  • Page 1 4x-785C User Manual PXI/PXIe Microwave Multiplexer Modules pickeringtest.com Issue 3.0, October 2023...
  • Page 2 © Copyright (2023) Pickering Interfaces. All Rights Reserved. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
  • Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

  • Page 4: Product Safety

    Product Safety Safety Symbols The following safety symbols may be used on the product and throughout the product documentation. Meaning/Description Symbol PROTECTIVE EARTH (GROUND) To identify any terminal which is intended for connection to an external conductor for protection against electric shock in case of a fault, or the terminal of a protective earth (ground) electrode.

  • Page 5: Table Of Contents

    Pre Operation Checks ..............................3.1 Hardware Installation ..............................3.2 Software Installation ..............................3.2 Testing Operation ................................3.3 Section 4 Programming Guide .................................4.1 Programming Options for Pickering PXI/PXIe Modules ..................4.1 Module Architecture ..............................4.2 Programming the Module ............................4.3 Using Pickering Drivers in LabVIEW ........................4.6 Section 5 Connector Information ..............................5.1 Section 6 Trouble Shooting ................................6.1...
  • Page 6 Contents Appendix A Relay Dimensional Drawings ............................A.1 Appendix B Mounting Bracket Information ............................B.1 Appendix C Part Number List ................................C.1 Page (vi)

  • Page 7: Warnings And Cautions

    Unused slots in the PXI/PXIe/LXI chassis are populated with blanking plates to prevent access to user I/O signals that may be present. Blanking panels are available to order from Pickering in a variety of slot widths. If the product is not used in this manner for example by using an extender card then additional care must be taken to avoid contact with exposed signals.

  • Page 8: Technical Specification

    SMA, SMA 2.9, SMA 2.4, SMA 1.85 or N-type for 50 Ω versions. Siemens 1.6/5.6 style connectors. These modules give you the highest RF and microwave performance available within a Pickering switching system. Although designed for microwave applications, they have many uses in the RF spectrum where extremely low insertion Single slot version loss and ultra high isolation are critical.
  • Page 9 PXI/PXIe Microwave Multiplexer 4x-785C Section 1 - Technical Specification MUX Bank 1 MUX Bank 1 Relay Cycle Counting To aid with module “health” monitoring all versions are provided with a relay cycle counting MUX Bank 1 MUX Bank 2 cycle feature. The number of MUX Bank 1 MUX Bank 2 operations per contact are stored...
  • Page 10 PXI/PXIe Microwave Multiplexer 4x-785C Section 1 - Technical Specification Remotely Mounted Microwave Multiplexer Versions 4x-785C pickering Single Slot Version 3 off Interface Cables 1.5m Length Remotely Mounted Microwave Multiplexers Interconnection Between 4x-785C Single Slot Version and Remotely Mounted Microwave Multiplexers Remote Mount Microwave Multiplexer (18-67 GHz) Range: •...
  • Page 11 Specifications Section 1 - Technical Specification 4x-785C General Multiplexer Information Relay Manufacturer: Radiall Configuration: SP6T or SP4T Microwave MUX with 1, 2 or 3 independent banks. LED Indicators: Multiplexers have blue LEDs to indicate a closed RF path. Operate Time: Typically 15 ms Maximum Cold Switch Voltage:...
  • Page 12 Specifications Section 1 - Technical Specification 4x-785C 18 GHz Unterminated & Terminated Versions Characteristic Impedance: 50 Ω Connectors: Bandwidth DC to 18 GHz Isolation: 80 dB (0-3 GHz) 70 dB (3-8 GHz) 60 dB (8-12.4 GHz) 60 dB (12.4-18 GHz) Insertion Loss: 0.2 dB (0-3 GHz) Typical Isolation (dB) - 18 GHz Unterminated Versions...
  • Page 13 Specifications 4x-785C Section 1 - Technical Specification 26.5 GHz Unterminated Versions Characteristic Impedance: 50 Ω Connectors: Bandwidth DC to 26.5 GHz Isolation: 80 dB (0-3 GHz) 70 dB (3-8 GHz) 60 dB (8-12.4 GHz) 60 dB (12.4-18 GHz) Typical Insertion Loss (dB) - 26.5 GHz 50 dB (18-26.5 GHz) Unterminated Versions Insertion Loss:...
  • Page 14 Specifications 4x-785C Section 1 - Technical Specification 26.5 GHz Terminated Versions Characteristic Impedance: 50 Ω Connectors: Bandwidth DC to 26.5 GHz Isolation: 80 dB (0-3 GHz) 70 dB (3-8 GHz) 60 dB (8-12.4 GHz) 60 dB (12.4-18 GHz) Typical Insertion (dB) Loss - 26.5 GHz 55 dB (18-26.5 GHz) Terminated Versions Insertion Loss:...
  • Page 15 Specifications Section 1 - Technical Specification 4x-785C 40 GHz Unterminated & Terminated Versions Characteristic Impedance: 50 Ω Connectors: SMA 2.9 Bandwidth DC to 40 GHz Isolation: 70 dB (0-6 GHz) 60 dB (6-12.4 GHz) 60 dB (12.4-18 GHz) 55 dB (18-26.5 GHz) 50 dB (26.5-40 GHz) Typical Isolation (dB) - 40 GHz Unterminated Versions Insertion Loss:...
  • Page 16 Specifications Section 1 - Technical Specification 4x-785C 50 GHz Unterminated & Terminated Versions Characteristic Impedance: 50 Ω Connectors: SMA 2.4 Bandwidth DC to 50 GHz Isolation: 70 dB (0-6 GHz) 60 dB (6-12.4 GHz) 60 dB (12.4-18 GHz) 55 dB (18-26.5 GHz) 50 dB (26.5-40 GHz) 50 dB (40-50 GHz) Insertion Loss:...
  • Page 17 Specifications 4x-785C Section 1 - Technical Specification 67 GHz Unterminated Versions Characteristic Impedance: 50 Ω Connectors: SMA 1.85 Bandwidth DC to 67 GHz Isolation: 70 dB (0-6 GHz) 60 dB (6-12.4 GHz) 60 dB (12.4-18 GHz) 55 dB (18-26.5 GHz) 50 dB (26.5-40 GHz) 50 dB (40-50 GHz) 50 dB (50-65 GHz)
  • Page 18 Specifications 4x-785C Section 1 - Technical Specification 67 GHz Terminated Versions Characteristic Impedance: 50 Ω Connectors: SMA 1.85 Bandwidth DC to 67 GHz Isolation: 70 dB (0-6 GHz) 60 dB (6-12.4 GHz) 60 dB (12.4-18 GHz) 55 dB (18-26.5 GHz) 50 dB (26.5-40 GHz) 50 dB (40-50 GHz) 50 dB (50-65 GHz)
  • Page 19 Specifications 4x-785C Section 1 - Technical Specification 2.5 GHz Unterminated Version Characteristic Impedance: 75 Ω Connectors: 1.6/5.6 Bandwidth DC to 2.5 GHz Isolation: 80 dB (0-1 GHz) 70 dB (1-2.5 GHz) Insertion Loss: 0.2 dB (0-1 GHz) 0.3 dB (1-2.5 GHz) VSWR: 1.2:1 (0-1 GHz) Typical Insertion Loss (dB) - 2.5 GHz 75 Ω...
  • Page 20 Specifications 4x-785C Section 1 - Technical Specification Mechanical Characteristics Power Requirements - 40-785C Front panel mounted multiplexers: +3.3 V +5 V +12 V -12 V • 40-785C Single unterminated versions (except 3 GHz) 0.13 A 0.01 A 0.75 A - 3 slot 3U PXI (CompactPCI card) Power Requirements - 42-785C •...
  • Page 21 Ordering Information 4x-785C Section 1 - Technical Specification Product Order Codes 4[A]-785C-[B][C][D][E] Interface 0 = PXI 2 = PXIe Type Options 4 = SP4T 50 Ω (SMA only) [Blank] = Panel Mount 5 = SP6T 50 Ω -T = Terminated & Panel Mount 7 = SP6T 75 Ω...
  • Page 22 Side View of the PXI Dual Unterminated Microwave Multiplexer Product Customization Pickering modules are designed and manufactured on our own flexible manufacturing lines, giving complete product control and enabling simple customization to meet very specific requirements. Customization can include: • Alternative relay types •...
  • Page 23 PXI/PXIe Microwave Multiplexer 4x-785C Section 1 - Technical Specification The 4x-785C is part of a range of switching modules suitable for RF and microwave applications. Pickering’s Range of PXI & PXIe Microwave Switching Modules Switch Type Banks Frequency Range Model No.

  • Page 24: Technical Description

    Section 2 - Technical Description Functional Description A functional block diagram is provided in Figure 2.1. The module is powered by +5V and +12V (PXI) or +3.3V and +12V (PXIe) supplies via PCI Bus connectors mounted on the mother board. The interface to the user test equipment is via the microwave relay’s SMA, N-type or 1.6/5.6 connectors.

  • Page 25: Mechanical Description

    Section 2 - Technical Description Mechanical Description The Microwave Multiplexer Module conforms to the 3U height (128mm) Eurocard standard and comprises the following: • CPCI Ejector Handle • Three, four or six slot width front panel (single slot for the remote -E option) •...

  • Page 26: Installation

    Modular products require installation in a suitable PXI/PXIe/LXI chassis. The module is designed for indoor use only. Pre-operation Checks (Unpacking) 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident.

  • Page 27: Hardware Installation

    If you are not a LabVIEW user you should choose the “full” version, and once that has been installed run the LabVIEW Runtime Engine installer via the shortcut on the Programs>>Pickering menu. In the absence of LabVIEW the Runtime Engine is required to support the Pickering Test Panels application.

  • Page 28: Testing Operation

    Figure 3.2 - General Soft Front Panel Icon A selector panel will appear, listing all installed Pickering PCI, PXI/PXIe or LXI switch cards and resistor cards. Click on the card you wish to control, and a graphical control panel is presented allowing operation of the card. Panels can be opened simultaneously for all the installed cards.
  • Page 29 Section 4 - Programming Programming options for Pickering Interfaces PXI/PXIe Modules For information on the installation and use of drivers and the programming of Pickering’s products in various software environments, please refer to the Software User Manual. This is available as a download from: pickeringtest.com/support/software-drivers-and-downloads...

  • Page 30: Module Architecture

    Section 4 - Programming Module Architecture The 40/42-785C is a 6 or 4-channel microwave multiplexer module available with one or two banks mounted on the front panel or one, two or three banks mounted remotely. In the default state, all channels are in the “off” position. Energising a particular channel number creates a signal path between the Com and the corresponding terminal number.

  • Page 31: Programming The Module

    Section 4 - Programming One sub-unit is used per bank to control the microwave multiplexer as shown below. Sub Unit Number Sub Unit Type Description MUX(6x1) + off SP6T Microwave Multiplexer Bank 1 MUX(6x1) + off SP6T Microwave Multiplexer Bank 2 MUX(6x1) + off SP6T Microwave Multiplexer Bank 3 MUX(4x1) + off...
  • Page 32 Section 4 - Programming Programming Bit / Signal Path Table For Triple Bank Versions 6-Channel Versions 4-Channel Versions Multiplexer Sub-Unit IVI Channel IVI Channel Bank Signal Path Signal Path Names Names Com to Ch1 comA chA1 Com to Ch1 comA chA1 Com to Ch2 comA...
  • Page 33 Section 4 - Programming Using PIPX40 setChannelState ViUInt32 sub_unit = 1; // Select Bank 1 pipx40_setChannelState(vi, sub_unit, 1, VI_ON); // Enables the Com to Ch1 signal path pipx40_setChannelState(vi, sub_unit, 2, VI_ON); // Releases the Com to Ch1 signal path // and enables the Com to Ch2 signal path pipx40_setChannelState(vi, sub_unit, 2, VI_OFF);...

  • Page 34: Using Pickering Drivers In Labview

    Section 4 - Programming Using Pickering Drivers In LabVIEW Most Pickering drivers include a LabVIEW wrapper to permit full operation of the Pickering product from the LabVIEW environment. These wrappers are normally installed to the current LabVIEW folder system during installation of the Pickering driver.
  • Page 35 Section 5 - Connectors pickering pickering Bank1 Bank2 40/42-785C-522 40/42-785C-521 40/42-785C-532 40/42-785C-531 40/42-785C-542 40/42-785C-541 40/42-785C-552 40/42-785C-551 40/42-785C-572 40/42-785C-571 40/42-785C-752 40/42-785C-751 Figure 5.1 - Microwave Multiplexer Module 40/42-785C SP6T Panel Mounted Non-terminated Versions: Connector Positions NOTE 1: Only the correct SMA connector series should be mated with these modules. The 40/42-785C range uses SMA, SMA-2.9 &...
  • Page 36 Section 5 - Connectors Bank1 Bank2 pickering pickering 40/42-785C-521-T 40/42-785C-522-T 40/42-785C-531-T 40/42-785C-532-T 40/42-785C-541-T 40/42-785C-542-T 40/42-785C-551-T 40/42-785C-552-T 40/42-785C-571-T 40/42-785C-572-T Figure 5.2 - Microwave Multiplexer Module 40/42-785C SP6T Panel Mounted Terminated Versions: Connector Positions NOTE 1: Only the correct SMA connector series should be mated with these modules. The 40/42-785C range uses SMA, SMA-2.9 &...
  • Page 37 Section 5 - Connectors pickering pickering Bank1 Bank2 40/42-785C-422 40/42-785C-421 40/42-785C-432 40/42-785C-431 40/42-785C-442 40/42-785C-441 40/42-785C-452 40/42-785C-451 40/42-785C-472 40/42-785C-471 Figure 5.3 - Microwave Multiplexer Module 40/42-785C SP4T Panel Mounted Non-terminated Versions: Connector Positions NOTE 1: Only the correct SMA connector series should be mated with these modules. The 40/42-785C range uses SMA, SMA-2.9 &...
  • Page 38 Section 5 - Connectors Bank1 Bank2 pickering pickering 40/42-785C-421-T 40/42-785C-422-T 40/42-785C-431-T 40/42-785C-432-T 40/42-785C-441-T 40/42-785C-442-T 40/42-785C-451-T 40/42-785C-452-T 40/42-785C-471-T 40/42-785C-472-T Figure 5.4 - Microwave Multiplexer Module 40/42-785C SP4T Panel Mounted Terminated Versions: Connector Positions NOTE 1: Only the correct SMA connector series should be mated with these modules. The 40/42-785C range uses SMA, SMA-2.9 &...
  • Page 39 Section 5 - Connectors pickering pickering 40/42-785C-561 40/42-785C-461 40/42-785C-561-T 40/42-785C-461-T Figure 5.5 - Microwave Multiplexer Module 40/42-785C Panel Mounted 3GHz Versions: Connector Positions NOTE: It is important that the N-type connector’s nut is properly tightened to the correct torque with an 18mm wrench.
  • Page 40 Section 5 - Connectors pickering pickering pickering 40/42-785C-xx1-E 40/42-785C-xx2-E 40/42-785C-xx3-E 40/42-785C-xx1-TE 40/42-785C-xx2-TE 40/42-785C-xx3-TE Figure 5.6 - Microwave Multiplexer Module 40/42-785C Remote Mounted Versions: Connector Positions NOTE 1: For versions with SMA connectors, only the correct connector series should be mated with these modules. The 40/42-785C range uses SMA, SMA-2.9 &...

  • Page 41: Trouble Shooting

    PCI configuration, highlighting any potential configuration problems. Specific details of all installed Pickering switch cards are included. All the installed Pickering switch cards should be listed in the “Pilpxi information” section - if one or more cards is missing it may be possible to determine the reason by referring to the PCI configuration dump contained in the report, but interpretation of this information is far from straightforward, and the support@pickeringtest.com...

  • Page 42: Maintenance Information

    For PXI modules which are supported in one of Pickering Interfaces’ Modular LXI Chassis (such as the 60-102B and 60-103B) no module software update is required. If the module was introduced after the LXI chassis was manufactured the module may not be recognized, in this case the chassis firmware may need upgrading.
  • Page 43 Appendix A Relay Dimensional Drawings 39.6mm SQ 44.5mm SQ 35.0mm 3.3mm Thru 27.0mm Figure A.1 - Dimensions for 18GHz / 26.5GHz / 40GHz / 50GHz / 67GHz Unterminated Relays - Applicable to Modules: 40/42-785C-52x-E 40/42-785C-53x-E 40/42-785C-54x-E 40/42-785C-55x-E 40/42-785C-57x-E pickeringtest.com Page A.1...
  • Page 44 Appendix A 57.15mm Sq 57.2mm Sq 45.75mm 4.35mm Thru 27.0mm Figure A.2 - Dimensions for 18GHz / 26.5GHz / 40GHz / 50GHz Terminated Relays Applicable to Modules: 40/42-785C-52x-TE 40/42-785C-53x-TE 40/42-785C-54x-TE 40/42-785C-55x-TE pickeringtest.com Page A.2...
  • Page 45 Appendix A 63.5mm 6 x M4 5.0mm 54.0mm 44.7mm Figure A.3 - Dimensions for 3GHz Unterminated & Terminated Relays Applicable to Modules: 40/42-785C-56x-E 40/42-785C-56x-TE pickeringtest.com Page A.3...
  • Page 46 Appendix B Mounting Bracket Information 90.0mm 4.4mm Thru 80.0mm 5.0mm X 90°, Near Side Rubber Boot 45.0mm 5.0mm X 90°, Far Side Clearance Area 71.7mm 68.5mm 18.5mm 12.0mm 2.5mm 100.0mm Figure B.1 Remote Mounting Bracket for 18GHz / 26.5GHz / 40GHz / 50GHz / 67GHz Unterminated Relays (Part No.
  • Page 47 Appendix B 90.0mm 4.4mm Thru 80.0mm 5.0mm X 90°, Near Side Rubber Boot 61.0mm 5.0mm X 90°, Far Side Clearance Area 71.7mm 68.5mm 18.5mm 12.0mm 2.5mm 100.0mm Figure B.2 Remote Mounting Bracket for 18GHz / 26.5GHz / 40GHz / 50GHz Terminated Relays (Part No.
  • Page 48 Appendix B 90.0mm 80.0mm 4.4mm Thru 68.0mm 5.0mm X 90°, Near Side 5.0mm X 90°, Far Side Rubber Boot Clearance Area 71.7mm 68.5mm 18.5mm 12.0mm 2.5mm 100.0mm 17.0mm Figure B.3 Remote Mounting Bracket for 3GHz Unterminated & Terminated Relays (Part No. 40-785A-561-TE-MB) For Use With Modules: 40/42-785C-x6x-E 40/42-785C-x6x-TE...
  • Page 49 Appendix C Part Number List The tables on the following pages show the complete list of part numbers for all the possible operating frequency, channel counts and bank number combinations for the 4x-785C microwave multiplexer range of modules. Product Order Codes - Panel Mounted Microwave Multiplexers 3 GHz, 50 Ω...
  • Page 50 Appendix C Product Order Codes - Remote Mounted Microwave Multiplexers 3 GHz, 50 Ω 18 GHz, 50 Ω 26.5 GHz, 50 Ω 40 GHz, 50 Ω 50 GHz, 50 Ω 67 GHz, 50 Ω 2.5 GHz, 75 Ω (N-Type) (SMA) (SMA) (SMA 2.9) (SMA 2.4)
