Chapter 5: Input Setting Functions
5-4
(Continued)
Parameter
Name
symbol
Maximum value of PV
input range
RH
(Physical
quantity)
Maximum value of
RSP remote auxiliary
analog input range
Minimum value of PV
RL input range
(Physical
Minimum value of RSP
quantity)
remote auxiliary analog
input range
PV input scale decimal
point position
SDP
RSP remote auxiliary
(Scaling)
analog input scale
decimal point position
Maximum value of PV
input scale
SH
Maximum value of
(Scaling)
RSP remote auxiliary
analog input scale
Minimum value of PV
input scale
SL
Minimum value of RSP
(Scaling)
remote auxiliary analog
input scale
P.UNI Control PV input unit
Control PV input
P.DP
decimal point position
Maximum value of
P.RH
control PV input range
Minimum value of
P.RL
control PV input range
Note1: In Cascade control, the LP2 lamp is lit while the Loop-2 parameter is displayed.
Display
Setting range
level
Depends on the input type.
- For temperature input -
Set the temperature range
EASY that is actually controlled.
(RL<RH)
- For voltage / current input -
Set the range of a voltage
/ current signal that is
applied.
The scale across which the
voltage / current signal is
actually controlled should
EASY
be set using the maximum
value of input scale (SH)
and minimum value of input
scale (SL). (Input is always
0% when RL = RH.)
EASY
Same as RH
EASY
0: No decimal place
EASY
1: One decimal place
2: Two decimal places
3: Three decimal places
EASY
4: Four decimal places
EASY
-19999 to 30000, (SL<SH),
| SH - SL | ≤ 30000
EASY
EASY
-19999 to 30000, (SL<SH),
| SH - SL | ≤ 30000
EASY
-: No unit
C: Degree Celsius
-: No unit
- -: No unit
- - -: No unit
F: Degree Fahrenheit
0: No decimal place
1: One decimal place
STD
2: Two decimal places
3: Three decimal places
4: Four decimal places
-19999 to 30000, (P.RL<P.RH),
| P.RH - P.RL | ≤ 30000
Menu symbol
PV
RSP
PV
RSP
PV
RSP
PV
RSP
PV
RSP
MPV
