wood Dowel (5) into Bottom Panel (L). Align the holes in Right Side Panel (E) with the inserted Wood Dowels (5) and slide to place. Secure Right Side Panel (E) to Bottom Panel (L) with Flat Washer (3), Spring Washer (2) and Allen Bolt (1) using Allen Key (4).
Page 9
STEP 4 Hardware needed Open Center Back Panel (I). Insert Center Back Panel (I) down along the groove of Left Middle Panel (C) and Right Middle Panel (D). Insert Side Back Panel (H) down along the groove of Left Side Panel (B) and Left Middle Panel (C). Repeat the process for the remaining Side Back Panel (H) to attach to Right Side Panel (E) and Right Middle Panel (D).
Page 10
STEP 5 Hardware needed Attach Hinge (8) to Right Door (G) with Hinge Screw (9) using Phillips head screwdriver. Fully tighten screws. With assistance, center the Right Door (G) along the edge of Right Side Panel (E). Attach Hinge (8) to Right Side Panel (E) with Hinge Screw (9).
Page 11
STEP 6 Hardware needed Insert the Shelf Pin (12) into the pre-drilled holes as shown in the diagram. Place Adjustable Shelf (K) onto the Shelf Pins as shown. Repeat the process for the remaining Adjustable Shelf (K) and the Center Adjustable Shelves (J). You can adjust the position of shelf as needed.
Page 12
STEP 7 Hardware needed Attach the Anti-tipping Strips (13) to the back top of the mantel with Screw (15) and Flat Washer (3). With assistance, place the console in the desired location and mark the wall just below the spot where the Aniti-tipping Strips are attached to the console.
Page 13
WARNING The maximum diagonal Plasma/LCD television screen size is 52inch (132.08cm). For use with televisions weighing 135 lbs. (61.23 kg) or less. Using larger or heavier televisions may cause instability or tip-over which lead to serious injury or even death. WARNING - Death or serious injury may occur when children climb on audio and/or video equipment furniture.
Page 14
ASSEMBLY IS COMPLETED PRINTED IN VIETNAM Page 13 of 13...
