Page 1
Double-click the desktop icon or visit the Web site: http://virtualtech.answerteam.com ❖ InTouch Calling within the United States (800) 457-7777 Calling from outside the United States (949) 859-4273 For more information, see Chapter 8 on C499-1200M1 3490CT ® e-support tool ™ Center page 193. TOSHIBA...
Page 2
AFFILIATES AND SUPPLIERS DO NOT WARRANT THAT OPERATION OF THE PRODUCT WILL BE UNINTERRUPTED OR ERROR FREE. YOU AGREE THAT TOSHIBA, ITS AFFILIATES AND SUPPLIERS SHALL HAVE NO RESPONSIBILITY FOR DAMAGE TO OR LOSS OF ANY BUSINESS, PROFITS, PROGRAMS, DATA OR...
Page 3
DISCLAIM ANY AND ALL LIABILITY ARISING OUT OF THE USE OF THE COMPUTER PRODUCTS IN ANY CRITICAL APPLICATIONS. IF YOU USE THE COMPUTER PRODUCTS IN A CRITICAL APPLICATION, YOU, AND NOT TOSHIBA, ASSUME FULL RESPONSIBILITY FOR SUCH USE. Model: Portégé 3490CT FCC Notice “Declaration of Conformity...
: Only peripherals complying with the FCC Class B limits may be attached to this computer. Operation with non-compliant peripherals or peripherals not recommended by Toshiba is likely to result in interference to radio and TV reception. Shielded cables must be used between the external devices and the computer's serial port, parallel port, monitor port, external disk drive port, USB port, PS/2™...
FCC Class A Notice Note: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
FCC. In the event repairs are ever needed on your modem, they should be performed by Toshiba Corporation or an authorized representative of Toshiba Corporation. Disconnection If you should ever decide to permanently disconnect your modem from its present line, please call the telephone company and let them know of this change.
Fax Branding The Telephone Consumer Protection Act of 1991 makes it unlawful to use a computer or other electronic device to send any message via a telephone fax machine unless such message clearly contains in a margin at the top or bottom of each transmitted page or on the first page of the transmission, the date and time it is sent and an identification of the business, other entity or individual sending the message and the telephone number of the sending machine or such business,...
Page 8
The user manual of analog equipment must contain the equipment’s Ringer Equivalence Number (REN) and an explanation notice similar to the following: The Ringer Equivalence Number (REN) of this device is 0.4. NOTICE: The Ringer Equivalence Number (REN) assigned to each terminal device provides an indication of the maximum number of terminals allowed to be connected to a telephone interface.
Page 9
Copyright This guide is copyrighted by Toshiba America Information Systems, Inc. with all rights reserved. Under the copyright laws, this guide cannot be reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed, however, with respect to the use of the information contained herein.
Page 10
Toshiba America Information Systems, Inc. SelectServ, VirtualTech and Ask IRIS Online are trademarks and InTouch is a service mark of Toshiba America Information Systems, Inc. CompuServe is a registered trademark of America Online, Inc. IBM and Wake on LAN are registered trademarks and PS/2 is a trademark of IBM Corporation.
Macrovision is a registered trademark of Macrovision Corporation. All other brand and product names are trademarks or registered trademarks of their respective companies. Energy Star Compliance As an Energy Star partner, Toshiba has determined that this product is Energy ® Star compliant.
Contents Contents... 13 Introduction... 21 Chapter 1: Finding Your Way Around ... 25 Making sure you have everything... 25 Front with the display panel closed... 26 Left side... 26 Back... 27 Right side... 28 Underside... 29 Front with the display panel open... 30 Keyboard indicator panel...
Page 14
Keeping yourself comfortable... 38 Precautions... 41 Setting up your computer... 42 Installing additional memory (optional)... 43 Connecting the modem... 47 Connecting to a power source... 48 Using the computer for the first time... 50 Opening the display panel... 50 Turning on the power... 50 Using the AccuPoint II pointing device...
Page 15
Connecting to the Internet... 78 Surfing the Internet... 79 Internet features... 79 Uploading and downloading files from the Internet... 80 Toshiba’s online resources ... 80 Chapter 4: Mobile Computing... 81 Toshiba’s energy-saver design... 81 Running the computer on battery power... 82 Maximizing battery life...
Page 16
Using battery alarms... 89 Turning off the display automatically... 90 Enabling the screen saver... 90 Changing the main battery... 91 Using the optional high-capacity battery ... 93 Installing the optional high-capacity battery in the base 94 Removing the optional high-capacity battery from the base...
Page 17
Connecting a serial mouse... 111 Connecting a USB mouse (Windows 98 Second Edition)..112 Connecting a PS/2 mouse... 113 Using a PS/2 mouse and the Accupoint II simultaneously ...113 Using a printer... 114 Connecting a parallel printer... 115 Setting up your printer to work with Windows 98 Second Edition...
Page 18
...155 Using Shut down... 157 Using Hibernation (Windows 98 Second Edition)... 160 Using Standby (Windows 98 Second Edition)... 162 Chapter 7: Toshiba Utilities... 165 Fn-esse... 166 Starting Fn-esse... 166 Assigning a key to a program or document... 167 Viewing existing key assignments... 169 Changing or removing existing key assignments...
Page 19
TSETUP... 173 Using Power Management ... 174 Power Saver in Windows 98 Second Edition... 175 Power Saver in Windows NT... 176 Power Save Modes tab (Windows NT)... 177 Changing power settings... 177 Setting user passwords... 178 Using an instant password ... 179 Registering a user password...
Page 20
Using VirtualTech... 224 If you need further assistance... 226 Before you call... 226 Contacting Toshiba... 226 Other Toshiba Internet Web sites ... 227 Toshiba’s worldwide offices... 228 Appendix A: Hot Keys... 233 Appendix B: Features and Specifications... 237 Appendix C: Video Modes... 245 Appendix D: Power Cable Connectors...
Introduction Welcome to the world of mobile computing. Your new Toshiba Portégé computer combines high performance with an ultrathin, ultracompact design. It provides the perfect balance between ultramobility and performance. Your operating system is Microsoft Edition or Windows NT features and easy Internet access.
Depending on your needs, you can: ❖ Read the entire guide from beginning to end. ❖ Skim through and stop when a topic interests you. ❖ Use the table of contents and the index to find specific information. If you are new to computers or have not used a notebook computer before, read through Chapter 1, Around”...
Page 23
❖ The Microsoft Windows operating system documentation that explains the features of the Windows operating system. ❖ Information on accessories available from Toshiba and how to order them. ❖ The Recovery and Configuration Builder CD containing the programs that are preinstalled at the factory. This CD allows...
Standby command TECHNICAL NOTE: For Windows NT use Suspend/Resume mode in place of Standby command. Service options Toshiba offers a full line of service options built around its SelectServ ™ material included with your computer for registration information. If you have a problem or need to contact Toshiba, see Something Goes Wrong”...
Before you do anything else, consult the Quick Start card shipped with your unit to make sure you received everything. If any items are missing or damaged, notify your network administrator or authorized Toshiba representative immediately. For additional help, see page 226.
Finding Your Way Around Front with the display panel closed Front with the display panel closed PC Card eject levers PC Card eject levers The PC Card eject levers release PC Cards from the PC Card slots, which are on the left side of the computer. For more information, “Using PC Cards”...
Pressing the power button turns the computer on and off. For more information, see Pressing the reset button restarts the computer when it is not responding to the keyboard. This overrides the Standby command. Use this button only if all other attempts at restarting the computer failed.
Finding Your Way Around Right side Right side Headphone jack USB port Microphone jack Monitor port The 3.5 mm diameter mini monaural microphone jack lets you connect an external microphone for recording sound. The 3.5 mm diameter mini headphone jack lets you connect stereo headphones.
about the optional expansion devices see on page 101. The DC IN jack is where you plug in the AC adapter. For more information, see The modem port enables you to connect the built-in modem to a standard telephone line. Underside Expansion memory slot...
Finding Your Way Around Front with the display panel open The optional high-capacity battery connector enables you to connect the optional high-capacity battery pack, which extends the time you can run the computer on battery power up to a total of 8 hours.
Finding Your Way Around Front with the display panel open The keyboard indicator panel is located above the keyboard. For more information, see “Keyboard indicator panel” on page The built-in monaural microphone lets you record sounds. For more information about the Portégé’s audio capabilities, see “Using audio features”...
Finding Your Way Around Front with the display panel open The numeric mode light glows when the numeric overlay is on. When this light is on, pressing an overlay key types the number printed on the key instead of typing the letter printed on the key. System indicator panel AC power On/off...
❖ Flashing amber, in two-second intervals, means the power is off and the computer is in Standby mode. For more information about Standby mode, see (Windows 98 Second Edition)” on page The main battery light indicates the status of the computer’s main battery.
Finding Your Way Around LAN Port Replicator ports can recharge the main battery while the computer is running or while it is off. TECHNICAL NOTE: The main battery doesn’t charge while the computer is consuming full power. For more information on your computer’s power management, see Management”...
Finding Your Way Around External USB diskette drive Use the parallel port to connect a parallel printer or other parallel device. Use the monitor port to connect an external monitor. For more information, see “Using an external monitor” on page 120.
Finding Your Way Around PC Card spacekeepers Connect the external USB diskette drive to the USB port on the right side of the computer. Alternatively, you can connect it to the USB port on the LAN Port Replicator, on the optional Multimedia Port Replicator, or on the optional I/O Adapter.
Chapter 2 Getting Started This chapter provides tips for working comfortably, summarizes how to connect components, and explains what to do the first time you use your notebook computer. Selecting a place to work Your computer is portable and designed to be used in a variety of circumstances and location Creating a computer-friendly environment Place the computer on a flat surface that is large enough for the...
AC power source, and let it dry out completely before turning it on again. If the computer does not operate correctly after you turn it back on, contact your Toshiba service representative or your network administrator. ❖...
Placement of the computer Proper placement of the computer and external devices is important to avoid stress-related injuries: ❖ Place the computer on a flat surface at a comfortable height and distance. You should be able to type without twisting your torso or neck, and look at the screen without slouching.
Page 40
Getting Started Selecting a place to work comfortably with your shoulders relaxed and your forearms parallel to the floor. If you are using a conventional chair: ❖ Your knees should be slightly higher than your hips. If necessary, use a footrest to raise the level of your knees and ease the pressure on the back of your thighs.
Work habits The key to avoiding discomfort or injury from strain is to vary your activities. If possible, schedule a variety of tasks into your working day. Finding ways to break up the routine can reduce stress and improve your efficiency. ❖...
Getting Started Setting up your computer Information on diskettes is stored magnetically. Getting a magnet too close to a diskette can erase important files. ❖ Scan all new files for viruses. This precaution is especially important for files you receive via diskette or email, or download from the Internet.
To use CD-ROMs, you must either: ❖ Connect the computer to the optional Multimedia Port Replicator and fit a CD-ROM drive or DVD-ROM drive in the SelectBay ❖ Install a PC Card CD-ROM drive in the computer’s PC Card slot, see To use DVDs, connect the computer to the optional Multimedia Port Replicator and fit a DVD-ROM drive in the SelectBay.
Getting Started Setting up your computer Installing a memory module The memory module fits into the expansion memory slot on the underside of the computer. You need a standard Phillips No. 1 screwdriver to install a memory module If you are adding memory after you have started using the computer, shut down the operating system, close the display panel and remove any cables.
Page 45
Removing the memory slot cover screws Using a standard Phillips No.1 screwdriver, remove the screws securing the memory slot cover, then remove the memory slot cover. NOTE: To avoid damaging the computer’s screws, use a standard Phillips no. 1 screwdriver that is in good condition. Put the screws in a safe place so that you can retrieve them later.
Page 46
Getting Started Setting up your computer NOTE: Static electricity can damage the memory module. Before you handle the module, touch a grounded metal surface to discharge any static electricity you may have built To avoid damaging the memory module, be careful not to touch its pin connector (on the side you insert into the computer).
cover and make sure the memory module is seated properly, as described in step 5. Connecting the modem Your computer comes with a built-in V.90 56K modem Locate the modem port on the right side of your computer. Plug one end of the telephone cable (provided) into the port. Connecting the internal modem Connect the other end of the telephone cable to the jack of a standard voice-grade telephone line.
Getting Started Setting up your computer Connecting to a power source Your computer requires power to operate. Use the power cable and AC adapter to connect the computer to a live power outlet, or use the main battery and the optional high-capacity battery. Connecting to an AC outlet The AC adapter enables you to power the computer from a wall outlet and to charge the computer’s main battery.
Connecting the AC adapter cable to the computer Insert the plug end of the power cable into a live wall outlet. The AC power light on the indicator panel glows green. If the main battery is present, the main battery light glows: ❖...
Getting Started Using the computer for the first time Using the computer for the first time For information on connecting devices, see computer” on page Opening the display panel Slide the display panel latch to the right and lift the display panel Opening the display panel CAUTION: To avoid damaging the display panel, don’t force it beyond the point where it moves easily.
Page 51
Releasing the power button lock and turning on the power Locate the power button to the right of the power button lock. Turn on the computer by pressing the button for at least one second. The on/off light on the system indicator panel glows green, indicating that the computer is on.
Getting Started Using the computer for the first time The hard disk drive light flashes to indicate that the hard disk drive is currently in use. CAUTION: Never turn off the computer while any of the drives is in use. Using the AccuPoint II pointing device The button in the middle of the keyboard is the Accupoint II pointing device.
Completing installation—Enables you to enter details to authenticate and personalize your copy of Windows 98 Second Edition. ❖ Registration—Allows you to register your Toshiba computer online, send your Windows 98 Second Edition registration Using the computer for the first time Getting Started...
Getting Started Using the computer for the first time information to Microsoft, and upgrade or extend your Toshiba warranty. NOTE: Windows NT does not support online registration. To register your computer, complete and mail the registration card provided by Toshiba.
Page 55
Using the computer for the first time Read the license agreement, click the button labeled I accept the agreement , then click Next . Click Finish . Setup displays the Date/Time Properties box. Setting your time zone, date, and time The Date/Time Properties dialog box has two tabs.
Registering your computer lets Toshiba keep you up-to-date with information about new products and upgrades and also extends your Toshiba warranty worldwide at no charge to you. See the registration card and warranty information for details about the warranty options available from Toshiba.
90. There are additional custom settings you can choose. “Toshiba Utilities” on page Turning off the computer It’s a good idea to turn off your computer when you are not using it for a while.
Getting Started Turning off the computer ❖ To avoid accidentally turning on the computer, slide the power button lock left to the locked position. Closing the display When you are finished, shut the computer down and close the display panel to keep dust and dirt out of the computer. If you close the computer while it is still on, one of these actions will occur: ❖...
To keep your computer clean, gently wipe the display panel and exterior case with a lightly dampened cloth. Ask your Toshiba sales representative or your network administrator for suggestions for appropriate cleaning products.
Getting Started Caring for your computer Using a computer lock You may want to secure your computer to a heavy object such as your desk. The easiest way to do this is to purchase an optional PORT-Noteworthy PORT-Noteworthy computer lock cable To secure the computer: Loop the cable through or around some part of a heavy object.
Chapter 3 Learning the Basics This chapter lists computing tips and provides important information about the system’s basic features. Computing tips ❖ Save your work frequently. Your work stays in the computer’s temporary memory until you save it to disk. If the network you are using goes down and you must restart your computer to reconnect, or your battery runs out of charge while you are working, you will lose all the work since you last saved.
Learning the Basics Using the keyboard ❖ Use ScanDisk and Disk Defragmenter regularly to conserve disk space and improve performance. Consult your Windows documentation for instructions. ❖ Always turn off your computer using the Shut Down or Standby command in Windows 98 Second Edition, or using the Shut Down or the Suspend command in Windows NT.
Ctrl, Fn and Alt keys Ctrl Ctrl, Fn and Alt keys The Ctrl, Fn and Alt keys do different things depending on the program you are using. For more information, see your program documentation. Character keys Typing with the character keys is very much like typing on a typewriter, except that: ❖...
Learning the Basics Using the keyboard Hot keys When used in combination with the Fn key, function keys marked with icons run programmed functions specific to your computer. For more information, see Windows special keys Windows special keys The keyboard provides two keys that have special functions: ❖...
The keys with numbers and symbols on them form the numeric and cursor overlay. This overlay lets you enter numeric data or control the cursor as you would using the ten-key keypad on a full- size keyboard. Using the numeric keyboard overlay To turn the numeric overlay on and off, press simultaneously.
Learning the Basics Starting a program Once the cursor control overlay is on: Type lowercase letters Type uppercase letters Use the numeric keys To turn off the cursor control overlay, hold down the press again. The cursor control mode light on the keyboard indicator panel goes out.
Starting a program from the Start/Programs menu When you install a program, Windows usually puts an icon in the Programs menu. To start a program that has an icon in the Programs menu, follow these steps, which use the Windows Wordpad program as an example: Click Start , then point to Programs .
Learning the Basics Starting a program Windows Explorer shows the contents of the Program Files folder on the right side of the window. The left side of the window shows all the folders contained within the Program Files folder. In the left part of the window, click Accessories . Using Windows 98 Second Edition, Windows Explorer shows the contents of the Accessories folder on the right side of the window.
Sample entering a program name and path ❖ If you don’t know the program’s location, click Browse..In the Browse dialog box, enter the file name (for example wordpad ) and select the drive to search. When Windows has found the file, click Open . HINT: To run the same program again, click the arrow to the right of the text box and select the command line from the drop-down list.
Learning the Basics Saving your work Many programs offer a feature that saves documents at regular intervals, such as every 15 minutes. Check your program’s documentation to see whether it has an automatic save feature. Saving files On the File menu of your Windows program, click Save . If you are working with a document that already has a file name, that’s all there is to it.
Printing your work Before you can print your work: ❖ Connect the printer to the computer. See on page 114 ❖ If you have not already done so, set up Windows 98 Second Edition or Windows NT to work with the printer. HINT: You only need to set up the printer the first time you connect it.
Learning the Basics Using diskettes Click OK to print. Using diskettes To use diskettes, you must connect the external USB diskette drive to the USB port on the right side of the computer, or to the LAN Port Replicator or optional Multimedia Port Replicator. See “Using the external USB diskette drive”...
Windows displays the contents of the drive. Double-click the folder that contains the file, then click the file you want to copy. HINT: Use the On the menu bar, click File , then click Send To . Click the icon for 3 ½ Floppy (A:). Windows copies the file(s).
Your computer comes with a Recovery and Configuration Builder CD that enables you to reinstall software that was preinstalled. This CD can be used to install or reinstall particular Toshiba applications, utilities, and drivers. You should always back up your files in case something happens to your computer. If you have a network partition at the office, you can hold copies of your files there.
TECHNICAL NOTE: When restoring files, the backup program prompts you if you try to overwrite a file that already exists on the hard disk. Make sure the backup version is the one you want before overwriting the existing file. Setting up for communications To connect to the Internet, use an online service, or communicate across the telephone lines with another computer, you need: ❖...
Learning the Basics Setting up for communications To set up the connection, use the Dial-Up Networking Wizard: Click Start and point to Programs . Using Windows 98 Second Edition, point to Accessories , then to Communications , and click Dial-Up Networking . Using Windows NT, point to Accessories , and click Dial-Up Networking .
You don’t really need to know anything about specific protocols— just make sure you are using the same protocols as the computer with which you are communicating. If you would like to know more, protocols are described in any book on telecommunications, available at your local book or computer store.
Learning the Basics An overview of using the Internet programs called Web browsers are specifically designed to work with HTTP. They make it easier to connect to a particular network address and send and receive information. Internet Service Providers To connect a computer directly to the Internet, many people and businesses use an Internet Service Provider (ISP).
Start your Web browser. Have your modem dial the ISP’s telephone number, and establish a connection with the ISP’s computer. Toshiba and Yahoo! have joined together to offer you a free account on Yahoo!. In order to sign up for Yahoo!, you must have an Internet access account.
File Transfer Protocol (FTP) features of your Web browser to transfer large amounts of data. Toshiba’s online resources Toshiba maintains a number of online sites to which you can connect. These sites provide information about Toshiba products, give help with technical questions and keep you up to date with future upgrades.
It has a number of other features that enhance its energy efficiency. Many of these energy-saving features have been set by Toshiba. We recommend you leave these features active, allowing your computer to operate at its maximum energy efficiency, so that you...
Mobile Computing Running the computer on battery power Running the computer on battery power Your computer contains a removable, rechargeable lithium ion (Li-ion) 3,000 mAh main battery that provides power when you are away from an AC outlet. You can recharge the main battery many times.
If a battery is leaking or damaged, replace it immediately. Use protective gloves when handling a damaged battery. ❖ When replacing the main battery, use an identical battery that you can purchase from Toshiba. See the accessories information provided with your computer or visit www.toshibaaccessories.com. Charging batteries The main battery and optional high-capacity battery need to be charged before you can use them to power the computer.
Mobile Computing Charging batteries Charging the main battery To charge the main battery while it is in your computer, use the AC adapter to connect the computer to a live wall outlet. With the computer off, recharging the main battery takes up to three hours. The main battery takes much longer to charge when the computer is on.
Doing so may reduce the potential charge of the battery. Use only battery chargers designed to work with your computer and its batteries. You can order a Toshiba battery charger through the accessories information sheet or Toshiba’s Web site at www.toshibaaccessories.com.
Mobile Computing Monitoring main battery power Monitoring main battery power The computer’s main battery light gives you an indication of the main battery’s current charge: ❖ No illumination means the main battery is not in use and the AC Adapter is not connected. ❖...
TECHNICAL NOTE: The computer drains battery power more quickly at low temperatures. Check your remaining charge frequently if you’re working in temperatures below 50 degrees Fahrenheit. The computer calculates the remaining battery charge based on your current rate of power use and other factors such as the age of the main battery.
Where you are working—since operating time decreases at low temperatures. Toshiba’s power-saving options greatly increase the length of time you can use the computer before having to recharge the main battery. Toshiba has combined these options into three preset power usage modes: ❖ Long Life ❖...
Using a hot key to select the power usage mode Press pop-up window. While continuing to press desired power usage mode. Release the You’re now in the selected mode. Using battery alarms You can configure the computer to warn you when the main battery is running low.
Mobile Computing Turning off the display automatically Before your computer runs out of battery power, save your data and: ❖ Suspend or shut down your computer. ❖ Shut down your computer and replace the main battery with a charged one as outlined in ❖...
Screen Saver tab of the Display Properties dialog box In the section labeled Screen Saver , select Blank Screen . In the Wait window, click the up and down buttons to set the number of minutes before the display turns off automatically. Click OK to save your changes and exit the Display Properties dialog box.
Page 92
Mobile Computing Changing the main battery Windows shuts down the computer. Close the display panel. Turn the computer over. Slide the main battery safety latch towards the outside edge of the computer. Releasing the main battery Grasp the main battery in the center and pull it gently away from the computer.
Using the optional high-capacity battery Inserting the main battery Push gently until you hear a click, indicating that the main battery is connected. If the main battery does not have a full charge, connect the computer to an external power source using the AC Adapter. Using the optional high-capacity battery The optional high-capacity lithium ion battery fits beneath the computer.
Mobile Computing Using the optional high-capacity battery Installing the optional high-capacity battery in the base Hold the battery at an angle with the label facing down and fit the connector side into the base. CAUTION: The optional high-capacity battery is designed so that it cannot be installed in reverse polarity.
Using the optional high-capacity battery Installing the optional high-capacity battery Removing the optional high-capacity battery from the base If the computer is connected to the base, remove it. See “Disconnecting the computer from the optional high- capacity battery base” on page Slide the battery lock on the right side of the optional high- capacity battery base to the unlocked position.
Page 96
Mobile Computing Using the optional high-capacity battery Opening the optional high-capacity battery connector cover Lay the base with the optional high-capacity battery installed face up. Optional high-capacity battery in the base Open the connector cover on the optional high-capacity battery. Opening the connector cover on the optional high-capacity battery...
Page 97
Using the optional high-capacity battery Insert the front corners of the computer into the front of the optional high-capacity battery base at an angle. Make sure the front of the computer fits securely inside the front corners of the base. Front of the computer aligned with the front of the battery base Lower the back of the computer into the battery base.
Mobile Computing Using the optional high-capacity battery Press the button on the left side of the base to enable the battery. This button is toward the front of the base next to the release latch. NOTE: The battery will not work until you press this button. Disconnecting the computer from the optional high-capacity battery base Push the release latch in the direction of the arrow.
Dispose of the battery as required by local ordinances or regulations. Use only batteries recommended by Toshiba. The materials that came with your computer may include an insert regarding the disposal of batteries. If not, check with your local government for information on where to recycle or dispose of old batteries.
❖ Always travel with the computer in a carrying case. Toshiba offers a choice of carrying cases for the computer. They all provide plenty of extra space for manuals, power cables, CD- ROMs or DVD-ROMs, and diskettes.
Chapter 5 Expansion Options Your computer is designed to work in your office as well as on the road. This chapter explains how to set up the various external devices so that your notebook can provide all the convenience of a traditional desktop computer.
Expansion Options Using the LAN Port Replicator Card slot, and a SelectBay in which you can fit a CD-ROM or DVD-ROM drive or a second hard disk drive. If you want a smaller expansion unit which will enable you to connect the computer to a printer, an external monitor, mouse and full-size keyboard when you visit another location, use the optional I/O Adapter.
For details of the ports, see page On/Off switch LAN Port Replicator Attaching the LAN Port Replicator Make sure the computer is off. Expansion port — cover open Locate the expansion port on the right side of the computer and open the port cover. Align the LAN Port Replicator’s cable connector with the port, squeeze the latches on the connector, and gently insert the connector into the port.
Expansion Options Using the optional Multimedia Port Replicator When the connector is fully seated, it clicks into place. Don’t force the bar into position. Connect the peripherals to the LAN Port Replicator. For more information, see: on page external monitor” on page Turn on the network function by sliding the on/off switch, located on the end of the LAN Port Replicator.
Use the parallel port to connect a parallel printer or other parallel device. Use the serial port to connect a serial mouse, serial printer or other serial device. The Line out jack allows you to send stereo sound from the computer’s sound system to an external audio device.
Expansion Options Using the external USB diskette drive I/O Adapter ports Use the serial port to connect a serial mouse, serial printer or other serial device. Use the parallel port to connect a parallel printer or other parallel device. Use the monitor port to connect an external monitor. For more information, see Use the Universal Serial Bus (USB) port to connect the external USB diskette drive or other USB peripherals.
Page 107
Using the external USB diskette drive Diskette-in-use light External USB diskette drive and connector cable TECHNICAL NOTE: You may attach the external USB diskette drive while the computer is on or off. If you attempt to use the drive when it is not attached to the computer, you will receive an error message.
Page 108
TECHNICAL NOTE: The default setting for USB-FDD Legacy Emulation is Disabled. Click Start . Select Settings , then Control Panel . Double-click the Toshiba Hardware Setup icon. Select the USB tab and click Enabled under USB-FDD Legacy Emulation. Click OK .
Using the arrow keys, move to the USB-FDD Legacy Emulation option in the Peripheral section and press the space bar to select Enabled . Press the Press to save the change. Your system will automatically restart. NOTE: Enabling Legacy Emulation may interfere with other USB devices while running Windows.
Expansion Options Using an external keyboard Connecting a PS/2 keyboard These instructions assume you are connecting the keyboard to the LAN Port Replicator that came with your system. Turn off the computer. NOTE: Make sure the computer is off before you attach the keyboard.
An external keyboard does not have the computer’s built-in keyboard. You can use the option in Toshiba Hardware Setup to set up an external keyboard key combination that will emulate the internal keyboard’s In Toshiba Hardware Setup, you can emulate the assigning key combinations in the keyboard option of the utility.
Expansion Options Using a mouse Locating the serial port on the LAN Port Replicator Turn on the computer. Windows automatically detects the mouse. Connecting a USB mouse (Windows 98 Second Edition) You can connect a USB mouse to the USB port on the right side of the computer while the computer is on.
Using a PS/2 mouse and the Accupoint II simultaneously With a PS/2 mouse, you can choose to have the AccuPoint II active at the same time. You set this option in Toshiba Hardware Setup: Click Start , point to Settings , and click Control Panel .
Expansion Options Using a printer ❖ Auto-selected This configures the PS/2 mouse to work when it is connected at power on, or the AccuPoint II pointing device to work otherwise. It is the default option. ❖ Simultaneous This configures both the AccuPoint II pointing device and the PS/2 mouse to work at the same time.
Plug the printer’s power cable into a live AC outlet. If your printer is ECP-compliant, set the computer’s parallel port to use ECP capabilities in the Toshiba Hardware Setup utility. See “Hardware Setup” on page 171 Setting up your printer to work with Windows 98 Second Edition Setting up a printer involves selecting a printer driver.
Page 116
Expansion Options Using a printer the printer can understand. This section describes how to select a printer driver in Windows 98 Second Edition. If you are using any non-Windows programs, you’ll need to set up a printer driver for each of those programs. Refer to your program’s documentation for more information.
Page 117
Add Printer Wizard Click Next . The Add Printer Wizard asks you to select your printer. HINT: If your printer is plug and play, Windows 98 Second Edition recognizes it automatically. You may skip the remainder of this section. See your printer manual. If the printer you are setting up: ❖...
Expansion Options Using a printer The Add Printer Wizard asks you to enter a “friendly” printer name. Enter a name for your printer, then click Next . If you are using more than one printer, make sure the name is descriptive enough to help you tell the difference.
Page 119
Printers window Double-click Add Printer . The Add Printer Wizard starts and prompts you to specify how the printer is to be managed. Add Printer Wizard dialog box Select one of the following printer management options: ❖ My Computer —All settings are managed and configured on this computer.
Expansion Options Using an external monitor ❖ Network printer server —Connects to a printer on another machine. All settings for this printer are managed by a print server that has been set by the network administrator. NOTE: The Add Printer Wizard leads you through the printer setup and configuration process.
Page 121
Turn off the computer. NOTE: Make sure the computer is off before you attach the monitor. Connecting a monitor with the computer’s power on may damage the monitor, the computer, or both. Attach the LAN Port Replicator to the computer. “Attaching the LAN Port Replicator”...
Expansion Options Using PC Cards To send information to both the built-in display panel and the external monitor, change the Power On Display option. To do this using the hot key: Press While holding down desired setting. This hot key cycles through the settings in the following order: built-in display only, external monitor only, and simultaneous display.
Most PC Cards conform to the PCMCIA (Personal Computer Memory Card International Association) standard. TECHNICAL NOTE: For PCMCIA-compatible PC Cards, check the package to make sure they conform to the PCMCIA 2.1 standard (or later). Other cards may work with your computer, but they are likely to be much more difficult to set up and use.
Expansion Options Using PC Cards Locate the appropriate PC Card release button on the front of the computer. ❖ The button on the left releases the upper PC Card spacekeeper. ❖ The button on the right releases the lower PC Card spacekeeper.
Locate the appropriate PC Card release button on the front of the computer. Slide the release button to the right. The PC Card pops out about an inch. Removing the PC Card from the slot Grasp the edges of the PC Card and carefully slide it out of the slot.
Expansion Options Playing a CD or DVD using Windows 98 Second Edition Hot swapping precautions Although you can insert a PC Card at any time, remember not to remove a card while it is in use. Otherwise, you could lose valuable information.
Playing a CD or DVD using Windows 98 Second Edition If you have installed a PC Card CD-ROM drive, or fitted a CD- ROM or DVD-ROM drive in the SelectBay of the optional Multimedia Port Replicator, you can play CD-ROMs, audio CDs and DVD-ROMs.
Expansion Options Playing a CD or DVD using Windows 98 Second Edition Inserting a disc WARNING: Before playing an audio CD, turn the volume down. Playing the compact disc at maximum volume could damage your ears. To turn the volume down, use the Volume Control program (click Start, Programs, Accessories, Entertainment, Volume Control).
Playing a CD or DVD using Windows 98 Second Edition Spindle Disc Positioning the disc on the spindle CAUTION: Make sure the disc is properly positioned on the spindle. If you position the disc incorrectly, it can jam the disc tray. Close the disc tray by pressing gently on the center of the tray until it clicks—indicating that it is locked.
Expansion Options Playing a CD or DVD using Windows 98 Second Edition Sample CD Player screen The CD Player control panel works much like an ordinary compact disc player: ❖ To stop the compact disc, click the Stop button. ❖ To eject a compact disc, click the Eject button on the CD Player control panel or press the eject button on the CD- ROM/DVD-ROM drive.
Playing a CD or DVD using Windows 98 Second Edition If you click the icon without having the compact disc in the drive, Windows prompts you to insert the disc. Removing a disc CAUTION: Never press the eject button while the computer is accessing the drive.
Expansion Options Playing a CD or DVD using Windows 98 Second Edition Caring for CDs and DVDs ❖ Store your discs in their original containers to protect them from scratches and keep them clean. ❖ Never bend a disc or place heavy objects on top of it. ❖...
Chapter 6 Enhancing Productivity In this chapter, you will explore some of the additional features of your computer. Personalizing your desktop Your desktop is your virtual workspace. This section explains how to customize its features for the way you like to work. You can customize these aspects of the desktop: ❖...
Enhancing Productivity Personalizing your desktop Customizing the taskbar As you work, the taskbar changes to reflect what you are doing. Its icons provide shortcuts to programs, documents, files, folders, system features, and components. Open applications also have Forward and Backward buttons to allow navigation through folders, documents, and Web sites.
Turning on the Active Desktop (Windows 98 Second Edition) The first step to bring active content to your desktop is to turn on the Active Desktop: Place the cursor in an empty space on the desktop and click the secondary button. Point to Active Desktop , then click View as Web Page .
Page 136
Enhancing Productivity Personalizing your desktop You can choose from three different styles: ❖ Web style In this style, you can browse the desktop and folders like you browse Web pages, by single-clicking items. Files, folders, and applications open in a single window, instead of in separate windows.
Page 137
You can display Web pages or any HTML page, as background in a window. In Web style, any folder with HTML content that is displayed as a Web page can include artwork, Microsoft Office documents, multimedia, interactive forms, and so on. Some windows—such as My Computer and Control Panel—come with a background that displays a description of each feature when you point to its icon.
Page 138
Enhancing Productivity Personalizing your desktop Sample Web-style option Click the style you want to use, Web style , Classic style, or Custom, based on settings you choose , then click OK . Choosing custom settings If you chose Custom: Click Settings .
The Custom Settings dialog box appears. Sample Custom-style options Select the options you want, then click OK . Personalizing individual windows Just as you can display a Web page on your desktop, you can also display a Web page in an individual window. If you subscribe to the Web page, it can be automatically updated on a regular basis.
Enhancing Productivity Personalizing individual windows To add a background to a window: Double-click My Computer . The system opens the My Computer window. Open the folder you want to customize. On the View menu, click Customize this Folder , and then follow the instructions in the Customize this Folder wizard.
Page 141
Personalizing individual windows The elements you can add to the top of the window are: Toolbar element Description Address Bar Opens Web pages, programs, folders, or documents. By default, the address bar shows your current location, and whether it is a folder or a Web page. You can browse to another location by typing an address—a URL, a path, or even a program name.
Enhancing Productivity Personalizing individual windows Displaying information about each folder (Windows 98 Second Edition) In addition to displaying the contents of each window, you might find it helpful to have Windows 98 Second Edition display the name of the folder and brief information about how to use the folder.
Staying up-to-date with your favorite Web sites Staying up-to-date with your favorite Web sites If you frequently visit certain Web sites looking for new content, Windows can automatically deliver the new content to your computer. This feature is called a “subscription.” Web site subscriptions work much like magazine subscriptions—...
Page 144
Enhancing Productivity Staying up-to-date with your favorite Web sites To subscribe to a Web site: In the My Computer window, go to the Web page to which you want to subscribe. On the Favorites menu, click Add to Favorites . The Add Favorite dialog box appears.
Emulating a full-size keyboard Although your computer’s keyboard is compatible with a full-size 101/102-key enhanced keyboard, it has fewer keys. Pressing the several keys allows you to emulate a full-size keyboard. The keys are: Alt, Ctrl, cursor control mode, and numeric control mode. See “Using the keyboard”...
Page 146
Enhancing Productivity Setting up for communications Windows 98 Second Edition opens the Control Panel. Double-click Modems . Windows 98 Second Edition displays the Modem Properties dialog box. Click the Diagnostics tab. Your modem should be listed next to one of the computer’s COM ports.
Double-click Modems . The Modem Properties dialog box appears. Your modem should be listed next to one of the computer’s COM ports. Make a note of the COM port to the modem is connected to. TECHNICAL NOTE: Windows NT communicates with the modem and displays identifying information reported by the modem.
Use an external CD-ROM drive. You can order a PORT-Noteworthy PC Card CD-ROM drive from Toshiba and install it using the PC Card slot on the left side of the computer. Alternatively, if you have a PC Card SCSI adapter, you can use a SCSI CD-ROM drive.
Page 149
Transferring files to another computer Using a direct cable connection To transfer the files between the two computers: Close Windows 98 Second Edition and turn off the power on both computers. Connect the LAN Port Replicator or other expansion device to your notebook computer.
Windows 98 Second Edition operating system, except for the system speaker, which is configured by the Toshiba System utility. To adjust the volume, click the speaker icon in the taskbar, or use the volume control dial on the front of the computer.
Recording sounds The built-in microphone may be used with other software to record monaural audio sounds and save them as digital audio .WAV files on disk. You may also record sounds as .WAV files by connecting an external microphone or other sound source to the microphone jack.
Enhancing Productivity Using audio features The Sound Recorder window displays the new sound file as a waveform. To hear what you just recorded, click the Play button. To save the file, select Save from the File menu. Adjusting recording quality The better the quality of the recording, the more disk space the sound file requires.
Powering down the computer When you power down the computer, you have three options to choose from: Shut down, Hibernation, and Standby. Each method has its advantages. Shut down command The Shut down command shuts the computer down completely. When you start up again, the computer runs a self-test and loads the operating system.
Enhancing Productivity Powering down the computer runs a self-test, loads the operating system, and then returns to the status in which you left it. Factors to consider when choosing Hibernation: ❖ While in Hibernation mode, the computer uses no battery power.
Using Suspend/Resume (memory) mode (Windows NT) Suspend/Resume (memory) mode is a Toshiba utility that maintains the operating state of your computer in memory while the computer is off enabled, whenever you turn on the computer you’ll be able to...
Page 156
Enhancing Productivity Powering down the computer ❖ Press and hold the When the pop-up window appears, press and release the Suspend/Resume (memory) mode icon is highlighted, then release the ❖ Open the Power Saver utility in Control panel, click select Battery Power , click Details , then click the System tab.
Enhancing Productivity Powering down the computer Using Shut down If you are using Windows 98 Second Edition, click Start , Shut Down , select Shut down from the drop-down menu, then click OK . Shut Down Windows dialog box (Windows 98 Second Edition) The computer shuts down completely.
Open the Start menu, point to Settings , then click Control Panel. If the Toshiba Power Saver icon is not present: click View all control panel options on the left side of the panel. In the Control Panel window, double-click the Power Saver icon.
Page 159
Select Shutdown for the options you want. ❖ When I press the power button Setting this option to Shutdown configures the computer to shut down when you press the power button. ❖ When I close the lid Setting this option to Shutdown configures the computer to shut down when you close the display panel.
Enhancing Productivity Powering down the computer Using Hibernation (Windows 98 Second Edition) NOTE: Windows NT does not support Hibernation mode. Suspend/Resume mode is to be used in place of Standby command. To power down the computer using the Hibernation option: Open the Start menu.
Panel. In the Control Panel window, double-click the Power Saver icon. If the Toshiba Power Saver icon is not present: click View all control panel options on the left side of the panel. In the Running on batteries area, click the Details button, then select the System Power Mode tab.
Enhancing Productivity Powering down the computer Click OK again, then close the Control Panel. NOTE: For more information about the Power Saver utility, “Using Power Management” on page Starting again from Hibernation mode To start up the computer from Hibernation mode, press the power button until the on/off light turns green.
Page 163
Panel. In the Control Panel window, double-click the Power Saver icon. If the Toshiba Power Saver icon is not present: click View all control panel options on the left side of the panel. In the Running on batteries area, click the Details button, then select the System Power Mode tab.
Page 164
Enhancing Productivity Powering down the computer ❖ Click All for the settings to apply whether you are using battery power or outlet power. Click OK . Click OK again, then close the Control Panel. NOTE: For more information about the Power Saver utility, “Using Power Management”...
TSETUP ❖ Power Saver ❖ The Power Management Properties dialog which Toshiba has added to the Power Management utility in Windows 98 Second Edition. This chapter also explains how to set and use passwords to protect your system and data.
233. You can assign any key that is not associated with a hot key or a keyboard overlay. Starting Fn-esse Click Start , point to Programs , Toshiba Utilities , then click Fn-esse . The Fn-esse keyboard appears. Fn-esse window key combination to: “Hot Keys”...
Explorer to the key on the Fn-esse keyboard to which you want to assign it. Release the primary button. Fn-esse displays the Add/Edit Command dialog box with the Description, Command Line and Working Directory fields automatically completed. Toshiba Utilities Fn-esse...
Page 168
Toshiba Utilities Fn-esse Click OK to close the Add/Edit Command dialog box with your key assignment in place. The program or document is now associated with the key you just selected. To open the program or document, press the appropriate key from within any Windows program.
Fn-esse displays the Assignment Type dialog box. To change the key assignment, click Direct or Popup and continue as if you were creating a new assignment. To remove the key assignment, click Clear . plus the appropriate key from within any Toshiba Utilities Fn-esse...
Toshiba Services The Toshiba Services utility allows you to enable or disable hot keys. Toshiba has defined a number of hot keys that make it easy to change your shutdown mode or power settings. To enable or disable hot key services: Open the Start menu, point to Settings , then click Control Panel.
Windows. Hardware Setup in Windows To access Hardware Setup in Windows 98 Second Edition, go to Start , Settings , Control Panel . Double-click the Toshiba Hardware Setup icon. The HW Setup dialog box appears. Sample HW Setup...
Page 172
Toshiba Utilities Hardware Setup Hardware Setup has the following tabs: ❖ General — Shows the BIOS version, memory configuration, and Hard Disk Drive (HDD) mode. ❖ Password — Allows you to set the user password and an owner string. ❖...
Apply , you can reconfigure that function. Any options that you change will become default settings when you restart your system. TSETUP TSETUP is much like Toshiba Hardware Setup, but it is MS-DOS-based. To access TSETUP during system boot: Turn off the computer.
Microsoft Power Manager to set the Hibernation option only. For other Windows 98 Second Edition and Windows NT power-saving options, use the Toshiba Power Saver utility. TECHNICAL NOTE: For Windows 98 Second Edition, Toshiba recommends that you always have the Hibernation option enabled.
Power Saver in Windows 98 Second Edition Power Saver in Windows 98 Second Edition Toshiba Power Saver enhances your computer’s power management capabilities. Power Save Modes is a series of settings for power management. You can change which mode your...
The preset modes cannot be deleted. Power Saver in Windows NT Toshiba Power Saver enhances your computer’s power management capabilities. Power Save Modes is a series of settings for power management. You can change which mode your...
You can choose a power usage mode for either battery or AC power from the preset modes or you can create a customized mode. However, Toshiba recommends that you retain the Full Power Mode setting for AC power. Power Save Modes tab (Windows NT) There are five Power Save modes from which to choose.
Setting a password lets you leave your computer, secure in the knowledge that nobody can access your files. You must enter the password before you can work on your computer again. Toshiba supports these types of passwords on your computer: ❖ An instant password secures your open programs and files when you leave the computer temporarily.
❖ A supervisor password prohibits unauthorized users from accessing certain functions such as Toshiba Hardware Setup. This is useful if more than one person uses the computer. A single user password supports the instant and power-on password functions.
Click Exit . To delete a user-level password in Windows NT: Click Start , point to Programs , and then point to Toshiba Utilities . Click Hardware Setup , click the Hardware Options button, then select the Password tab.
YOU WILL NEVER BE ABLE TO ACCESS YOUR HARD DISK AGAIN. Toshiba is not responsible for any data loss, lack of use, inability to access the hard disk drive, or any other loss to you or any other person or organization that results from an inaccessible hard disk drive.
Page 182
Toshiba Utilities Setting user passwords Windows NT: The right side of the Explorer window displays the HDD Password program file: hddpwdNT.exe . If you are using Windows 98 Second Edition, double-click the hddpwd32.exe file. If you are using Windows NT, double-click the hddpwdNT.exe file.
Page 183
Password utility prompts you to enter the next password. Repeat steps 11 through 14 for each drive that requires a new password. After you complete all these steps, the HDD Password utility prompts you to create a password backup diskette. Toshiba Utilities Setting user passwords ”.
A warning dialog box appears. Click OK to continue deleting a registered password. The Toshiba HDD Password Utility dialog box appears. The hard disk drives with a registered password display “Registered” under the User columns. HINT: Clicking Cancel allows you to exit the utility.
Page 185
After all the selected drives have been processed, the Delete User Password dialog box appears. HINT: Clicking No cancels the deletion process. Click OK . The Toshiba HDD Password Utility dialog box displays the drives with deleted passwords as “Deleted (Pending)” in the status column. Toshiba Utilities Setting user passwords ”.
Toshiba Utilities Using a supervisor password Click Exit . A dialog box appears prompting you to shut down the computer. TECHNICAL NOTE: If you try to change the password before restarting the computer, the password that was in place the last time the computer was started will be the effective password.
To set a supervisor-level password in Windows NT: Click Start , then click Shut Down . The Shut Down Windows dialog box appears. Using a supervisor password simultaneously to return to Windows 98 Alt, Toshiba Utilities Enter “Using the 106.
Page 188
Windows NT shuts down and the computer turns itself off. Connect your diskette drive. For instructions, see external USB diskette drive” on page Insert the Toshiba Companion Diskette into the diskette drive and turn on the computer. After a few minutes, a Welcome screen appears.
If the password is correct, this message appears: SUPERVISOR PASSWORD = Not Registered ❖ If the password is incorrect, you get the message: Password verify error Do you want to retry <Y/N>? Toshiba Utilities Using a supervisor password simultaneously to return to Windows. and press dos\svpw Enter...
Page 190
Windows NT shuts down and the computer turns itself off. Connect your diskette drive. For instructions, see external USB diskette drive” on page Insert the Toshiba Companion Diskette into the diskette drive and turn on the computer. After a few minutes, a Welcome screen appears.
Page 191
Enter the password and press NOTE: After three attempts to enter the correct password, the utility exits to the system prompt without deleting the supervisor password. Press Ctrl, Alt, Toshiba Utilities Using a supervisor password Enter c:\toshiba\svpw Enter simultaneously to return to Windows.
Page 192
Toshiba Utilities Using a supervisor password — Blank Page —-...
For further assistance and solutions, use Toshiba’s support tool, VirtualTech, to help diagnose and solve possible problems. If all else fails, contact Toshiba. You will find information on Toshiba’s support services at the end of this chapter.
If Something Goes Wrong Problems that are easy to fix Problems that are easy to fix Your program stops responding. If you are working with a program that suddenly freezes all operations, chances are the program has stopped responding. You can exit the failed program without shutting down Windows 98 Second Edition or closing other programs.
Page 195
Your program performs an illegal operation. If you receive the message, “ , ” you should record the details of the message and consult operation the software manufacturer. To record the details: Click the Details button and select the text Windows 98 Second Edition displays.
If Something Goes Wrong Problems when you turn on the computer To close the program: Press Ctrl The Close Program dialog box displays all the programs and processes currently in operation. If the program has stopped responding, the words “not responding” appear beside it. Click End Task , then click Cancel .
Page 197
Problems when you turn on the computer The computer starts but, when you press a key on the keyboard or touch the AccuPoint II, nothing happens. To clear the condition, press press the reset button. Clearing the condition may get the computer running, but it won’t solve a resource conflict.
If Something Goes Wrong Windows 98 Second Edition is not working The computer displays the Make sure there is no diskette in the external USB diskette drive. If there is one, remove it and press any key to continue. If pressing any key does not work, press button to restart the computer.
Page 199
Windows 98 Second Edition is not working To open the Startup menu: Restart your computer. Press when your computer starts. The Startup menu displays these options: ❖ Normal ❖ Logged (\BOOTLOG.TXT) ❖ Safe mode ❖ Step-by-step confirmation ❖ Command prompt only ❖...
If Something Goes Wrong Windows 98 Second Edition is not working You or a qualified Windows 98 Second Edition expert can use this log file to check the loading and initializing of device drivers. DEFINITION: A device driver is a file that contains information to help the computer’s BIOS (Basic Input/Output System) control the operation of devices connected to the system.
Page 201
Windows 98 Second Edition is not working system asks you to confirm each line of the startup process once it appears. Use this option: ❖ When the startup process fails while loading the startup files. ❖ To verify all drivers are being loaded. ❖...
If Something Goes Wrong Windows 98 Second Edition is not working Use this option when you want to run MS-DOS or Windows 98 Second Edition commands. This option is for advanced users who are familiar with MS-DOS and know what these commands do. Safe mode command prompt only Selecting Safe mode command prompt only bypasses the system start-up files and displays the command prompt.
Windows 98 Second Edition can help you If Windows 98 Second Edition has started properly, but you still have a problem using your computer, the online Help can assist you in troubleshooting the problem. To access Windows 98 Second Edition Help: Click the Start button and click Help .
If Something Goes Wrong Resolving a hardware conflict If there is still a problem, Windows 98 Second Edition should display a message that explains what the conflict is. If this happens, you may need to solve the problem on your own. A plan of action The smooth operation of the system depends on the interaction of all devices, programs, and features.
Direct Memory Access Similarly, the data required by the device is stored in a specific place or address in memory called the Direct Memory Access (DMA). The DMA provides a dedicated channel for adapter cards to bypass the microprocessor and access memory directly. If two or more devices use the same DMA, the data required by one device overwrites the data required by the other, causing a hardware conflict.
If Something Goes Wrong Resolving a hardware conflict ❖ Disable another system component and use its resources for the new device. See Manager” on page ❖ Reconfigure the device so that its requirements do not conflict. Refer to the device’s documentation for instructions about changing settings on the device.
Checking device properties Device Manager provides a way to view the properties of a device. Properties include the name of the manufacturer, the type of device, the drivers installed, and the system resources assigned to the device. To check a device’s properties: Click the My Computer icon with the secondary button, then click Properties .
If Something Goes Wrong Resolving a hardware conflict Select Shut down , then click OK . Windows 98 Second Edition shuts down and turns off the computer automatically. NOTE: You may have to manually turn off the computer in Windows NT. Remove the memory card.
Page 209
If the AC power light still does not come on, check that the wall outlet is working properly by plugging in a lamp or other appliance. The AC adapter and power cable work correctly, but the main battery will not charge. The main battery doesn’t charge while the computer is consuming full power.
If Something Goes Wrong Resolving a hardware conflict Is your software using the hard disk more? Is the display power set to turn off automatically? Was the battery fully charged to begin with? All these conditions affect how long the charge lasts. For more information on maximizing main battery power, see “Changing the main battery”...
The keyboard locks and the computer will not restart. Make sure the power is on and press the reset button. AccuPoint II problems Some of the keyboard problems already listed may affect the AccuPoint II. In addition: Your finger slides off the AccuPoint II easily. If the AccuPoint II cap is oily, remove the cap and clean it with a cotton swab dipped in rubbing alcohol.
If Something Goes Wrong Resolving a hardware conflict Display problems Here are some typical display problems and their solutions: The display is blank. Display Auto Off may have gone into effect. Press any key to activate the screen. You may have activated the instant password feature by pressing simultaneously.
for the screen. The Settings tab allows you to choose the screen resolution. The built-in screen flickers. Some flickering is a normal result of the way the screen produces colors. To reduce the amount of flickering, try using fewer colors. A message tells you that there is a problem with your display settings and that the adapter type is incorrect or the current settings do not work with your hardware.
Page 214
If Something Goes Wrong Resolving a hardware conflict To run ScanDisk: Click Start , point to Programs , Accessories , System Tools, and click ScanDisk . Click the drive you want to test. Select the type of test you want to use. A thorough test is more complete but takes much more time than a standard test.
Page 215
You may also be able to recover lost data using utility software, which is available from your network administrator or your authorized Toshiba representative. Some programs run correctly but others do not. This is probably a configuration problem. If a program does not run properly, refer to its documentation and check that the hardware configuration meets its needs.
Page 216
If Something Goes Wrong Resolving a hardware conflict If you are starting the computer from a diskette, the diskette in the drive does not have the files necessary to start the computer. Replace it with a bootable diskette. The drive cannot read a diskette. Try another diskette.
Page 217
The audio settings are incorrect. Please check sound card or drivers. The audio card was found, but there is a problem with the audio card or drivers. The wrong audio card and/or audio driver may be installed in the system. Check installation of audio sound card.
If Something Goes Wrong Resolving a hardware conflict Sound system problems You do not hear any sound from the computer. Adjust the volume control. If you are using an external headphone or speakers, check that they are securely connected to your computer. In TSETUP, check that the sound function is enabled.
Card Information Structure (CIS). Sometimes the CIS contains enough information for you to use the card immediately. Other cards must be set up before you can use them. Use the Windows 98 Second Edition PC Card (PCMCIA) Wizard to set up the card.
Page 220
If Something Goes Wrong Resolving a hardware conflict The slots appear to be dead. PC Cards that used to work no longer work. Check the PC Card status: Click the My Computer icon with the secondary button, then click Properties . The System Properties dialog box appears.
Remove the card from the slot. HINT: Windows NT does not support hot swapping. The system does not recognize your PC Card or PCMCIA socket controller. This problem may be caused by a low main battery. Charge the main battery fully: Make sure the computer is not in Standby mode.
If Something Goes Wrong Resolving a hardware conflict The printer will not print. Check that the printer is connected to a working power outlet, turned on and ready (on line). Check that the printer has plenty of paper. Some printers will not start printing when there are just two or three sheets of paper left in the tray.
The modem will not receive or transmit properly. Make sure the RJ11 cable (the one on the right side of the computer that goes from the modem to the telephone line) is firmly connected to the computer’s modem port and the telephone line socket.
If Something Goes Wrong Using VirtualTech On a regular basis, back up the information stored on your hard disk. Here are some ways you can do this: ❖ Copy files to diskette in Windows 98 Second Edition, following the steps in ❖...
Page 225
To load an update, click yes . ❖ Run a detailed system report that harvests and compiles your system’s hardware and software information. This report is also accessible to Toshiba’s InTouch Center technicians to reference when you place a call or send a question electronically. ❖...
Contacting Toshiba If you still need help and suspect that the problem is hardware- related, Toshiba offers a variety of resources to help you. Start with accessing Toshiba on the Internet using any Internet browser by typing: www.pcsupport.toshiba.com...
Information about what you were doing when the problem occurred. ❖ Exact error messages and when they occurred. For technical support, call the Toshiba InTouch Center: Within the United States at (800) 457-7777 Outside the United States at (949) 859-4273 Other Toshiba Internet Web sites www.toshiba.com...
CHS Promark Colombia Ltda. Carrera 129, Nro. 2957 Parque Industrial de Occidente Bodega 30 - Zona Fontibón Santa Fe de Bogotá, Colombia Australia Toshiba (Australia) Pty. Limited 84-92 Talavera Road North Ryde NSW 2113 Sydney Australia Belgium Toshiba Information Systems Benelux (Belgium) B.V.
Page 229
Denmark Scribona Danmark A/S Naverland 27 DK2600 Glostrup Denmark France Toshiba Systèmes (France) S.A. 7, Rue Ampère 92804 Puteaux Cédex France Greece Ideal Electronics S.A. 109 Syngrou Avenue 176 71 Kalithea Athens Greece Ireland Same as United Kingdom Japan Toshiba Corporation, PCO-IO...
Page 230
Edificio Europa, 1a Planta Escalera A 28831 (Madrid) San Fernando de Henares Spain New Zealand Toshiba (New Zealand) Pty. Limited Level 4, 3 Ferncroft Street Grafton Auckland New Zealand Papua New Guinea Fujitsu (PNG) Pty. Ltd. P.O. Box 4952 Boroko...
Page 231
Switzerland Ozalid AG Herostrasse 7 8048 Zürich Switzerland United States Toshiba America Information Systems, Inc. 9740 Irvine Boulevard Irvine, California 92618 United States If Something Goes Wrong Toshiba’s worldwide offices United Kingdom Toshiba Information Systems (U.K) Ltd. Toshiba Court Weybridge Business Park...
Appendix A Hot Keys These hot keys are used in conjunction with the system functions on and off. Instant Password Security This hot key locks the keyboard and blanks the display. To start work again, if you haven’t registered a password, press Enter type your password and press information about the instant password, see...
Page 234
Hot Keys Shutdown mode Shutdown mode This hot key displays the shutdown mode pop-up window and cycles through the different Shutdown modes. For Windows 98 Second Edition: The Shutdown modes in Windows NT are Shutdown and Suspend/Resume (Memory). Sample shutdown modes window (Windows NT) Sound This hot key cycles the alarm volume through Off, Low, Medium, and High.
Display options This hot key cycles through these display options: built-in display only, external monitor only, and simultaneous display. Keyboard This hot key turns the cursor control overlay on and off. This hot key turns the numeric overlay on and off. This hot key turns the scroll lock feature on and off.
Appendix B Features and Specifications This appendix lists the features and specifications of your computer. Features This section lists the features of your computer and any external devices that come with the system. Technology and processor Microprocessor Processor L1 cache Processor L2 cache Front side bus System bus...
Features and Specifications Features ROM BIOS Main memory Built-in memory Expansion memory Access speed Data / address bus width Storage capacity Hard disk 3.5-inch diskette drive Standard hardware Display panel Video controller Keyboard 512 KB 4 Mbit flash EPROM 128 MB SDRAM, 3.3V, expandable to 256 MB One expansion slot available for one SODIMM SDRAM module CAS latency = 2...
Page 239
Pointing device Sound Modem NOTE: Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during downloads. Actual data transmission speeds will vary depending on line conditions. PC Card slots Ports Microphone jack Headphone jack USB port Monitor port Expansion port Features and Specifications...
Page 240
Features and Specifications Features Modem port Infrared port External power and the batteries Power supply AC power cable Main battery pack RTC battery Intelligent power supply Automatic power off RJ11 jack IrDA1.1 fast infrared port 100 - 240V, 50/60 Hz, 45 watts maximum universal external AC Adapter Weight: 0.5 lbs (235 g) Size: width x depth x height...
Page 241
LAN Port Replicator Communications PS/2-compatible mouse/ keyboard port Parallel port Serial port Monitor port Network port USB port Line-out port DC IN jack LAN on/off switch Features and Specifications Built-in Ethernet module supports 10BASE-T (10 megabits per second,) or 100BASE-Tx Fast Ethernet (100 megabits per second) Allows you to attach a PS/2-compatible keyboard or mouse, or to attach both using a Y-cable...
Features and Specifications Specifications Specifications Physical dimensions Weight Size Environmental conditions Ambient Temperature Relative Humidity Altitude (from sea level) Shock Vibration Optional accessories and devices This section lists some options available for your computer. To order additional devices or accessories see the accessories information packaged with your computer, or visit www.toshibaaccessories.com 3.4 lbs.
Memory modules 64 MB 128 MB Power devices Battery charger Optional high-capacity battery Additional main battery packs Security Cable Other devices and accessories I/O Adapter Multimedia Port Replicator Features and Specifications Optional accessories and devices SODIMM SDRAM module expands the computer’s memory to 192 MB SODIMM SDRAM module expands the computer’s memory to 256 MB...
Page 244
Features and Specifications Optional accessories and devices Secondary hard disk drive CD-ROM drive DVD-ROM drive Carrying case HDD drive kit to fit the Multimedia Port Replicator’s SelectBay CD-ROM drive kit to fit the Multimedia Port Replicator’s SelectBay PORT-Noteworthy PC Card CD-ROM drive DVD-ROM drive kit to fit the Multimedia Port Replicator’s SelectBay PORT-Noteworthy PC Card DVD-ROM drive...
Appendix C Video Modes This appendix lists the video modes supported by the computer display adapter, and identifies the characteristics of each mode. The columns of the following tables are defined as follows: Mode is the mode number in hexadecimal, and is generally used by programmers to specify video modes in programs.
Video Modes This table lists the video modes for your computer: Mode (hex) Type Resolution 0, 1 VGA Text 40 x 25 2, 3 VGA Text 80 x 25 0, 1 VGA Text 40 x 25 2, 3 VGA Text 80 x 25 0+, 1+ VGA Text 40 x 25 2+, 3+...
Page 247
Mode (hex) Type Resolution SVGA 640 x 480 Graph SVGA 800 x 600 Graph SVGA 1024 x 768 Graph SVGA 1280 x 102 Graph SVGA 640 x 480 Graph SVGA 800 x 600 Graph SVGA 1024 x 768 Graph Video Modes Internal LCD Grid Grid...
Page 248
Video Modes Mode (hex) Type Resolution SVGA 1024 x 600 Graph SVGA 1280 x 102 Graph SVGA 640 x 480 Graph SVGA 640 x 480 Graph SVGA 800 x 600 Graph SVGA 800 x 600 Graph SVGA 1024 x 768 Graph SVGA 1024 x 768...
Page 249
Mode (hex) Type Resolution SVGA 640 x 480 Graph SVGA 800 x 600 Graph This table describes the display image size at different resolutions for the internal display, an external display and simultaneous display. Internal display Resolution only 640 x 480 Cropped image* 800 x 600 Full screen...
Appendix D Power Cable Connectors Your computer features a universal power supply you can use worldwide. This appendix shows the shapes of the typical AC power cable connectors for various parts of the world. USA and Canada UL approved CSA approved Australia AS approved United Kingdom...
Page 252
Power Cable Connectors — Blank Page —-...
Glossary TECHNICAL NOTE: Some features defined in this glossary may not be available on your computer. Acronyms These acronyms may appear in this user’s guide. alternating current basic input/output system BIOS bits per second compact disc compact disc read-only memory CD-ROM compact disc read/write memory CD-RW...
Page 254
Glossary Acronyms DIMM DSTN DVD-ROM digital versatile (or video) disc read-only memory EPROM HTML LPT1 MIDI PCMCIA direct memory access dual inline memory module disk operating system dots per inch dual supertwist nematic digital versatile (or video) disc enhanced capabilities port erasable programmable read-only memory file allocation table Federal Communications Commission...
Page 255
SCSI SDRAM SRAM SVGA Terms These terms may appear in this user’s guide. active-matrix display —A liquid crystal display (LCD) made from an array of liquid crystal cells using active-matrix technology. Also known as a “TFT display,” in its simplest form there is one thin film transistor (TFT) for each cell.
Page 256
Glossary Terms application —A computer program that you use to perform tasks of a specific type. Applications include word processors, spreadsheets, and database management systems. See also program . backup —A copy of a file, usually on a removable disk, kept in case the original file is lost or damaged.
Page 257
byte —A sequence of eight bits. A byte is the smallest addressable unit of data. See also bit, gigabyte, kilobyte , megabyte . cache —A section of very fast memory in which frequently used information is duplicated for quick access. Accessing data from cache is faster than accessing it from the computer’s main memory.
Page 258
Glossary Terms controller —A device that controls the transfer of data from a computer to a peripheral device and vice versa. For example, disk drives, monitors, keyboards, and printers all require controllers. CPU —See central processing unit (CPU). CPU cache —A section of very fast memory residing between the CPU and the computer’s main memory that temporarily stores data and instructions the CPU will need to execute commands and programs.
Page 259
disk —A round, flat piece of material that can be magnetically influenced to hold information in digital form, and used in the production of magnetic disks, such as diskettes and hard disks. Compare disc. See also diskette, hard disk. disk drive —The device that reads and writes information and programs on a diskette or hard disk.
Page 260
Glossary Terms emulation— A technique in which a device or program imitates another device or program. enable —To turn on a computer option. See also disable . executable file —A computer program that is ready to run. Application programs and batch files are examples of executable files. Names of executable files usually end with a .bat or .exe extension.
Page 261
—The physical components of a computer system. Compare software. Hibernation —A feature of many Toshiba notebook computers that saves to the hard disk the current state of your work, including all open files and programs, when you turn the computer off. When you turn on the computer again, your work is returned to the same state it was when the computer was turned off.
Page 262
Glossary Terms keyboard shortcut —A key or combination of keys that you use to perform a task instead of using a pointing device such as the AccuPoint II. kilobyte (KB) —A unit of data equal to 1024 bytes. See also byte . L1 (level one) cache —Memory cache built into the processor to help improve processing speed.
Page 263
MIDI (Musical Instrument Digital Interface) —A standard for connecting musical instruments, synthesizers, and computers. The MIDI standard provides a way of translating music into a form computers can use, and vice versa. modem —Short for “modulator/demodulator.” A device that converts information from digital to analog and back to digital, enabling information to pass back and forth between digital computers and analog telephone lines.
Page 264
Glossary Terms parallel —Processes that occur simultaneously. In communications, it means the transmission of more than one bit of information at a time. On your computer, the parallel port provides a parallel communications interface between the computer and an appropriate device.
Page 265
RAM (random access memory) —Volatile memory that can be written to as well as read. By volatile, we mean that information in RAM is lost when you turn off your computer. This type of memory is used for your computer’s main memory. See also memory. Compare ROM.
Page 266
Glossary Terms Standby —A feature of some Windows operating systems that allows you to turn off the computer without exiting your open applications and to continue from where you left off when you turn the computer on again. Suspend —A feature of some Windows operating systems that allows you to turn off the computer without exiting your open applications and to continue from where you left off when you turn the computer on again.
Index AC power adapter-connecting to the computer 48 power light 51 recharging the battery 34 status 32 accessories 242 carrying case 100 Direct Cable Connection software PORT-Noteworthy computer lock cable 60 AccuPoint II location 52 replacing the cap 211 using 52 Add Printer Wizard 116 alarm low battery 89...
Page 268
Index replacing 91 safe disposal 99 safety precautions 83 status 33 caps lock light 31 care of 132 playing 126 viewing contents 130 CD Player control panel 130 CD-ROM drive features 127 cleaning the computer 59 COM port default setting 145 communications 145 finding COM port name 145 network connection 75...
Page 269
care of 132 playing 126 viewing contents 130 DVD-ROM drive disc-in-use light 127 features 127 inserting DVDs or compact discs manual eject 127 removing compact discs or DVDs email 79 environmental considerations 242 ergonomics 38 Ethernet 35 external monitor connecting 120 external monitor, connecting 106 features 61 file transfer protocols 76...
Page 270
Index I/O Adapter ports keyboard 106 monitor 106 mouse 106 parallel 106 serial 106 USB 106 infrared port 26 Internet 77 chat rooms 80 connecting to 78 news groups 80 overview 77 Internet access 80 Internet Service Provider (ISP) 78 Interrupt ReQuest (IRQ) Channel 204 jacks DC IN 29...
Page 271
modem connecting 47 troubleshooting 222 verify connection 146 modem port 29 modes Hibernation 154 Safe, Windows 98 SE 200 serial and parallel 114 monitor external, connecting 102 port 28 monitor port 35 mouse connecting 111 port 35 moving the computer 59 Multimedia Port Replicator 104 network accessing 75...
Page 272
Index pointing device & serial, USB, or PS/2 mouse 111 port expander keyboard 105 Line out jack 105 monitor 104 mouse 105 parallel port 105 serial port 105 Universal Serial Bus (USB) port Port Replicator DC IN jack 104 ports audio device 35 communications 145 expander 104...
Page 273
134 time setting time, date, time zone 55 toolbars 141 Toshiba online services Toshiba Forum 226 Toshiba’s Power Saver utility 161 traveling tips 100 troubleshooting AC/power AccuPoint II 211 computer emits a loud, high- computer will not start 196...
Page 274
Index disk or diskette drive not accessed 197 diskette drive cannot read diskette 216 diskette will not insert 215 hot swapping fails 220 Internet problems 202 keyboard AccuPoint II problems 211 error message(s) 210 locks and computer won’t restart 211 nothing happens 210 nothing happens when pressing keys or...
Page 275
36 utilitities Toshiba’s Power Saver 161 video controller specifications 238 video modes 245 characteristics 245 VirtualTech™ 193 using 225 volume control 150 dial 26 warranty extended worldwide 56 Web address 79 Web browsers 78 Web site subscriptions 143...
Need help?
Do you have a question about the Portege 3490CT and is the answer not in the manual?
Questions and answers
