Toshiba Tecra A11-S3511 Specifications

Tecra A11 Detailed Product Specification
Model Name A11-S3511
:
C1 2
Operating System

Genuine Windows® 7 Professional 32-bit,
Professional 64-bit; includes Windows® XP Professional downgrade
(Windows® XP Professional pre-installed)
3
Processor and Graphics
 Intel ®
Core™ i3-350M Processor
o 2.26 GHz, 3MB Cache
 Mobile Intel ®
HM55 Express Chipset
 Mobile Intel
®
HD Graphics with 64MB - 728MB dynamically allocated
shared graphic memory (with Windows 7 Professional 64-bit)
5
Memory
 Configured with 2GB (2GB x 1) DDR3 1066MHz (max 8GB)
 2 main memory slots. Both slots are occupied
6
Storage Drive
 250GB (5400 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive
 DVD SuperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
8
Display
 15.6" diagonal widescreen TruBrite
768 native resolution (HD)
o Native support for 720p content
o 16:9 aspect ratio
Sound
 Built-in stereo speakers
Input Devices
 Standard US keyboard with 10-key numeric pad (black)
 TouchPad™ pointing device
 TouchPad™ Enable/Disable
 Control Buttons:
o TOSHIBA eco Utility™ button
o Volume Down
o Volume Up
o Presentation button
Communications
 Webcam and microphone
 Modem
9
 Intel 82577LC Gigabit Network Connection (10/100/1000 Ethernet)
 Centrino® Advanced-N 6200 (Intel
 Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
 ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
 Memory Card Reader
Secure Digital, Secure Digital High Capacity, Mini SD Card,
o
Micro SD Card, Micro SDHC, xD Picture Card, Memory Stick™,
Memory Stick PRO™, Multi Media Card [shared slot]
Ports
 Video
RGB (monitor) output
o
Mini DisplayPort™
o
 Audio
Microphone input port
o
Headphone output port
o
 Data
Serial port
o
4 USB v2.0 ports
o
2 x USB v2.0
o
1
Part Number: PTSE0U-02P00M
Genuine Windows® 7
4
7
®
TFT LED backlit display at 1366 x
® 10
802.11a/g/n )
© Copyright 2010 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
o
o
RJ-45 LAN port
o
RJ-11 modem port
o
Docking connector
o
 Security
Fingerprint Reader
o
Slot for Security Lock
o
Physical Description
 Textured Finish in Charcoal Black
 Dimensions (W x D x H ): 14.7" x 9.86" x 1.31"/1.48"
 Weight: Starting at 5.6 lbs., depending upon configuration
12
Battery
 6 cell (55 Wh) Lithium Ion battery pack
 Dimensions (W x H x D): 8.11" x 1.78" x 0.79"
 Weight: starting at 0.72 lbs.
 Battery Life Rating (measured by MobileMark™ Productivity 2007)
Included 6 cell battery: 4 hours, 41 minutes
o
Power Supply
 75W (15V x 5A) Auto-sensing ,100-240V/50-60Hz AC Adapter
 Dimensions (W x H x D): 4.96" x 1.18" x 1.97"
 Weight: starting at 0.79 lbs.
Toshiba EasyGuard
 Protect & Fix
o Toshiba PC Health Monitor
o TOSHIBA HDD protection (3D Accelerometer)
o TOSHIBA Shock Protection System
o HALT Tested Design
o LCD Cover pressure Resistant Design
o Hinge Design Enhancement
o Polyurethane (PU) Coated Palm Rest
o Spill Resistant Keyboard
TOSHIBA PC Diagnostic Tool
o
 Secure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad
o Infineon TPM Software Professional Package
o Trusted Platform Module v1.2
o TOSHIBA Secure Digital Token Utility
o Reinforced Security Cable Lock Slot
o Execute Disable Bit
 Connect
o Diversity Antenna
o TOSHIBA ConfigFree
o Voice-over-IP Ready Design
o TOSHIBA Bluetooth
o Wireless Communication On/Off Switch
 Optimize
o Toshiba Disc Creator
o TOSHIBA Device Access Control
o TOSHIBA Power Management Extension
o TOSHIBA Password Utilities
o TOSHIBA Recovery Media Creator
o TOSHIBA eco Utility
o TOSHIBA Assist
o TOSHIBA USB Sleep and Charge
o TOSHIBA Zooming Utility
FN Shortcut Keys
o
BIOS
 APM, ACPI, PNP, VESA , DPMS, DDC, SM BIOS, PCI BIOS support
 Computrace
®
( BIOS enabled)
Tecra A11-S3511
UPC: 883974507375
1 x USB v2.0 with Sleep and Charge (left side)
1 x eSATA/USB combo port with Sleep and Charge
14
®
® ®
TrueSuite
®
®
Stack
11
13
