- Page 1 UH835S Series UH850 Series UH850S Series Handheld UHF-CB Transceiver For more exciting new products please visit our website: Australia: www.uniden.com.au...
- Page 2 Warning WATERPROOF: IPX7/JIS7 Uniden’s UH835S/UH850/UH850S radio is designed to meet the water proofing standard of IPX7/JIS7. This Means: Being defined as having no ingress of water when immersed at 1 metre for 30 minutes. The radio will only meet this rating if fully assembled and all rubber seals and covers are well maintained and correctly fitted.
-
Page 3: Table Of Contents
Monitor CTCSS Busy Channel Lock-out (BCL) Call Tone Roger Beep Key Beep Scramble Keypad Lock Backlighting Voice Enhancer (EOL) Setting CTCSS Codes and Frequencies DCS Codes Table UHF-CB Channel Guidelines UHF-CB Channels and Frequencies Warranty Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 4: Introduction
The radio meets waterproof (IPX7/JIS7) specifications only when the battery, the antenna and accessory MIC jack cap are correctly installed. The radio won't retain its waterproof rating when the accessory Speaker MIC/Earphone MIC are connected. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 5: Included In Your Package
VOX Earpiece MIC. (EM-800) Owner’s Manual Cigarette Cradle Charger (CK-850) Magnetic Antenna (AT-820) Magnetic Antenna manual Swivel-Type Belt Clip Carry Case If any of these items are missing from the box, contact your place of purchase, immediately. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 6: Controls And Indicators
Key Lock System SCAN [OS/GS/MS] key Master Scan Scramble UP and DOWN Keys Battery Indicator Priority Watch 10 LED Scanning High Power 11 MENU [MEM] Key 12 PTT KEY Busy Channel 13 SMART KEY Lockout Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 7: Getting Started
Input Voltage (Cigarette Lead Charger): +12VDC to NOTE +24VDC. If Charge LED didn’t light up, please confirm the above temperature. Attaching the Antenna Attach the antenna to the radio. Be sure the antenna is firmly seated. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 8: Attaching The Battery Pack
Slide the belt clip into the catch until it snaps into place. To Remove the Belt Clip: Pinch and hold the belt clip latch and then slide the belt clip up and out of the catch. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 9: Charging The Battery Pack
• You can monitor incoming calls while the radio is in the drop-in charger. UH850S-2TP comes with dual desktop charger, it allows you to charge two radios at once. Do not charge the standalone battery pack with the Drop-In Charger (DT850D). NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 10: Battery Level Display
- up to 30 hours (Low Power*)/up to 18 hours (High Power) UH835S (2000mA battery) - up to 27 hours (Low Power*)/up to 18 hours (High Power) *This is based on the following Duty Cycle: Transmit (Low Power) Receive Stand-by Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 11: Led Status
Green Receiving Signal Transmitting signal Accessory Jack Cover Make sure the Accessory Jack Cover is rmly pushed in to maintain submersible rating. Connecting the SPKR/MIC Release the Accessory Jack Cover to plug in the SPKR/MIC. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 12: Operation
Press [MENU/MEM] 2 times. Sq and the current squelch level will ash on the display. 2. Use to change the squelch level from Auto/1 to 5. 3. Press & hold [MENU/MEM] to save and exit. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 13: Selecting Channel
45° angle away from your head. Speak in a clear, normal conversational voice. 4. When you have finished speaking, release [PTT] and listen for a response then TX disappears on the LCD. LED lights green while receiving a signal. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 14: To Operate In Duplex Mode
CH41-CH48 when duplex is selected. 3. Press & hold [ to save and exit. MENU/MEM] Contact your retailer for a list of repeaters available in your area. NOTE Operation with the aid of a Repeater Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 15: Transmit Power Select
SCAN Memories; one for Open Scan (OS) mode and the other for Group Scan (GS) mode, to give you flexibility and allow you to use the radio more effectively. Group Scan and Master Scan modes share the same SCAN Memory. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... - Page 16 Press and hold the [SCAN| OS/GS/MS] key. The default scan mode is Open Scan. OS (Open Scan) Press and hold the [SCAN| OS/GS/MS] key. GS (Group Scan) Press and hold the [SCAN| OS/GS/MS] key. MS (Master Scan) Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S...
-
Page 17: Open Scan (Os) Mode
GS and M.SCAN icons. NOTE If SCAN is deactivated while on an active channel, the radio will stay on that active channel. If no channels are active, the radio will reinstate the starting channel. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 18: Group Scan (Gs) Mode
If scanning stops on a channel which is not a Priority Channel, UHF CB Radio will continue monitoring the Priority Channel for activity while listening to the active one. To select GS scan mode, Press and hold the [SCAN| OS/GS/MS] key. GS icon appears on the display. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 19: Master Scan (M.scn) Mode
Master Scan to work effectively each radio in the group must have the same channels in its GS memory. To add/remove channels from GS SCAN Memory, refer the section above. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... - Page 20 P-: Master Scan uses current CH in GS memory P1: Master Scan uses CH09-20 in GS. P2: Master Scan uses CH21-30, 39, 40 in GS. P3: Master Scan uses CH49-60 in GS. P4: Master Scan uses CH61-70, 79, 80 in GS. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S...
- Page 21 5. Press and hold the [ to save and exit from the Menu MENU/MEM] Mode. If a button is not pressed within 10 seconds the UHF CB Radio will automatically exit the Menu Mode. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S...
-
Page 22: Priority Channel
1. Press [MENU/MEM] 7 times. PRI and current channel setting ashes. 2. Press to select the desired channel. 3. Press & hold [MENU/MEM] to save and exit. Recalling the Instant Channel Press [S] when Smart Key is set to Instant Channel function. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 23: Monitor
1. Select desired channel. 2. Press [MENU/MEM] 3 times. DCS/CTCSS setting ashes. 3. Press to change the selection. 4. Press & hold [MENU/MEM] to save and exit. Select oF to turn DCS/CTCSS off for the selected channel. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 24: Dcs
1. Press [MENU/MEM] 10 times. VOX setting flashes. 2. Press to select the desired setting. The 6 VOX levels are from 1 (low sensitivity) to 5 (high sensitivity) and Off. 3. Press & hold [MENU/MEM] to save and exit. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 25: Busy Channel Lock-Out (Bcl)
3. Press & hold [MENU/MEM] to save and exit. Current regulations require calling tones to be restricted to one transmission per minute. If a second transmission is attempted within one minute then an error tone will sound. NOTE Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 26: Roger Beep
This prevents users without descrambler equipment or a compatible unit from understanding the conversation. Select desired channel. Scr appears when Scramble setting is from 1 to 5. 1. Press [MENU/MEM] 4 times. The Scramble setting flashes. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 27: Keypad Lock
Choose from 4 different receive audio level settings to provide a natural Voice Enhancer for super clarity and performance. Press [S], when in Smart key EQL mode, to change the setting between; Off(Normal) /L1(Bass) /L2(Midrange) /L3(High) Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 28: Ctcss Codes And Frequencies
71.9 141.3 74.4 146.2 77.0 151.4 79.7 156.7 82.5 162.2 85.4 167.9 88.5 173.8 91.5 179.9 94.8 186.2 97.4 192.8 100.0 203.5 103.5 210.7 107.2 218.1 110.9 225.7 114.8 223.6 118.8 241.8 123.0 250.3 127.3 Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 29: Dcs Codes Table
DCS Codes Table DCS Code DCS Code DCS Code Code No. Code No. Code No. (Octal) (Octal) (Octal) Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 30: Uhf-Cb Channel Guidelines
The above situations are not a fault of the radio but a symptom of mixed wideband and narrowband radios in current use. It is expected that as older wideband radios are phased out this issue will be eliminated. Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... -
Page 31: Uhf-Cb Channels And Frequencies
477.300 (CH36) 477.050 476.575 477.325 (CH37) 477.075 476.600 477.350 (CH38) 477.100 476.625 477.125 476.650 477.150 476.675 477.175 476.700 477.200 476.725 477.225 476.750 477.250 476.775 477.275 476.800 477.300 476.825 477.325 476.850 477.350 476.875 477.375 476.900 477.400 Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S... - Page 32 477.0625 476.5875 477.3375 (CH 77) 477.0875 476.6125 477.3625 (CH 78) 477.1125 476.6375 477.1375 476.6625 477.1625 476.6875 477.1875 476.7125 477.2125 476.7375 477.2375 476.7625 477.2625 476.7875 477.2875 476.8125 477.3125 476.8375 477.3375 476.8625 477.3625 476.8875 477.3875 476.9125 477.4125 Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S...
-
Page 33: Warranty
IMPORTANT: Satisfactory evidence of the original purchase is required for warranty service Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor: The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden”). - Page 34 Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the address shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim.
- Page 35 Handheld UHF-CB Transceiver UNIDEN UH835S/UH850/UH850S...
- Page 36 THANK YOU FOR BUYING A UNIDEN PRODUCT. © 2018 Uniden Australia Pty Limited. Printed in Vietnam. U01UT967ZZE(0)
