Daikin EWYA004D2V3P Installer's Reference Manual page 181

EWAA004~008D + EWYA004~008D
Packaged air-cooled water chillers
and packaged air to water heat pumps
4P688013-1B – 2022.09
a WLAN cartridge
b Router
c Smartphone + app
Configuration
To configure the ONECTA app, follow the in-app instructions. While doing this, the
following actions and information are needed on the user interface:
Mode: Turn AP mode ON (= WLAN adapter active as access point) or OFF.
# Code
[D.1] N/A
Reboot: Reboot the WLAN cartridge.
# Code
[D.2] N/A
WPS: Connect the WLAN cartridge to the router.
# Code
[D.3] N/A
INFORMATION
You can only use this function if it is supported by the software version of the WLAN,
and the software version of the ONECTA app.
Remove from cloud: Remove the WLAN cartridge from the cloud.
# Code
[D.4] N/A
Home network connection: Read out the status of the connection to the home
network.
The WLAN cartridge needs to be inserted in the
user interface. See the installation manual of the
WLAN cartridge.
Field supply.
The ONECTA app needs to be installed on the
user's smartphone. See:
http://www.onlinecontroller.daikineurope.com/
Description
Enable AP mode:
▪ No
▪ Yes
Description
Reboot the gateway:
▪ Back
▪ OK
Description
WPS:
▪ No
▪ Yes
Description
Remove from cloud:
▪ No
▪ Yes
11 Configuration
|
Installer reference guide
181
