Initial Configuration - golmar 6502/G2+ Installer Manual

G2+

4. INITIAL CONFIGURATION

To configure a panel as a block
1
20-09-2017
09:27
Marcar el número de vivienda
Dial apartment number
o pulsar or press para mostrar la agenda to show name list
Access to the configuration by pressing
5 times in the indicated pushhbutton.
5
Address
Block
Ajustes de la placa
Door panel mode
Choose the Block mode with the
arrows and validate the selection.
If it is necessary to us another IP address on the panel, it can be set in a manual way. To do that, you must follow the before
described steps but, in the step 8 you must choose the
9
Address
Enter the desired IP address
for the door panel and press
Once all the previous steps are done, a confirmation screen will appear.
In systems with general panels, these must be programmed in the same way as described before but, in the step number 5 the
"General" option must be chosen.
You must finish the configuration process in the same way as if it was a block panel.
(*) It is reommended to change the installer code that is mentioned in this manual.
www.golmar.es
panel, do the following steps:
2
****
Introducir contraseña
Enter password
(*)Enter the installer code
through the keypad and validate it
6
Address
1
Ajustes de la placa
Enter block number (1 to 32)
Enter, through the keypad, the
block number "1" and press over
the validate option.
Manual mode,
10
192.168.1.2
Ajustes de la placa
Enter local IP address
Enter the subnet mask of the
door panel and press validate.
validate.
5
Address
General
Ajustes de la placa
Door panel mode
Choose the General mode with the
arrows and validate the election.
3
Settings
****
Menú de ajustes
Door panel
2718 Press the "Door panel" option
.
from the settings menu (1/4).
7
Address
1
Ajustes de la placa
Enter door panel number (1 to 4)
Enter through the numeric keypad the
panel number "1" and press validate
and then follow the steps described below:
11
Address
255.255.255.0
Ajustes de la placa
Enter Subnet Mask address
6
Address
1
Ajustes de la placa
Enter door panel number (1 to 4)
Enter through the numerical
keypad the number of
panel and press validate
4
Door panel
Ajustes de la placa
Address
Choose the "Address" option of the
door panel settings (1/5).
8
Address
Automatic
Ajustes de la placa
Network settings mode
Choose the automatic IP
assignment. In this way, the door
.
panel will take the
IP address.
Address
192.168.2.1
Ajustes de la placa
Enter Gateway address
Enter the Gateway address and
press validate.
general
6502/G2+
192.168.100.101
4
