Table of Contents

Parts Checklist............................................................................................................3
Product Overview........................................................................................................3
Videoconferencing......................................................................................................4
Audioconferencing......................................................................................................4
The Room.................................................................................................................4
Room Reverberation.....................................................................................................4
Ambient Room Noise....................................................................................................5
Room Usage..............................................................................................................5
Typical Configurations..................................................................................................6
Required Cable...........................................................................................................6
Required Tools ..........................................................................................................7
Microphone and Speaker Terminations............................................................................8-9
Connections...............................................................................................................9
Echo Cancellation / Signal Processing................................................................................9
Volume Control..........................................................................................................9
Microphone Muting.....................................................................................................9
Multi-point Calls.........................................................................................................9
What's in the Box........................................................................................................10
Installation................................................................................................................10
Using the System........................................................................................................11
Remote Control..........................................................................................................11
Echo Cancellation / Signal Processing................................................................................11
Auto Mixing.............................................................................................................11
Calibration
Videoconferencing......................................................................................................11
Audioconferencing......................................................................................................12
Technical Support.......................................................................................................12
Audio Recordings.......................................................................................................12
Recordings During Videoconferencing..............................................................................12
Common Problems.....................................................................................................12
Defective / Damaged Components...................................................................................13
1
Page 1 of 29
SHURE EXHIBIT 1026

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SM-02 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Shure SM-02

  • Page 1: Table Of Contents

    What’s in the Box…………………………….…….……………………………………………………...10 Installation…………………………………….…….……………………………………………………..10 Using the System……………………………….….………………………………………………………11 Remote Control………………………………….………………………………………………………...11 Echo Cancellation / Signal Processing…………..………………………………………………………...11 Auto Mixing……………………………………….………………………………………………………11 Calibration Videoconferencing…………………………………….…………………………………………………..11 Audioconferencing………….…………………………….……………………………………………….12 Technical Support………………………………………….……………………………………………...12 Recordings Audio Recordings…………………………………………….…………………………………………...12 Recordings During Videoconferencing……………………….…………………………………………..12 Troubleshooting Common Problems………………………………………………………………………………………..12 Defective / Damaged Components………………………………………………………………………..13 Page 1 of 29 SHURE EXHIBIT 1026...
  • Page 2 Polycom View Station………………………………………………………………………………………20 Premier Telephone Interface…………………………………………………………………………..……21 Sony Contact PCS 1500..…………………………………………………………………………………...22 Tandberg Vision 800, 2500…………………………………………………………………………………23 Tandberg Vision 2000………………………………………………………………………………………24 Tanberg Vision 5000, 6000, 7000 (single SM-02)…………………………………………………………25 Tanberg Vision 5000, 6000, 7000 (multiple SM-02s)…...…………………………………………………26 VCON MediaConnect 6000, 8000…………………………………………...……………………………..27 VTel LC5000, TC2000, Galaxy Group Systems.…………………………………………………………..28 Cables..………………………………………………………………………………………………….…..29...
  • Page 3: What's In The Box

    2. Enables all participants to be heard in larger rooms 3. Provides a virtually invisible audio system when using CTG ceiling microphones and speakers The SM-02 is a single box microphone / speaker amplification system designed for teleconferencing applications. The Soundman system functions as an audio peripheral to a video codec without affecting or voiding the manufacturer’s factory warranty.
  • Page 4: Videoconferencing

    The Premier is manufactured by Polycom and has hardware and software modifications for use with the SM-02. The Premier functions as a phone only (commonly placed on a credenza) and may also be controlled through a wireless remote ®...
  • Page 5: Ambient Room Noise

    microphones outside the dome in the lower section of ceiling will result in better sound. Please contact CTG’s technical support for recommendations in challenging rooms. Ambient Room Noise When a teleconferencing system transmits excessive ambient noise it is very noticeable to a quieter far end room.
  • Page 6: Typical Configurations

    Typical Configurations The following drawings illustrate common room layouts: TABLE TABLE This is typically a 20’L x 15’Wx 9’H This is typically a 20’L x 20’Wx 9’H room. room. The videoconferencing system is The videoconferencing system is located at centered in the room lengthwise. the head of the table.
  • Page 7: Required Tools

    ™ must be Teflon insulated unless they are enclosed in approved conduit. Every microphone and speaker connects directly (homerun) to the SM-02. To avoid crosstalk, do not run microphone and speaker cables through the same conduit. Required Tools and Hardware The following tools are recommended for the installation of the ceiling components: •...
  • Page 8: Microphone Mounting Detail

    MICROPHONE MOUNTING DETAIL There is a ground jumper between terminals 3 and 4 that should be 4.58" removed if metallic conduit is used, or if the ceiling tile is foil backed, or if any part of the microphone housing comes in contact with building ground. Adjust the exposed length of the 0"...
  • Page 9: Connecting To A Group Videoconferencing System Connections

    Adjustments to the incoming audio should only be made through the videoconferencing system. The speaker volume on the front of the SM-02 is a “set and forget” level. An external volume control should never be inserted between the output of the codec and the input of the SM-02.
  • Page 10: Connecting The Premier Telephone Interface

    2. LINE OUT B on the SM-02 connects to a MIC jack on the Satellite 3. LINE IN B on the SM-02 connects to the AUD I/O jack on the Satellite 4. An analog telephone line connects to the TEL LINE jack 5.
  • Page 11: Using The System

    Auto Mixing The Satellite has an additional microphone input for larger rooms. The output of a second SM-02 may be connected to this input. This input may also be used to highlight a presentation area. Calibration SPEAKER LEVEL MICROPHONE ™...
  • Page 12: Audioconferencing

    Recordings Audio Recordings A record jack is available on the rear of the SM-02 for audio recordings. Recordings may be made on or off a teleconference because the jack is always “hot”. A mini 1/8 inch (3mm) mono phone plug should be used to connect to the SM-02.
  • Page 13: Defective / Damaged Components

    • Ensure that the echo cancellation setting of the codec is set to ON if available • Verify that the LINE OUT A of the SM-02 connects to the specified input by • Ensure the SPEAKER LEVEL is set to at least the 2:00 position •...
  • Page 14: Specifications

    Specifications SM-02 – microphone / speaker control unit: LINE POWER LINE MIC / SPEAKER RECORD CONNECTIONS 1. Power supply connector 2. Line Output – reserved for video codec 3. Line Output – reserved for Premier 4. Line Input – reserved for video codec 5.
  • Page 15: Ctg Microphones: Cm-01, Tm-01, Tm-02

    CTG Microphones: CM-01, TM-01, TM-02 All versions of the CTG microphone utilize a special pressure sensitive, tensionless low- mass element enhanced with an integrated FET low noise amplifier. Their characteristics result in ultra smooth frequency response providing excellent feedback stability for teleconferencing applications.
  • Page 16: Ctg Premier Satellite

    2. RJ45 – connects the Premier phone 3. Input 1 – connects to VR-100 Line Output 4. Input 2 – connects to a second SM-02 Line Output for larger areas 5. Output – connects to the Line Input of the SM-02 6.
  • Page 17: Appendix; Quick Setup Instructions Intel Teamstation

    8: mic 1+ Step 2: Connection of Codec • Connect the LINE OUT A of the SM-02 to the MIC INPUT of the codec with the cable provided by CTG. • Connect the LINE IN A of SM-02 to the LINE OUTPUT of the codec.
  • Page 18: Picturetel Concorde, 4Xxx, Venue

    Enter the PictureTel set menu: Disable the automatic gain control under audio signal processing (if available). • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 12 o’clock position. If needed, call a CTG technician to fine-tune the system levels. •...
  • Page 19: Picturetel Swiftsite, Swiftsite Ii

    8: mic 1+ Step 2: Connection of Codec • Connect the LINE OUT A of the SM-02 to the POWERMIC INPUT of the codec with the cable supplied by CTG. • Connect the LINE IN A of SM-02 to the LINE OUTPUT of the codec.
  • Page 20: Polycom View Station

    Connect POWER to the SM-02. Step 3: Adjust the Send Level • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 12 o’clock position. If needed, call tech support to fine-tune the system levels. • Microphone muting should be performed through ViewStation’s wireless remote control.
  • Page 21: Premier Telephone Interface

    Premier Telephone Interface Quick Setup Sheet SM-02 LINE POWER LINE MIC / SPEAKER ECORD CONNECTIONS SATELLITE PREMIER LINE Step 1: Connect Speakers and Microphones Pinouts: 15 pin D Connector pin 1: speaker 1+ pin 9: speaker 1- pin 2: speaker 2+...
  • Page 22: Sony Contact Pcs 1500

    • Change the audio setting to AUX • Connect the LINE OUT A of the SM-02 to the LINE INPUT of the codec with the cable provided by CTG. • Connect the LINE IN A of SM-02 to the LINE OUTPUT of the codec.
  • Page 23: Tandberg Vision 800, 2500

    The line input volume should be set to 50%. Step 3: Adjust the Send Level • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 12 o’clock position. If needed, call a CTG technician to fine-tune the system levels. •...
  • Page 24: Tandberg Vision 2000

    The line input volume should be set to 50%. Step 3: Adjust the Send Level • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 12 o’clock position. If needed, call a CTG technician to fine-tune the system levels. •...
  • Page 25: Tanberg Vision 5000, 6000, 7000 (Single Sm-02)

    The line level input volume should be set to 50%. Step 3: Adjust the Send Level • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 12 o’clock position. If needed, call a CTG technician to fine-tune the system levels. •...
  • Page 26: Tanberg Vision 5000, 6000, 7000 (Multiple Sm-02S)

    8: mic 1+ Step 2: Connection of Codec • Connect the LINE OUT A of each SM-02 to a MIC INPUT of the codec with the cable provided by CTG. • Connect the LINE IN A of each SM-02 with speakers connected, to a LINE OUTPUT of the codec.
  • Page 27: Vcon Mediaconnect 6000, 8000

    8: mic 1+ Step 2: Connection of Codec • Connect the LINE OUT A of the SM-02 to the MIC INPUT of the codec with the cable provided by CTG. • Connect the LINE IN A of SM-02 to the LINE OUTPUT of the codec.
  • Page 28: Vtel Lc5000, Tc2000, Galaxy Group Systems

    Echo cancellation should be enabled in the codec. Step 3: Adjust the Send Level • With a screwdriver turn the SM-02 MIC ADJUST clockwise to the 2 o’clock position. If needed, call a CTG technician to fine-tune the system levels. •...
  • Page 29: Cables

    Cables CTG will ship one set of cables for the specified videoconferencing system. If the videoconferencing system is not specified, dual RCA cables will ship with the SM-02. The chart below details the codec connections used by CTG. Videoconferencing System...
