Toshiba Portege 3490CT Brochure & Specs

TOSHIBA
Portégé 3490CT
Ultra-Mobility
!
Part Number: PP349U-6PY831
!
UPC Code: 032017089341

Product Highlights

Performance
128MB SDRAM, expandable to 256MB
Intel Pentium III processor, 700MHz
® ®
Great Features!
11.3" diagonal TFT Color LCD
8MB internal Video Memory
Get Connected!
Integrated V.90 K56 modem
Expandibility!
LAN Port Replicator with 6 ports
System Characteristics
Processor
Intel Pentium III 700MHz LV Processor featuring Intel
® ®
Speedstep ™ Technology Performance (1.35V)
Integrated co-processor
L2 Cache Memory
256KB Level 2 cache integrated on die
100MHz front side bus clock speed
Main Memory (on board)
128MB standard, expandable to 256MB
128Mbit PC100 SDRAM, 3.3V
Data/Address Bus Width: 64-bit/32-bit
Expansion Memory
Module type: SODIMM
64Mb/128Mb PC100 SDRAM
Data/Address Bus Width: 64-bit/32-bit

MASS STORAGE

Floppy Disk Drive (TEAC)
3.5", 1.44MB External USB Floppy Disk Drive
Primary Hard Disk Drive (Toshiba MK2016GAP)
20.0 billion byte Enhanced IDE (ATA-5), 2.5"
Service removable
9.5 mm height, 0.2 lbs
13 ms average access time (read/write)
3.0 ms track to track seek time (read/write)
4200 rpm drive rotation
Supports PIO Mode4
Graphics/Video
Display
11.3" Poly-silicon TFT Color LCD (XGA)
Internal display supports up to 16M colors at 1024 x 768
Graphics Controller
S3 Savage IX graphics controller, 128-bit 3D Graphics
Accelerator
128bit BitBLT engine, 33MHz PCI bus
8MB internal video memory
External Color Support
640 x 480, 800 x 600; 60/75/85Hz Non-Interlaced @ 16M
1024 x 768; 60/75Hz Non-Interlaced @ 16M
1280 x 1024; 60Hz Non-Interlaced @ 16M
1600 x 1200; 60/75Hz Non-Interlaced @ 64K

Input Devices

Keyboard
84 keys with 12 function keys
2mm key stroke, 4.8mm height
Dedicated Windows® keys
Integrated AccuPoint® II pointing device with user-
programmable scroll buttons
Expandability
1 Expansion memory slot
2 PC Card slots support two Type II or one Type III
Cards; PCMCIA R2.01, PC Card16, CardBus
Ports
1 Fast infrared port (4Mbps, IrDA1.1 compliant)
1 SVGA video port
1 Universal Serial Bus (USB) port
RJ-11 modem port
1 Serial PCI port (for Port Replicator)
LAN Port Replicator includes:
DC-In
USB port
Line out
SVGA port
1 serial port
1 ECP parallel printer port
1 PS/2 Keyboard/Mouse
1 RJ45 LAN port
Sound
Toshiba America Information Systems Inc. ("TAIS") shall not be liable for damages of any kind for use of this information, which is subject to change without notice. Copyright 2001 TAIS Key West 15T
GREEN Spec 01-26-01.doc Rev. 24 08/29/01
Yamaha YMF743
16-bit stereo, Windows Sound System Ver.2.0, Sound
Blaster® Pro compatible (on DOS box only)
3D Sound Support (AC'97 Codec-based)
Direct 3D Sound
Hardware acceleration for DirectSound
Full Duplex support
Ports
Microphone port
Headphone port
Line-out (on LAN Port Replicator)
Sound Volume Control button
Built-in Microphone
Built-in Speaker
Communication
Integrated V.90 56K modem
Data and fax support

Physical Description

Dimensions (WxDxH): 10.3" x 9.1" x 0.8"
Weight: 3.4lbs (with 6-cell battery)
LED Indicators
Power / System Sleep / Suspend Status
DC-In
Primary HDD
Main Battery Charging Status
Secondary Battery Charging Status
®
Caps Lock
Arrow mode
Numeric mode

Power Supply

AC Adapter
45W AC Adapter
100-240V 50/60Hz frequency (Universal) input
Dimension (WxDxH): 3.9" x .98" x 1.96"
Weigh: 0.5 lbs (w/o AC Power Cable)
Battery Pack
Rechargeable, removable Li-Ion battery (6 cell)
10.8V x 3000mAh capacity
2.5+ hours battery life
Recharge time: 2.5H unit off / 3-6H unit on
Dimensions (WxDxH): 8.2" x 1.5" x 0.76"
Weigh: 0.6 lbs
Battery life may vary depending on applications, power management
settings and features utilized. Recharge time varies depending on
usage.
Slot for Kensington Lock
Memory, HDD and Modem (by screw only)
User Power-on and HDD password
Screen Saver by software
TSETUP, APM V1.2, ACPI V1.0b, PnP V1.0a, VESA V2.0,
DPMS, DDC2B, SM BIOS V2.3, PC BIOS V2.1 Support
System Bus Architecture: PCI Bus V2.2

Operating Systems

Microsoft® Windows 2000
Microsoft Windows NT 4.0
Microsoft Windows 98
Microsoft Internet Explorer - 98SE/NT4.0/2000
Puma IntelliSync 97 - NT4.0 only
Toshiba custom utilities - 98SE/NT4.0/2000
VirtualTech – 98SE/NT4.0/2000
Electronic User Guide - 98SE/NT4.0/2000
1 year parts, labor and battery

Environmental Specifications

Temperature:
O O
Operating: 5 to 35
O
Non-operating: -20
Thermal gradient:
O
Operating: 15 C per hour maximum
PC O
Non-operating: 20
Relative Humidity:
Operating: 20% to 80% non-condensing
Non-operating: 10% to 90% non-condensing
Altitude (relative to sea level):
Operating: -197 to 9,842 feet
Non-operating: -197 to 32,808 feet
Shock:
Operating: 10G
Non-operating: 60G
Vibration:
Operating: 0.5G
Non-operating: 1.0G
Accessories
Security
Bios
Software
Warranty
O O
C (41 to 95 F)
O O O
to 65 C (-4 to 149 F)
C per hour maximum
PA3053U-1PCC Bluetooth PC Card
8484415560 Agere Wireless LAN Gold Card
8485582350 Agere AP-1000 (w/ Gold card)
PA3066U-1PCC Fingerprint Reader PC Card
PA3079U-1PCC 2GB* Type II PC Card HDD
PA3041U-1PRP I/O Adaptor
PA3040U-1PRP LAN Port Replicator
PA3042U-1DST MultiMedia Port Replicator
PA3035U-1ACA 45W universal AC adapter
PA3038U-1BRL Li-Ion Battery Pack
PA3039U-1BRL High Capacity Battery
KTT-MD100/64 64MB Memory
KTT-MD100/128 128MB Memory
PA3015U-1CDD CD-ROM (MultiMedia Port Replicator)
PA3014U-2DVD DVD-ROM (MultiMedia Port Replicator)
Product/Part Number/UPC
Portégé 3490CT PP349U-6PY831 / 032017089341
