Function of Each Menu
PPC Manual Revision 1
Menu symbol
Operation mode (STOP/RUN switch, REMOTE/LOCAL switch, Auto-tuning
MODE
switch, SP number selection, etc.)
The parameters in the menu of the following table indicate the parameters to set the
functions necessary for operation. The symbol in parentheses are shown on Group
display.
Menu symbol
CS
SELECT parameter
SP SP and alarm setpoint
SPS
SP-related function
ALRM Alarm function
PVS
PV-related function
PID PID setting
Super, Super 2, Sample PI control, non-linear PID control, anti-reset windup,
TUNE
output velocity limiter, and manual preset output
ZONE Zone control
SP (LP2)
SP and alarm setpoint (Loop 2)
SPS (LP2) SP-related function (Loop 2)
ALRM (LP2)
Alarm function (Loop 2)
PVS (LP2) PV-related function (Loop 2)
PID (LP2)
PID setting (Loop 2)
Super, Super 2, non-linear PID control, anti-reset windup, output velocity
TUNE (LP2)
limiter, manual preset output (Loop 2)
ZONE (LP2)
Zone control (Loop 2)
PPAR Not used
PYS1 (1)
10-segment linearizer 1
PYS2 (2) 10-segment linearizer 2
PYS3 (3)
10-segment linearizer 3
PYS4 (4) 10-segment linearizer 4
Chapter 15: Parameter Settings
Function
Function
15-3
