SSS110 Single Point Nest Swing
Installation Instructions
Central Bracket and
Universal Joint Assembly.
* Please use the fixings provided
STS295
WSR050
HSS615
Fig .1
Sheet 1 of 4
The site must be level to maintain critical dimensions.
TZS004B
LKN330
WSR050
SSS005R
SSS010GAL
Rev 01
Advertisement
Related Manuals for Sutcliffe Play SSS110
Summary of Contents for Sutcliffe Play SSS110
- Page 1 SSS110 Single Point Nest Swing Installation Instructions The site must be level to maintain critical dimensions. Central Bracket and Universal Joint Assembly. TZS004B * Please use the fixings provided LKN330 WSR050 SSS005R STS295 SSS010GAL WSR050 HSS615 Fig .1 Sheet 1 of 4...
- Page 2 SSS110 Single Point Nest Swing Installation Procedure Installation Procedure 1. Plan the final position of the play equipment ensuring there is enough space. 2. Excavate the foundation hole in accordance with the foundation drawing. 3. Start the assembly by attaching two legs to the central bracket.
- Page 3 SSS110 Single Point Nest Swing Installation Procedure Parts List Description Qty. Stock Required Tools: Central Bracket SSS005R Tape Measure Swing Leg SSS010GAL Spirit Level Universal Joint SSS004 Digging Implements Nest Swing Seat SNS022 M12 Torque Wrench M12 X 35 Screw...
- Page 4 SSS110 Single Point Nest Swing Maintenance Instructions NOTE The warranty is invalidated if these instructions are not followed. Recommended Regular Inspection and Maintenance Interval (days) Check stability of structure, tighten connections if required Check all uprights at ground level for corrosion.
