Left side

The following figure shows the computer's left side.
1.
2.
3.
RGB Monitor Port
Fan Vents
To prevent possible over heating of the CPU, never block the fan vent.
TV Out Port
i.LINK (IEEE1394a)
Port
Universal Serial Bus
(USB) Port
PC Card Slot
User's Manual
1 2
RGB Monitor Port
Fan Vents
TV Out (S-Video) Port
The left side of the computer
This 15-pin port lets you connect an external
video display to the computer.
The fan vents help prevent the CPU from
overheating.
Connect a 4-pin S- video cable into this connector
in order to output either an NTSC or PAL
television signal.
This port allows you to connect an external
device, such as a digital video camera, for high-
speed data transfer.
The availability of this function depends on the
model you purchased.
The Universal Serial Bus (USB 2.0 and 1.1
compatible) port enables USB-equipped devices
such as keyboards, mice, hard drives, scanners,
and printers to be connected to the computer.
The PC Card slot can accommodate one 5 mm
PC Card (Type II). You can install any industry
standard PC Card such as a SCSI adapter,
Ethernet adapter or flash memory card.
3 4 5
4. i.LINK (IEEE1394a) Port
5. Universal Serial Bus (USB) Port
6. PC Card Slot
The Grand Tour
6
2-4
