Display Structure - Danfoss EKE Installation Manual

LED Alarm and Warning
2 Sec
Powe r
-/AC +/AC PE

Display Structure

ARROW UP
General features and warning
Plastic housing features
• DIN rail mounting complying with EN 60715
• Self-extinguishing V0 according to IEC 60695-11-10 and glowing/hot wire test at 960 °C according
to IEC 60695-2-12
© Danfoss | Climate solutions | 2023.07
Alarm/Warning LED indication
Valve position by LED indication
2 Sec
Valve open circuit or valve driver heat problem
CIRCUIT
EXIT
1 Sec
Normal valve operation
1 Sec
Valve type not defined
0 Sec
No Alarm/Warning A/&B
Alarm/Warning A or B
5 Sec initial boot
0 Sec
1 Valve closed
2 Valve closing
3 Valve idle on target
4 Valve idle on target
5 Valve opening
6 Valve open
ALARM
UNIT
TEXT/VALUE
ENTER
ARROW DOWN
AN433741508202en-000203 | 9
Power
