MAC3 HydroController HCW User Manual page 29

J6
J6
Termica motor
1
Thermal motor
2 12Vis
Nivel agua bajo
3
Low water level
4 12Vis
Flotador
5
Floatswitch.
6 12Vis
OFF
INVERTER
7 Gnd Irrig.
Zona Irrig. 1
8
Zone Irrig. 1
Zona Irrig. 2
9
Zone Irrig. 2
Zona Irrig. 3
10
Zone Irrig. 3
Istruzioni-HCMMMTTT-09022023 (Cod.620100007 Rev.16) EsEng (USA) MAC3.doc
J7
Zona Irrig. 4
11
Zone Irrig. 4
12 Gnd Irrig.
13
14
15
16
17
ON
18 Gnd CAN
19 CAN H
24 Vdc
(Multipress)
20 CAN L
24 Vdc
(Multipress)
24 Vdc
(Multipress)
J7
J8
24 Vdc
21
Multipress
22
23
-
R2 Max 2A 250Vac - Max 2A 30 Vdc
-
24
-
-
25
-
26
27
Config.
MultiBomba
Multipump R3 Max 2A 250Vac - Max 2A 30 Vdc
connection
28
29
30
TARJETA DE ESPANSION
EXPANSION BOARD
R2 R3
J8
CAN H
CAN L
-
R2 Config. NO
Config. R2 NO
R2 Config. NC
Config. R2 NC
R2 Config. COM
Config. R2 COM
-
R3 Config NO
Config. R3 NO
R3 Config. NC
Config. R3 NC
R3 Config.COM
Config. R3 COM
Conifig.
Multipump
29
