Danfoss EKE Installation Manual page 5

See below table with recommended connection terminals for driver function
Driver input
Voltage A / Voltage B
Current A / Current B
Voltage A / Current B
Current A / Volatge B
Mounting/Demounting
The unit can be mounted onto a 35 mm DIN rail simply by snapping it into place and securing it with
a stopper to prevent sliding. It is demounted by gently pulling the stirrup located in the base of the
housing.
Mounting :
© Danfoss | Climate solutions | 2023.07
Terminal to use - signal Input A
Ext. GND + PeA
GND + PeA
GND + PeA
GND + PeA
1
Terminal to use - signal Input B
Ext. GND + PeB
GND + PeB
GND + PeB
GND + PeB
2
3
"Click"
AN433741508202en-000203 | 5
