- Page 1 UH8080S Remote Speaker MIC UHF CB Transceiver For more exciting new products please visit our website: Australia: www.uniden.com.au...
-
Page 2: Table Of Contents
Contents Introduction Controls & Connectors Indicators Included with your UH8080S Transceiver Optional Accessories Connecting the Microphone Slide Mount Bracket Mounting the MIC Hanger Operation Turning on the Power Setting the Auto Squelch Selecting a Channel Channel Banks - Using the POLICE button... - Page 3 Turning Instant Replay On/Off Close Call RF Capture Using Close Call Selective Calling Programming the Selcall ID for your UH8080S Storing Selcall IDs of other users to the ID Memory Tone Calling (Making a Selcall Call) Receiver Quiet (TSQ) Mode...
-
Page 4: Introduction
Introduction The Uniden UH8080S is designed to provide you with years of trouble free service. Its rugged components and materials are capable of withstanding harsh environments. Please read this Operating Manual carefully to ensure you gain the optimum performance of the unit. -
Page 5: Controls & Connectors
Controls & Connectors Base (Front & Rear) UH8080S EXT.SP. ANT. DC 13.8V DC 27.6V Remote LCD Speaker MIC UNIDEN UH8080S UHF CB Transceiver... - Page 6 SQL - Squelch Button POWER - Power Button REPLAY - Replay Button MENU - Menu Button - Move selection right /ENTER - Enter Button - Move selection left - Select Up and Down Buttons MICROPHONE RJ45 type plug SPEAKER Front MIC Jack Cover UNIDEN UH8080S UHF CB Transceiver...
-
Page 7: Indicators
DCS/CTCSS - DCS/CTCSS selected MON/SQT - Flashing: Monitor/ Tight Squelch DCS/CTCSS Code Number /Extra RX Channel Indicator INST - Instant Channel TSQ - Tone Squelch enabled DUAL/HOLD - Dual Watch/Hold SCAN - Scan mode Signal Power Level UNIDEN UH8080S UHF CB Transceiver... -
Page 8: Included With Your Uh8080S Transceiver
Included with your UH8080S Transceiver Remote LCD Speaker Owner’s Manual Microphone Hanger with Microphone screws, washers (RM880) Slide Mount Bracket, Extension Cable DC Power Cord Guide Rails and (EC770) with fuse Screws Mounting Bracket, Adaptor Cable Mounting Screws, Washer Stars And Screws UNIDEN UH8080S UHF CB Transceiver... -
Page 9: Optional Accessories
Optional Accessories • UHF Antenna • External Speaker DECT Wireless Speaker Microphone (MK800W) Visit the UH8080S page on the website for more information on the availability of optional accessories: www.uniden.com.au for Australia UNIDEN UH8080S UHF CB Transceiver... -
Page 10: Connecting The Microphone
Disconnecting the MIC from the MIC Jack Pull back the rubber cover and move it down along the cord. Using the flat blade of a screwdriver or similar object carefully push the lock tab of the MIC plug towards the MIC cord and at the same time tug on the MIC cord to draw back the MIC plug. UNIDEN UH8080S UHF CB Transceiver... -
Page 11: Slide Mount Bracket
How to attach Slide Mount Bracket? When you unpack the box, ensure that you have the slide mount bracket, guide rails and the screws. Align the guide rails along the side of the base and insert them into the slots provided. Then use the screws to lock them securely in position. UNIDEN UH8080S UHF CB Transceiver... - Page 12 Slide Mount Bracket Slide the bracket along the guide rails to attach the bracket to the unit. Over the BASE unit Under the BASE unit UNIDEN UH8080S UHF CB Transceiver...
-
Page 13: Mounting The Mic Hanger
(not supplied) High quality Double-Sided tape can be found at good retail stores. Secure the front and back pieces of the MIC Hanger using the supplied binding screws. Locate a suitable mounting position. Apply high quality Double-Sided tape onto the flat area of the MIC Hanger back piece and then press firmly to the mounting position. UNIDEN UH8080S UHF CB Transceiver... - Page 14 2. Drill a 13mm hole at the MIC hanger location. 3. Thread the microphone plug through the hole and connect with the extension cable. 4. Mount the MIC Hanger over the hole and cable. 5. At the Radio: Connect the extension cable plug to the MIC Jack. Fit the rubber bushing over the MIC jack. UNIDEN UH8080S UHF CB Transceiver...
-
Page 15: Operation
Operation Turning on the Power Press and hold [POWER]. Low-Voltage/High-Voltage Alert The UH8080S can operate on 12VDC (13.8V) or 24VDC (27.6V) power supply, with the range between 10.2VDC to 28.8VDC. If the power supply voltage exceeds 28.8VDC, an alert tone sounds and HI DC flashes for 5 seconds. The power source must not exceed 32VDC otherwise permanent damage may occur to your radio, which may not be covered by the manufacturer’s warranty. NOTE If the input voltage falls below 10.2VDC, LO DC flashes for 5 seconds. The power turns off automatically if voltage falls below 9.0VDC. -
Page 16: Setting The Auto Squelch
SQL-2 - moderate sensitivity SQL-3 - medium sensitivity SQL-4 - minimum sensitivity (max/tight squelch) 1. Press [SQL]. The squelch setting flashes. 2. Press to change the setting. • If SQL-0 (squelch open) is selected then MON (monitor) icon flashes. • If SQL-4 (tight squelch) is selected then SQT icon flashes. • Selecting tight squelch mode may prevent the reception of weak signals. NOTE • High noise areas may still break the squelch. 3. Press [SQL] to store the setting. UNIDEN UH8080S UHF CB Transceiver... -
Page 17: Selecting A Channel
Operation Selecting a Channel Press to select the desired channel. Channel Banks - Using the POLICE Button The UH8080S has three banks (groups) of channels to select from; CB UHF CB + User programmable RX channels¹ Pre-programmed Police frequencies² FIRE Pre-programmed Fire & Ambulance frequencies² When the CB icon is showing the 80 UHF-CB and any user programmed RX channels will be available for selection or scanning. -
Page 18: Programming The Instant Priority Channel
Momentarily press [INST] to return to the Instant Channel. Press [INST] again to return to the previous channel. Transmitting The UH8080S transmits only on UHF-CB Channels. For your reference a list of the available channels, corresponding frequencies and guidelines for their use and selection is printed on p.47 - p.49. For Australia, Channels 05 and 35 are reserved for Emergency NOTE Calls. -
Page 19: Ctcss (Continuous Tone Coded Squelch System)
DCS (Digital Coded Squelch) DCS is a digital extension of CTCSS. It provides 104 extra, digitally coded, squelch codes that follow after the 38 CTCSS codes. CTCSS 1-38, followed by DCS 1-104. Follow the steps for setting a CTCSS code. Press until the DCS codes appear. Press [DCS/CTCSS] to set. The DCS icon and code will display. UNIDEN UH8080S UHF CB Transceiver... -
Page 20: Call Tone Function (Wake Up Tones)
In normal Simplex operation, your radio transmits on one particular frequency and receives on that same frequency. If there is a barrier that partially blocks your transmitted signal, the probability of another radio receiving the signal is very slim. Hills, tall buildings, metallic structures,...etc tend to act as a screen between radios. Standard Operation without the aid of a Repeater station. UNIDEN UH8080S UHF CB Transceiver... -
Page 21: Operating The Uhf Cb Radio In Duplex Mode
ON or OFF (standard channel numbering). 3. Press and hold [MENU] to save & exit from the menu mode. DUP icon displays when a selected channel is set to Duplex mode. • Only channels 01 - 08, and channels 41 - 48 are available for Duplex. • Check with your local Retailer for information on available repeaters. • If a button is not pressed within 10 seconds the UHF CB Radio will NOTE automatically exit the Menu Mode. UNIDEN UH8080S UHF CB Transceiver... -
Page 22: Scanning
Group Scan (GS) and Master Scan (M.SCN) (a special case of Group Scan). During SCAN the UH8080S only checks channels or frequencies that are in the SCAN Memory, which are indicated by the M (memory) icon. The UH8080S maintains two SCAN Memories; one for Open Scan (OS) mode and the other for Group Scan (GS) mode, to give you flexibility and allow you to use the radio more effectively. - Page 23 MS: Master Scan is ON with the current GS channel memory. Open/Group Scan is disabled. P1: Master Scan is ON with loading CH09-20 in GS. P2: Master Scan is ON with loading CH21-30, 39, 40 in GS. P3: Master Scan is ON with loading CH49-60 in GS. P4: Master Scan is ON with loading CH61-70, 79, 80 in GS. UNIDEN UH8080S UHF CB Transceiver...
-
Page 24: Open Scan (Os) Mode
To select OS Scan Mode: 1. Press [MENU] three times. The SCAN setting flashes. 2. Press to change the setting to OS. 3. Press and hold [MENU] to save and exit from the Menu mode. UNIDEN UH8080S UHF CB Transceiver... -
Page 25: Group Scan (Gs) Mode
1. Press [MENU] three times. The SCAN setting flashes. 2. Press to change the setting to GS. 3. Press and hold [MENU] to save & exit from the menu mode. If a button is not pressed within 10 seconds the UHF CB Radio will automatically exit the Menu Mode. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 26: Priority Watch
ON or OFF. 3. Press and hold [MENU] to save & exit from the menu mode. If SCAN is deactivated while it is tuned to an active channel, the UH8080S will stay on that active channel. If none of the channels are active, the UH8080S will reinstate the scan start channel. NOTE If OS/GS Scanning is initiated when there are no channels programmed in OS/GS memory, an error tone will be heard and scanning will not start (see Add/Remove Channels from SCAN Memory, p.22). -
Page 27: Busy Channel Lockout
ON or OFF. 3. Press and hold [MENU] to save & exit from the menu mode. If a button is not pressed within 10 seconds the UH8080S will automatically exit the Menu Mode. NOTE Roger Beep 1. Press [MENU] seven times. -
Page 28: Key Beep On/Off
ON or OFF. 3. Press and hold [MENU] to save & exit from the menu mode. If a button is not pressed within 10 seconds the UHF CB Radio will automatically exit the Menu Mode. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 29: Volume Sync
Scramble enables private communications by scrambling the voice signal. This prevents users without descrambler equipment or a compatible unit understanding the conversation. Select desired channel. 1. Press [MENU] 11 times. The Scramble setting flashes. 2. Press to change the setting between OFF, 1 (Scramble-1), 2 (Scramble-2). 3. Press and hold [MENU] to save & exit from the menu mode. For safety purposes Scramble is invalid on channel 5, 11 and 35. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 30: Backlight Colour
01 (low contrast) to 10 (high contrast). 3. Press and hold [MENU] to save & exit from the menu mode. If a button is not pressed within 10 seconds the UHF CB Radio will automatically exit the Menu Mode. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 31: Operation - Special Features
Operation - Special Features 100 User Programmable RX Channels The UH8080S has 100 receive only channels (CH81 to CH180) which can be programmed with frequencies ranging from 400-520MHz (in 12.5kHz steps). The extra RX channels only appear, as part of the CB channel bank, when a frequency has been programmed to a channel. There are three ways to programme RX channels;... -
Page 32: Store A Police/Fire Frequency To A Rx Channel
2. Change the RX channel using if desired. 3. Press and hold [ENTER]. A confirmation tone sounds to indicate the new channel is programmed. The RX channel number flashes. 4. If a name is desired press [SQL] twice to begin Alpha Tag edit (see manual programming above). 5. Press and hold [ENTER], or wait for 10sec, to exit programming mode. UNIDEN UH8080S UHF CB Transceiver... -
Page 33: Instant Replay
On. Press and hold [REPLAY] to turn Instant Replay On/Off. Two beep tones sound. Turn Instant Replay Off if you want to prevent the current 1 minute of recordings from being overwritten. UNIDEN UH8080S UHF CB Transceiver... -
Page 34: Close Call Rf Capture
Operation - Special Features Close Call RF Capture ™ The Close Call RF Capture feature sets the UH8080S so it detects and then displays the frequency of a nearby strong radio transmission. Close Call RF capture works great for finding frequencies at venues such as malls and sporting events. Close Call RF Capture doesn’t tune to a frequency to check for a transmission, instead it directly detects the presence of a strong, nearby signal and instantly tunes to the source’s frequency. The UH8080S only tries to find Close Call transmissions from 400-... -
Page 35: Using Close Call
3. Press and hold [HOLD] to unlock the currently displayed frequency. Two beeps sound. 4. Press [MENU] to resume Close Call RF Capture mode. • Close Call RF Capture feature is separate to and cannot be operated at the same time as SCAN or normal receive mode. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 36: Selective Calling
Therefore Selcall is a group feature used by groups with similarly set up radios. The UH8080S has a Selective Calling system. Exceptional features, like 10 Selcall ID Memories, Receiver Quieting, Tone Squelch Scanning, Tone and Group Calling make the UH8080S superior to other transceivers in its class. Receiver Quieting (Tone Squelch) When activated on individual UHF-CB channels (except for emergency CH05 and CH35), it automatically mutes the receiver audio circuit of the radio. It will stay in this Quiet mode as long as the Selcall tone code (Selcall ID) required to open the muting circuit is not received. -
Page 37: Programming The Selcall Id For Your Uh8080S
Selcall settings menu as follows: 1. Power Off the UH8080S. 2. Press and hold [POWER] and [MENU]. The UH8080S should turn on in the SELCALL Menu selection state (no tone will sound). Cd dispays to indicate the Call ID setting (factory default ID is 00000). -
Page 38: Tone Calling (Making A Selcall Call)
CAL will display when transmitting the Selcall. An acknowledge tone coming from the called radio will be received if you have successfully made contact. The acknowledge tone for the UH8080S is a succession of three low tone beeps. Receiver Quiet (TSQ) Mode Puts the receiver in the QUIET mode (also known as the Tone Squelch (TSQ) mode) for the selected channel. When activated, the transceiver prevents any unwanted... -
Page 39: To Activate/Deavtivate Tone Squelch (Tsq) On A Channel
Refer to p.44, ‘Alarm Mode’ for other alarm settings) and displays the CAL icon. c) Flashes the TSQ icon for about 20 seconds allowing you to use the PTT button. If you are not able to respond within the 20 second period, TSQ icon stops flashing and ‘QUIET’ mode resumes. The UH8080S can decode a Selcall call even though not in ‘QUIET’ mode. NOTE UNIDEN UH8080S UHF CB Transceiver... -
Page 40: Scanning Tone Squelched Channels
Scanning can be increased in many different ways. You can either decrease the number of channels to be scanned thus increasing the scanning speed – or – change some of the Selcall parameters (refer to NOTE ‘Selcall Programming’). UNIDEN UH8080S UHF CB Transceiver... -
Page 41: Group Calling
Operation - Special Features Group Calling The UH8080S has the capability to respond to Group Calling and to transmit Group Calling Codes. Group Calling allows you to call members of your group simultaneously. However, to do this, you need to follow a certain format (see below) when programming your TX Selcall Selcall ID Format To call Transmitter SELCALL ID 10 radios [X] [X] [X] [X] [A] 100 radios... -
Page 42: Selcall Settings
Period setting. Otherwise you will not be able to selectively call one another. NOTE The UH8080S allows you to select which Tone Period is best for you. The three most commonly used tone settings (40,70 or 100 mSec) are available. With the freedom to change this parameter, you can easily adapt to the existing system in your group without the inconvenience of having the unit serviced by the dealer. -
Page 43: Lead-In Delay Programming
Operation - Special Features Lead-in Delay Programming 1. Power Off the UH8080S. 2. Press and hold [POWER] and [MENU]. The SELCALL Settings Menu will display (no tone will sound). 3. Press [MENU] repeatedly to select the Lead-in Delay setting - which is indicated on the display as Ld. -
Page 44: Alarm Mode
Operation - Special Features Alarm Mode When a received code matches to your receiver Selcall ID the UH8080S will respond based on the Call Alarm mode. Call Alarm - Auto mode (Default) a) Transmit an Acknowledge tone to the Caller. -
Page 45: Selcall Tone Frequency List
71.9 141.3 74.4 146.2 77.0 151.4 79.7 156.7 82.5 162.2 85.4 167.9 88.5 173.8 91.5 179.9 94.8 186.2 97.4 192.8 100.0 203.5 103.5 210.7 107.2 218.1 110.9 225.7 114.8 233.6 118.8 241.8 123.0 250.3 127.3 UNIDEN UH8080S UHF CB Transceiver... -
Page 46: Dcs Codes Table
DCS Codes Table DCS Code DCS Code DCS Code Code No. Code No. Code No. (Octal) (Octal) (Octal) UNIDEN UH8080S UHF CB Transceiver... -
Page 47: Uhf Cb Channel Guidelines
The above situations are not a fault of the radio but a symptom of mixed wideband and narrowband radios in current use. It is expected that as older wideband radios are phased out this issue will be eliminated. UNIDEN UH8080S UHF CB Transceiver... -
Page 48: Uhf Cb Channels & Frequencies
477.300 (CH36) 477.050 476.575 477.325 (CH37) 477.075 476.600 477.350 (CH38) 477.100 476.625 477.125 476.650 477.150 476.675 477.175 476.700 477.200 476.725 477.225 476.750 477.250 476.775 477.275 476.800 477.300 476.825 477.325 476.850 477.350 476.875 477.375 476.900 477.400 UNIDEN UH8080S UHF CB Transceiver... - Page 49 477.0625 476.5875 477.3375 (CH 77) 477.0875 476.6125 477.3625 (CH 78) 477.1125 476.6375 477.1375 476.6625 477.1625 476.6875 477.1875 476.7125 477.2125 476.7375 477.2375 476.7625 477.2625 476.7875 477.2875 476.8125 477.3125 476.8375 477.3375 476.8625 477.3625 476.8875 477.3875 476.9125 477.4125 UNIDEN UH8080S UHF CB Transceiver...
-
Page 50: Warranty
IMPORTANT: Satisfactory evidence of the original purchase is required for warranty service Please refer to our Uniden website for any details or warranty durations offered in addition to those contained below. Warrantor: The warrantor is Uniden Australia Pty Limited ABN 58 001 865 498 (“Uniden Aust”). - Page 51 Procedure for obtaining warranty service: Depending on the country in which the Product was first purchased, if you believe that your Product does not conform with this warranty, you should deliver the Product, together with satisfactory evidence of your original purchase (such as a legible copy of the sales docket) to Uniden at the address shown below. You should contact Uniden regarding any compensation that may be payable for your expenses incurred in making a warranty claim. Prior to delivery, we recommend that you make a backup copy of any phone numbers, images or other data stored on your Product, in case it is lost or damaged during warranty service.
- Page 52 © 2014 Uniden Australia Pty Limited. Printed in Vietnam. U01UT957AZZ(0)
