Danfoss EKE Installation Manual page 8

Cabling
Stepper valve connector
A1
A2
B1
B2
Not connected
• All valves are driven in a bipolar mode with a 24 V supply chopped to control the current
(Current driver).
• The stepper motor is connected to the "Stepper Valve" terminals (see terminal assign
ment) with a standard M12 connection cable.
• To configure stepper motor valves other than Danfoss stepper motor valves, the correct
valve parameters must be set as described in the Valve configuration section by
selecting user defined valve.
Power supply and
Battery input
Analog inputs
Sensor
Stepper valve
Digital input
Digital output
• The max. cable distance between the controller and the valve depends on many factors like
shielded/unshielded cable, the wire size used in the cable, the output power for the
controller and the EMC.
• Keep controller and sensor wiring well separated from mains wiring.
• Connecting sensor wires more than specified length may decrease the accuracy of
measured values.
• Separate the sensor and digital input cables as much as possible(at least 10cm) from the
power cables to the loads to avoid possible electromagnetic disturbances. Never lay power
cables and probe cables in the same conduit (including those in electrical panels)
© Danfoss | Climate solutions | 2023.07
ETS/KVS/CCM/ CCMT/CTR/ CCMT L
(Using Danfoss M12 Cable)
White
Black
Green
Cable length
Max 5m
Max 10m
Max 10m
Max 30m
Max 10m
Max 10m
Red
-
Wire size min/max (mm
AWG 24-12 (0.34-2.5 mm2)
Torque (0.5-0.56Nm)
AWG 24-16 (0.14-1.5mm2)
AWG 24-16 (0.14-1.5mm2)
AWG 24-16 (0.14-1.5mm2)
Torque (0.22-0.25Nm)
AWG 24-16 (0.14-1.5mm2)
AWG 24-16 (0.14-1.5mm2)
ETS 8M
ETS 6
Bipolar
Orange Orange
Yellow Yellow
Red Red
Black Black
- Grey
)
2
AN433741508202en-000203 | 8
