PMC 309
THE LOGICAL CHOICE
INSTRUCTION AND PARTS MANUAL
MODEL PM50
PLANEMATIC DRIVE
READ THIS MANUAL BEFORE INSTALLING, OPERATING OR
SERVICING THIS PRODUCT. THIS MANUAL CONTAINS IMPORTANT
INFORMATION. MAKE THIS MANUAL AVAILABLE TO ALL PERSONS
RESPONSIBLE FOR THE OPERATION, INSTALLATION, SERVICING
AND MAINTENANCE OF THIS PRODUCT.
TWG Canada, 19350 22nd Ave
Surrey, BC V3Z 3S6 CANADA
(604) 547-2100
salesinfo@dovertwg.com
07 2020

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TWG PullMaster PM50 and is the answer not in the manual?

Questions and answers

Related Manuals for Dover TWG PullMaster PM50

Summary of Contents for Dover TWG PullMaster PM50

  • Page 1 THE LOGICAL CHOICE INSTRUCTION AND PARTS MANUAL MODEL PM50 PLANEMATIC DRIVE TWG Headquarters, 11135 S TWG Canada, 19350 22nd Ave James Ave Jenks, OK 74037 USA Surrey, BC V3Z 3S6 CANADA (918) 298-8300 (604) 547-2100 salesinfo@dovertwg.com salesinfo@dovertwg.com READ THIS MANUAL BEFORE INSTALLING, OPERATING OR SERVICING THIS PRODUCT.
  • Page 2 Effective 2011/10/01 UPERSEDES RIOR ARRANTIES LIMITED WARR ANTY 50130-0 Seller warrants that each article (whether Gear Drive Products, Brake Products and/or Winch Products, all of which are covered hereunder) sold under this order shall at the time of shipment (i) conform to applicable specifications, and (ii) be free from defects in material and workmanship during normal and ordinary use and service (the "Warranty").

  • Page 3: Safety Recommendations

    SAFETY RECOMMENDATIONS WARNING FAILURE TO COMPLY WITH THE FOLLOWING SAFETY RECOMMENDATIONS AND LOCAL RULES AND REGULATIONS COULD RESULT IN PROPERTY DAMAGE, SEVERE INJURY OR DEATH. Do not install, operate or service Planematic drive before reading and understanding manufacturer's instructions. The Planematic drive described herein is not designed for operations involving lifting or moving personnel. Do not lift or carry loads over people.
  • Page 4 DESCRIPTION OF THE MODEL PM50 The PULLMASTER Planematic drive is a high performance, highly efficient, planetary hydraulic drive with equal speed in both directions achieved by two planetary reductions. Automatic disc brake with static and dynamic function is spring applied and hydraulically released by the motor. The main components of this unit are: ✛...
  • Page 5 MODEL CODING FOR PLANEMATIC DRIVE MODEL PM50 P M 50 X - XX - XXX - XX X - X XXX BASIC UNIT P = Planematic drive TYPE OF UNIT M = Equal speed SIZE OF UNIT 50 = 50,000 lb-in output torque REDUCTION RATIO Used for non standard reduction ratios only TYPE OF BRAKE...
  • Page 6 OPTIONS REDUCTION RATIO: The reduction ratio of the standard PULLMASTER Planematic drive is 41.2:1. Drives with different reduction ratios and altered output performances are optionally available. TYPE OF BRAKE: The standard PULLMASTER Planematic drive output shaft rotates forward in clockwise direction as viewed from the motor end of the unit.

  • Page 7: Specifications

    SPECIFICATIONS Performance specifications are based on standard hydraulic motor and gear ratio. Performance specifications for Planematic drives supplied with optional motors and/or reductions are provided in attached supplement. MAXIMUM OUTPUT TORQUE: 50,000 lb-in 5649 Nm MAXIMUM OUTPUT RPM: 48 rpm PERMISSIBLE OPERATING PRESSURE: 2200 psi 152 bar...
  • Page 8 OVERHUNG LOAD RATING PG-50-OH The magnitude and location of a load is dependent on the following factors: SF = service factor (Table A) AF = application factor (Table B) a = bearing geometry constant = -3.10 T = basic thrust or tension load = 25,300 c = basic load constant = 51,000 L = allowable overhung load in lbs.

  • Page 9: Performance Graphs

    PERFORMANCE GRAPHS PG-PM50 OUTPUT TORQUE VS. OIL PRESSURE OUTPUT TORQUE - Nm 1130 2260 3390 4519 5649 2200 2000 1600 1200 10,000 20,000 30,000 40,000 50,000 OUTPUT TORQUE - lb.in. OUTPUT RPM VS. OIL VOLUME OUTPUT RPM Performance graphs are based on standard hydraulic motor and gear ratio. PAGE 7 309 REV.
  • Page 10 TYPICAL HYDRAULIC CIRCUIT HC-PMH50-A 800 PSI [55 BAR] 2(US)GPM [8 L/MIN] CIRCULATION RETURN LINE (MUST GO DIRECT REQUIRED FOR MODELS TO RESERVOIR) SUPPLIED WITH EXTERNAL BRAKE RELEASE OPTION CIRCULATION SUPPLY LINE PM50: 3.5 (US) GPM [13 LPM] PH50: 4.5 (US) GPM [17 LPM] EXTERNAL CIRCULATION MODELS ONLY CONTROL VALVE...
  • Page 11 RECOMMENDATIONS HYDRAULIC FLUID: HYDRAULIC PRESSURE RELIEF: The hydraulic fluid selected for use with PULLMASTER The hydraulic circuit for the PULLMASTER Planematic Planematic drives should be a high grade, petroleum drive requires a pressure relief set at the operating based fluid, with rust, oxidation and wear resistance. pressure (see SPECIFICATIONS).

  • Page 12: Installation Instructions

    INSTALLATION INSTRUCTIONS DANGER FAILURE TO FOLLOW INSTALLATION INSTRUCTIONS WILL RESULT IN PROPERTY DAMAGE, SEVERE INJURY OR DEATH. To ensure satisfactory operation, the PULLMASTER Planematic drive must be properly installed. Observe the following installation instructions: 1) The Planematic drive mounting structure must be strong enough to withstand operating torques without excessive deflection.
  • Page 13 OPERATING INSTRUCTIONS DANGER FAILURE TO FOLLOW INSTALLATION INSTRUCTIONS WILL RESULT IN PROPERTY DAMAGE, SEVERE INJURY OR DEATH. Verify proper installation, acceptable system back pressure and adequate brake circulation flow before operating the Planematic drive. 1) The standard Planematic drive brake applies only in counterclockwise rotation as viewed from the motor end of the unit.

  • Page 14: Troubleshooting

    TROUBLE SHOOTING GENERAL: Typical Planematic drive operating problems are caused by a malfunctioning hydraulic system. Verify hydraulic pressure and flow at the drive motor are as specified before dismounting or disassembling Planematic. IMPORTANT: Ensure that the hydraulic system reservoir is full and that the system pump is running at full rpm before doing any system checks.
  • Page 15 TROUBLE SHOOTING CONTINUED PROBABLE CAUSE FAILURE Brake will not hold load. Hydraulic system back pressure SPECIFICATIONS. Refer to procedure described in TROUBLE SHOOTING - HYDRAULIC SYSTEM PRESSURE AND PLANEMATIC TORQUE to verify system back pressure at motor. Brake piston release oil being trapped by hydraulic system control valve.
  • Page 16 SERVICE INSTRUCTIONS GENERAL: Before attempting disassembly of the PULLMASTER Model PM50 Planematic drive, the following instructions for disassembly and reassembly should be read and understood. It is suggested that all expendable parts, such as O-rings and oil seals, are not reused on reassembly. It is therefore important to have a Planematic seal kit (Part No.
  • Page 17 SERVICE INSTRUCTIONS CONTINUED NOTE: Pocket seals, body seals, and ring seals in the hydraulic motor assembly are not part of the PULLMASTER Planematic drive seal kit. The seal kit for the hydraulic motor can be ordered from the factory under Part No. 23121. REMOVAL OF HYDRAULIC MOTOR ASSEMBLY: If disassembly of the hydraulic motor is not necessary, proceed as follows: 1) Remove 12 hex capscrews item 821, together with lockwashers item 823, from motor adaptor item 800.
  • Page 18 SERVICE INSTRUCTIONS CONTINUED 14) Proceed to BRAKE DISASSEMBLY CONTINUED instructions. DISASSEMBLY OF BRAKE ASSEMBLY WITH BRAKE EFFECTIVE IN BOTH DIRECTIONS: Refer to PARTS REFERENCE on page 26 and BRAKE GROUP drawing G1064 on page 27. 1) Remove connecting shaft item 600. 2) Remove brake hub item 720, with ball bearing item 407.
  • Page 19 SERVICE INSTRUCTIONS CONTINUED DISASSEMBLY OF FINAL DRIVE AND OUTPUT SHAFT ASSEMBLY: If final drive or output shaft assembly requires service or repair, disassemble as follows: 1) Remove final sungear item 340, from center of three final planet gears item 320. 2) Pull out final planet hub assembly and inspect for wear or damage.
  • Page 20 SERVICE INSTRUCTIONS CONTINUED REASSEMBLY OF BRAKE HOUSING ASSEMBLY: Reassemble brake housing assembly by reversing disassembly procedure. 1) Install new, well-greased O-rings item 751 and 753, into glands of brake piston item 750. 2) Slide brake piston into brake housing with holes for brake springs facing out of brake housing (see BRAKE GROUP drawing).
  • Page 21 SERVICE INSTRUCTIONS CONTINUED REASSEMBLY OF BRAKE ASSEMBLY WITH BRAKE EFFECTIVE IN BOTH DIRECTIONS: Refer to PARTS REFERENCE on page 26 and BRAKE GROUP drawing G1064 on page 27. 1) Install internal gear item 430, into spring stopper item 770, and fasten with retaining ring item 772. 2) Install spring stopper item 770, onto brake housing item 700, using six capscrews item 771, and lockwashers item 773.
  • Page 22 SERVICE INSTRUCTIONS CONTINUED - Ensure that circulation supply flow is being supplied to and vented from brake housing. If an internal circulation model, fill with hydraulic oil through one of three filler / drain ports before running. - Run Planematic drive in hoisting direction, with no load, at reduced speed (approximately 30% of maximum hydraulic volume).

  • Page 23: Recommended Maintenance

    RECOMMENDED MAINTENANCE In order to maintain the PULLMASTER Planematic drive in peak operating condition at all times, it is recommended that the following preventive maintenance procedure is carried out every 12 months or 500 operating hours, whichever occurs first. Disconnect all hydraulic connections and remove the Planematic drive from its mounting. Disassemble the Planematic drive in accordance with the SERVICE INSTRUCTIONS.
  • Page 24 PARTS REFERENCE - FINAL DRIVE QTY. PART NO. DESCRIPTION ITEM NO. 21394 FINAL HOUSING 25806 BEARING - TAPERED ROLLER SKF #32017 X 26006 WASHER KEYED TIMKEN K91517 OUTPUT SHAFT 25805 BEARING - TAPERED ROLLER SKF #33217 FLANGE CAPSCREW - HEX HEAD GRADE 5 FLANGE CAP LOCKWASHER 21398...
  • Page 25 FINAL DRIVE GROUP G1037-A Group drawings may reference more parts than are actually present in a specific assembly. Parts that are referenced on the drawing but are not on the PARTS REFERENCE list should be ignored. PAGE 23 309 REV. 990801...
  • Page 26 PARTS REFERENCE - BRAKE GROUP WITH BRAKE IN ONE DIRECTION ITEM NO. QTY. PART NO. DESCRIPTION 25339 O-RING -278 12"ID 1/8"CS 25264 CAPSCREW -HEX HEAD 3/8 - 16NC X 1.00 GRADE 5 25037 LOCKWASHER 3/8" 21180 PLANET HUB STOPPER 21395 PLANET HUB 21424 HUB EXTENSION...
  • Page 27 PARTS REFERENCE - BRAKE GROUP WITH BRAKE IN ONE DIRECTION G1039 Group drawings may reference more parts than are actually present in a specific assembly. Parts that are referenced on the drawing but are not on the PARTS REFERENCE list should be ignored. PAGE 25 309 REV.
  • Page 28 PARTS REFERENCE - BRAKE GROUP WITH BRAKE IN BOTH DIRECTIONS QTY. PART NO. DESCRIPTION ITEM NO. 25339 O-RING -278 12"ID 1/8"CS 25264 CAPSCREW -HEX HEAD 3/8 - 16NC X 1.00 GRADE 5 25037 LOCKWASHER 3/8" 21180 PLANET HUB STOPPER 21395 PLANET HUB 21424 HUB EXTENSION...
  • Page 29 PARTS REFERENCE - BRAKE GROUP WITH BRAKE IN BOTH DIRECTIONS G1064 Group drawings may reference more parts than are actually present in a specific assembly. Parts that are referenced on the drawing but are not on the PARTS REFERENCE list should be ignored. PAGE 27 309 REV.
  • Page 30 PARTS REFERENCE - MOTOR GROUP QTY. PART NO. DESCRIPTION ITEM NO. 21390 MOTOR ADAPTOR 25310 O-RING -012 3/8"ID 1/16"CS 25370 PIPE PLUG 1/16 - 27 NPT 25040 PIPE PLUG 1/8 - 27 NPT 25118 CAPSCREW - HEX HEAD 3/8 - 16NC X 1.25 GRADE 5 25037 LOCKWASHER 3/8"...

  • Page 31: Motor Group

    MOTOR GROUP G1033-A Group drawings may reference more parts than are actually present in a specific assembly. Parts that are referenced on the drawing but are not on the PARTS REFERENCE list should be ignored. PAGE 29 309 REV. 031006...
  • Page 32 TYPICAL ASSEMBLY DRAWING 309 REV. 031006 PAGE 30...

  • Page 33: Installation Drawing

    INSTALLATION DRAWING I1018D PAGE 31 309 REV. 031006...
  • Page 34 APPENDIX A OUTPUT SHAFT CODE ITEM PART DESCRIPTION PART NUMBER OUTPUT SHAFT 21399 22375 21399 21399 21804 22165 150A 22203 FLANGE 21419 21805 (QTY. 2) CAPSCREW 25139 25139 25013 (5/8"-11NC X 1.5) (1/2"-13NC X 1.25) FLANGE CAP 21420 21420 22166 (QTY.
  • Page 35 APPENDIX B BRAKE CODE - 10 - 11 - 17 ITEM PART DESCRIPTION PART NUMBERS 20849 20849 20849 20849 22457 & 24457 & SHUTTLE 22444 22444 ORIFICE 21483 21483 21483 21483 PLUG 1/8-27 NPT 25040 25040 25040 25040 25040 25040 PIPE PLUG 1/8-27 NPT 25040...

  • Page 36: Bolt Torque Chart

    BOLT TORQUE CHART TORQUE TORQUE BOLT DIAMETER Lb-ft Inches 5/16 7/16 9/16 1085 1000 1356 1200 1627 1500 2034 NOTE: Unless otherwise specified, torque bolts per above chart. 309 REV. 990801 PAGE 34...
