4. LAN/WAN indicator
5. Signal indicator
6. Reset button
7. Nano SIM card slot
8. WPS button
9. Power button
10. External antenna port
11. Telephone port
12. LAN/WAN port
13. LAN port
14. Power connector
• On: the WAN or LAN port is connected.
• Off: the WAN or LAN port is not connected.
• 1 bar: weak signal strength.
• 2 bars: good signal strength.
• 3 bars: excellent signal strength.
• Off: no signal.
Use a paperclip to press the button for 3 seconds
to reset the device.
Insert a Nano SIM card in the slot.
Press the button for 3 seconds to enable the WPS
function. The WPS function will be automatically
disabled if a WPS connection is not established
within 2 minutes.
• Press for 3 seconds to power off your device.
• Press for 1 second to power on your device.
Install an external antenna to improve signal
reception.
Connect to a telephone to make or answer calls.
Used to connect to an internet source or wired
devices such as computers or switches.
Used to connect to wired devices such as
computers or switches.
Used to connect to the power adapter.
