Orchard - Ship
OTU/OTW215
Installation Instructions
Rev 01
Page 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Orchard - Ship and is the answer not in the manual?

Questions and answers

Related Manuals for Sutcliffe Play Orchard - Ship

Summary of Contents for Sutcliffe Play Orchard - Ship

  • Page 1 Orchard - Ship OTU/OTW215 Installation Instructions Rev 01 Page 1...

  • Page 2: Installation Instructions

    OTU/OTW215 Orchard Unit Installation Instructions Installation of this type of equipment requires at least three people, and the use of a lifting tower or platform. 1. Read all instructions carefully before starting assembly. 2. Identify all components using the parts list and fixing kit list. If you are unsure, please contact our office.
  • Page 3 OTU/OTW215 Orchard Unit Parts List Description Description CZA003 Spider's Web Rail ORP019 Little Sail Panel CZD005 Straight Rail ORP020 Large Sail Panel DZA057 Bench Seat Rail ORP021 Triangle Sail Panel DZA236 Panel Fixing Bracket 3 ORP032 Bench Seat Panel ORA012 Megaphone Barrier ORR220 Spider's Web Net...
  • Page 4 OTU/OTW215 Orchard Unit OTU215F Fixing Kit List: Description ADH150 Super Glue CZS002Y Net Fixing Cover CZS004Y Yellow Nut Cover 58+7 CZS009BK Nylon Bracket Cover 28+2 DZS005 Nylon Nut Cover 63+2 DZS007 Nylon Fixing Covers 59+1 DZS009 Step Washer 117+3 DZA106 Climbing Grips FIX125 M6x25 Security Bolt...
  • Page 5 OTU/OTW215 Orchard Unit Parts List THS025 Illustrations Not To Scale ORM027 OPA006 or OPA007 Wet Pour or Loose Fill ORM028 ORR220 PED080 Rev 01 Page 5...
  • Page 6 OTU/OTW215 Orchard Unit Parts List CZA003 CZD005 DZA236 ORM019 PZA212 ORM030 ORM021 ORM005 ORM023 PZA050 PZA010 Rev 01 Page 6...
  • Page 7 OTU/OTW215 Orchard Unit Parts List ORA017 ORM011 ORA018 ORA202 ORA222 ORA229 PED002 PED302 DZA057 Rev 01 Page 7...
  • Page 8 OTU/OTW215 Orchard Unit Parts List ORP018 ORP032 ORA013 ORA012 ORA014 PZB070 Rev 01 Page 8...
  • Page 9 OTU/OTW215 Orchard Unit Parts List ORP020 ORP019 ORP021 ORP016 ORP015 Rev 01 Page 9...
  • Page 10 OTU/OTW215 Orchard Unit Parts List ORP010 ORP013 ORP002 ORP011 ORP012 Rev 01 Page 10...
  • Page 11 OTU/OTW215 Orchard Unit Fixing Kit CZS002Y CZS004Y CZS009BK DZA106 DZS005 DZS007 DZS009 FIX202 MSL002 ORS002 ORS003 PZA705ZP PZS001 WSR440 Rev 01 Page 11...
  • Page 12 OTU/OTW215 Orchard Unit Rev 01 Page 12...
  • Page 13 OTU/OTW215 Orchard Unit Rev 01 Page 13...
  • Page 14 OTU/OTW215 Orchard Unit Rev 01 Page 14...
  • Page 15 OTU/OTW215 Orchard Unit Fixing Details - Post Caps and Shoes Rev 01 Page 15...
  • Page 16 OTU/OTW215 Orchard Unit Fixing Details - Deck Rails Yellow deck rails are to be positioned under the shuffle decks. Rev 01 Page 16...
  • Page 17 OTU/OTW215 Orchard Unit Fixing Details - Spider's Web Net Rev 01 Page 17...
  • Page 18 OTU/OTW215 Orchard Unit Fixing Details - Spider's Web Net Rev 01 Page 18...
  • Page 19 OTU/OTW215 Orchard Unit Fixing Details - Decks This assembly of fixings is featured on 18mm thick decks: This assembly of fixings is featured on 21mm thick decks: Rev 01 Page 19...
  • Page 20 OTU/OTW215 Orchard Unit Fixing Details - Decks Fixing the bracing plates to the split deck: MCS335 MCS331 DZS009 LKN320 DZS005 Rev 01 Page 20...
  • Page 21 OTU/OTW215 Orchard Unit Fixing Details - Decks Fixing the central positions on deck rails: Rev 01 Page 21...
  • Page 22 OTU/OTW215 Orchard Unit Fixing details for the following activities (please check coach screw length): Rev 01 Page 22...
  • Page 23 OTU/OTW215 Orchard Unit Fixing details for the following activities: Rev 01 Page 23...
  • Page 24 OTU/OTW215 Orchard Unit Fixing details for the following activities (please check coach screw length): Rev 01 Page 24...
  • Page 25 OTU/OTW215 Orchard Unit Fixing details for the following activities (please check coach screw length): Rev 01 Page 25...
  • Page 26 OTU/OTW215 Orchard Unit Fixing details for the following activities (please check coach screw length): Rev 01 Page 26...
  • Page 27 OTU/OTW215 Orchard Unit Fixing Details - Inclined Climber (please check coach screw length): CRITICAL: ENSURE THERE IS A MINIUMUM GAP OF 26mm BETWEEN LOWEST POINT OF DRAG RAMP CURVE AND TOP OF DECK. 25mm FINGER PROBE MUST PASS THROUGH ALL ROUND BETWEEN DRAG RAMP AND DECK.
  • Page 28 OTU/OTW215 Orchard Unit Fixing Details - Panels CZS004Y HSS514 M10 x 40 DZS009 DZS009 LKN320 CZS004Y Rev 01 Page 28...
  • Page 29 OTU/OTW215 Orchard Unit Fixing Details - Bench & Slide Rev 01 Page 29...
  • Page 30 OTU/OTW215 Orchard Unit Fixing Details - Slide Rev 01 Page 30...
  • Page 31 OTU/OTW215 Orchard Unit Fixing Details - Climbing Wall Rev 01 Page 31...

  • Page 32: Maintenance Instructions

    OTU/OTW215 Orchard Unit Maintenance Instructions NOTE The warranty is invalidated if these instructions are not followed. All wood needs annual inspection and retreatment where required. Recommended Regular Inspection and Maintenance Interval Days Check stability of structure, tighten connections if required. Check all uprights at ground level for corrosion and/or rot.
