Chapter 23: D Registers (Holding Registers)
Register
No.
D5331 OU.H
D5332 OU.L
RET.H
D5335
RET.L
D5336
D5337 to D5340
OU.A
D5341
D5343 RET.A
D5344 to D5400
23-62
Description
100% segmental point of OUT
current output
0% segmental point of OUT current
output
100% segmental point of RET
current output
0% segmental point of RET current
output
OUT current output range
RET current output range
Range and meaning of value
-100.0 to 200.0%
0: 4-20 (4 to 20 mA)
1: 0-20 (0 to 20 mA)
2: 20-4 (20 to 4 mA)
3: 20-0 (20 to 0 mA)
