SDD100
Dizzy disc
Technical information sheet
REV 03
The site must be level to maintain critical dimensions.
Foundations for bark/sand
Spirit level
0
4
Loose fill
400
400
concrete
2
Timber wedge
Play level
300
780
Spragging
iron
Foundations for wet pour/tiles
Spirit level
0
4
Play level
400
400
concrete
2
Dizzy disc
Code: SDD100
Sheet 1 of 3
AREA 9M²
HIC 1
Timber wedge
80
700
Spragging
iron
Advertisement
Table of Contents
Related Manuals for Sutcliffe Play SDD100
Summary of Contents for Sutcliffe Play SDD100
- Page 1 SDD100 Dizzy disc Technical information sheet REV 03 Dizzy disc Code: SDD100 Sheet 1 of 3 The site must be level to maintain critical dimensions. AREA 9M² HIC 1 Foundations for wet pour/tiles Foundations for bark/sand Spirit level Timber wedge...
- Page 2 Safety surface recommended 9.0 m based on 1.65 m from the center of the equipment (HIC 1M) Length of the safety perimeter 11m. Parts list Item Description Qty. Stock No. Dizzy disk assy SDD100 Required tools: Tape measure Spirit level Digging implements Wedge...
- Page 3 SDD100 Dizzy disc Maintenance Instructions REV 03 Recommended Regular Inspection and Maintenance Interval (days) Check stability of structure, tighten connections if required. Check all uprights at ground level for corrosion and/or rot. Replace any defective parts. Check all painted elements for damage, rub down and repaint or replace as required.
