- Page 1 Youthzone Installation Instructions SZU030 Rev 00...
- Page 2 SZU030 Youthzone Unit Installation Instructions Rev 00 Check using the Parts List that none of the components are missing. Plan the final position of the ball court ensuring there is sufficient space. Ensure the ground surface is level Excavate the foundation holes in accordance with the plan. Each leg is numbered to correspond with the foundation plan.
- Page 3 SZU030 Youthzone Unit Parts list Rev 00 SZA028 TZA060 SZA030 SZA020 SZA070 SZA040 SZA050 Description TZA060 Basketball goal SZA040 Cross bar frame SZA020 2.5m Lower panel Top Trim SZA050 1.1m Lower panel Top Trim SZA030 2.5m Upper panel BottomTrim 32 SZA028 2.5m Upper plain panel SZA070...
- Page 4 SZU030 Youthzone Unit Maintenance Instructions NOTE The warranty is invalidated if these instructions are not followed. Recommended Regular Inspection and Maintenance Interval Days Check stability of structure, tighten connections if required. Check all uprights at ground level for corrosion and/or rot. Replace any defective parts.
