Back side

The following figure shows the computer back panel.
1.
2.
3.
Modem Jack
Security Lock
LAN Jack
Universal Serial Bus
(USB) Ports
DC IN 19V Jack
User's Manual
1
2
Modem Jack
Security Lock
LAN Jack
4. Universal Serial Bus (USB) Ports
5. DC IN 19V Jack
The back side of the computer
In regions where an internal modem is installed
as standard equipment, this jack lets you use a
modular cable to connect the modem directly to a
telephone line.
An optional security cable attaches to this port in
order to anchor your computer to a desk or other
large object to deter theft.
This jack lets you connect to a LAN. The adapter
has built-in support for Ethernet LAN
(10 megabits per second, 10BASE-T) and
Fast Ethernet LAN (100 megabits per second,
100BASE-TX). Two indicators built into the jack
let you see the LAN status.
The Universal Serial Bus (USB 2.0 and 1.1
compatible) ports enable USB-equipped devices
such as keyboards, mice, hard drives, scanners,
and printers to be connected to the computer.
The DC IN jack is where you plug in the
AC adapter.
The Grand Tour
3 4 5
2-5
