DEMO MANUAL DC2479A-A

PARTS LIST

ITEM QTY REFERENCE
Required Circuit Components
1 1 CIN1
2 4 CIN2, CIN3, CIN4, CIN5
3 4 COUT2, COUT4, COUT6, COUT8 CAP ., 470µF, 2.5V, POSCAP , F8 SANYO-D4D
4 1 C4
5 1 C7
6 3 C8, C9, C10
7 1 Q1
8 2 R1, R3
9 2 R2, R9
10 2 R4, R18
11 1 R11
12 1 R16
13 1 R19
14 1 U1
Additional Demo Board Circuit Components
1 8 COUT1, COUT3, COUT5, COUT7,
COUT11, COUT12, COUT13,
COUT14
2 0 COUT9, COUT10
3 0 C1, C3, C5, C11
4 0 R8, R10
5 2 R12, R14
6 0 R13
7 0 R20
Hardware: For Demo Board Only
1 9 E1-E7, E17, E18
2 0 E8-E14
3 1 JP1
4 2 J1, J3
5 2 J2, J4
6 4 J2, J4 (×2)
7 2 J2, J4
8 2 J2, J4
9 2 J5, J6
10 1 XJP1
6
PART DESCRIPTION
CAP ., 150µF, 25V, Aluminum Electr.,
CAP ., X5R, 22µF, 25V, 10%, 1210
CAP ., X5R, 2.2µF, 10V, 10%, 0603
CAP ., X5R, 0.1µF, 25V, 10%, 0603
CAP ., X7R, 1µF, 10V,10%, 0603
XSTR, SUD50N04-8M8P-4GE3 MOSFET
RES., 10, 1%,1/10W, 0603
RES., 121k, 1%,1/10W, 0603
RES., 10k, 1%,1/10W, 0603
RES., 1k, 1%,1/10W, 0603
RES., 0.01Ω, 1W, 2512
RES., 90.9k, 1%,1/10W, 0603
LTM4650EY#PBF , 16×16×5.01 BGA
CAP ., X5R, 100µF, 6.3V, 20%,1210
CAP ., OPT, SANYO-D4D
CAP ., OPT, 0603
RES., OPT, 0603
RES., 0Ω,1/10W, 0603
RES., OPT, 0603
RES., OPT, 2512
TESTPOINT, TURRET, .094"
TESTPAD SMD
HEADER, 3 PIN 2mm SINGLE ROW
JACK BANANA
STUD, TESTPIN
NUT, BRASS 10-32
RING, LUG #10
WASHER, TIN PLATED BRASS
CONN, BNC, 5 PINS
SHUNT 2mm
MANUFACTURER/PART NUMBER
SUN ELECT., 25CE150AX
MURATA, GRM32ER61E226KE15L
PANASONIC, 2R5TPF470M6L
MURATA, GRM188R61A225KE34D
AVX, 06033D104KAT2A
AVX, 0603ZC105KAT2A
VISHAY, SUD50N04-8M8P-4GE3
VISHAY, CRCW060310R0FKEA
VISHAY,CRCW0603121KFKEA
VISHAY, CRCW060310K0FKEA
VISHAY, CRCW06031K00FKEA
VISHAY, WSL2512R0100FEA
VISHAY, CRCW060390K9FKEA
LINEAR TECH., LTM4650EY#PBF
AVX, 12106D107MAT2A
OPT
OPT
OPT
VISHAY, CRCW06030000Z0EA
OPT
OPT
MILL-MAX, 2501-2-00-80-00-00-07-0
TESTPAD SMD
WURTH ELEKTRONIK, 620-003-111-21
KEYSTONE, 575-4
PEM KFH-032-10
ANY #10-32
KEYSTONE #10
ANY #10
CONNEX 112404
WURTH ELEKTRONIK, 608-002-134-21
