  • Page 1 40-562B User Manual PXI BRIC™ Multi-Slot Matrix Module pickeringtest.com Issue 1.0 June 2020...
  • Page 2 © COPYRIGHT (2020) PICKERING INTERFACES. ALL RIGHTS RESERVED. No part of this publication may be reproduced, transmitted, transcribed, translated or stored in any form, or by any means without the written permission of Pickering Interfaces. Technical details contained within this publication are subject to change without notice.
  • Page 3 Pickering Interfaces strives to fulfil all relevant environmental laws and regulations and reduce wastes and releases to the environment. Pickering Interfaces aims to design and operate products in a way that protects the environment and the health and safety of its employees, customers and the public. Pickering Interfaces endeavours to develop and manufacture products that can be produced, distributed, used and recycled, or disposed of, in a safe and environmentally friendly manner.

  • Page 4: Product Safety

    PRODUCT SAFETY SAFETY SYMBOLS The following safety symbols may be used on the product and throughout the product documentation. MEANING / DESCRIPTION SYMBOL PROTECTIVE EARTH (GROUND) To identify any terminal which is intended for connection to an external conductor for protection against electric shock in case of a fault, or the terminal of a protective earth (ground) electrode.

  • Page 5: Table Of Contents

    CONTENTS Copyright Statement ..............II Technical Support and Warranty ..........III Product Safety ................IV Contents (this page) ..............V Warnings and Cautions ..............VII Section 1 Technical Specification ...............1.1 Section 2 Technical Description ..............2.1 Mechanical Description ............2.1 Functional Description ............2.3 Section 3 Installation ..................3.1 Pre Operation Checks ............3.1...
  • Page 6 THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page (VI)

  • Page 7: Warnings And Cautions

    Not to be used in safety critical circuits, refer to the Pickering Interfaces’ terms & conditions of sale. This module must not be used for the switching of Mains Circuits. For the switching of voltages up to the module’s full specification, Secondary Circuit power supplies and the Device Under Test must...
  • Page 8 CAUTION - PRODUCT DOCUMENTATION SYMBOL Suitably qualified & trained users should ensure that the accompanying documentation is fully read and understood before attempting to install or operate the product. SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS All cleaning and servicing requires the equipment to be isolated and disconnected from the power source and user I/O signals (refer to the Maintenance Section).

  • Page 9: Technical Specification

    Analog busing is housed within the module using in 2, 4, 8 or 12-slot sizes to suit high performance PXI matrix a high performance screened analog backplane. Pickering can requirements, it is constructed using instrumentation quality reed construct custom cable assemblies for all of our PXI modules, relays.
  • Page 10 2 Amp BRIC Matrix Modules From Pickering Pickering has over 50 years of experience designing relays to the 40-565B - 2-Pole Matrix - Electro-mechanical Relay highest quality levels demanded by the ATE industry. We know From 29x8 to 232x8 what makes a good relay and how to construct a reliable relay.
  • Page 11 SECTION 1 - TECHNICAL SPECIFICATION Overview pickering BRIC Multi-Slot Matrix – 40-562B How to use the BRIC matrix to connect instrumentation to the UUT Single-Pole Matrices Single-pole 40-562B matrices extend from 10x32 configurations to 792x4 configurations X792 Double-Pole Matrices Double-pole 40-562B matrices extend from 22x16 configurations to 792x4 configurations X792 pickeringtest.com...
  • Page 12 SECTION 1 - TECHNICAL SPECIFICATION pickering Specifications BRIC Multi-Slot Matrix – 40-562B Relay Type Power Requirements The 40-562B BRIC modules are fitted with ruthenium sputtered +3.3V +12V -12V reed relays, these offer very long life with good low level switching 0.3A...
  • Page 13 SECTION 1 - TECHNICAL SPECIFICATION pickering Ordering Information BRIC Multi-Slot Matrix – 40-562B 40-562B BRIC Matrix Product Order Codes x8 Configuration Options BRIC2 - 2-Slot 1-Pole Matrix 40-562B-221-(config) BRIC2 BRIC4 BRIC8 BRIC12 BRIC2 - 2-Slot 2-Pole Matrix 40-562B-222-(config) 40-562B- 40-562B-...
  • Page 14 Connector Accessories data sheets where a complete list Product Customization and documentation can be found for accessories, or refer to the Pickering PXI modules are designed and manufactured on our own Connection Solutions catalog. flexible manufacturing lines, giving complete product control and enabling simple customization to meet very specific requirements.
  • Page 15 We provide a full range of supporting cable and connector solutions for all our switching products—20 connector families with 1200+ products. We offer everything from simple mating connectors to complex cables assemblies and terminal blocks. All assemblies are manufactured by Pickering and are guaranteed to mechanically and electrically mate to our modules. Connectors & Backshells...
  • Page 16 BRIC Multi-Slot Matrix – 40-562B Programming Pickering provide kernel, IVI and VISA (NI & Keysight) drivers which are compatible with all Microsoft supported versions of Windows and popular older versions. For a list of all supporting operating systems, please see: pickeringtest.com/os...

  • Page 17: Technical Description

    SECTION 2 - TECHNICAL DESCRIPTION pickering SECTION 2 - TECHNICAL DESCRIPTION MECHANICAL DESCRIPTION The BRIC Module comprises an alloy chassis, 2 slot (3 daughtercards), 4 slot (6 daughtercards), 8 slot (12 daughtercards) or 12 slot (18 daughtercards) width, with an integral backplane and a number of Ultra High Density Matrix Daughtercards.
  • Page 18 SECTION 2 - TECHNICAL DESCRIPTION pickering Figure 2.2 - 96-pin Micro-D Connectors used on the 44x4 Daughtercards Figure 2.3 - 68-pin Micro-D Connectors used on the 22x8, 11x16 and 5x32 Daughtercards BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 2.2...

  • Page 19: Functional Description

    SECTION 2 - TECHNICAL DESCRIPTION pickering FUNCTIONAL DESCRIPTION A functional block diagram for the BRIC4 version is provided in Figure 2.5 - other BRIC sizes have the same architecture with 2, 8 or 12 slot occupancy. The module is powered by a +5V and +3.3V input via compact PCI connector J1 mounted on the backplane.
  • Page 20 SECTION 2 - TECHNICAL DESCRIPTION pickering Matrix Daughtercard 6 4-Slot Backplane Y Isolation Relays Y Bus Relay Matrix Coils X Bus EEPROM Control Relay Drivers U2 to U25 Logic Matrix Daughtercard 5 Y Isolation Relays Y Bus Relay Matrix Coils...

  • Page 21: Installation

    PREOPERATION CHECKS (UNPACKING) PREOPERATION CHECKS (UNPACKING) 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. 1. Check the module for transport damage and report any damage immediately to Pickering Interfaces. Do not attempt to install the product if any damage is evident.

  • Page 22: Hardware Installation

    For a system comprising more than one chassis, turn ON the last chassis in the system followed by the penultimate, etc, and finally turn ON the external controller or chassis containing the system controller. 9. For Pickering Interfaces modular LXI installation there is no requirement to use any particular power up sequence.

  • Page 23: Testing Operation

    Figure 3.2 - General Soft Front Panel Icon A selector panel will appear, listing all installed Pickering PCI, PXI or LXI switch cards and resistor cards. Click on the card you wish to control, and a graphical control panel is presented allowing operation of the card.
  • Page 24 SECTION 3 - INSTALLATION pickering THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 3.4...

  • Page 25: Programming Guide

    SECTION 4 - PROGRAMMING PROGRAMMING OPTIONS FOR PICKERING INTERFACES PXI MODULES For information on the installation and use of drivers and the programming of Pickering’s products in various software environments, please refer to the Software User Manual. This is available as a download from: https://www.pickeringtest.com/support/software-drivers-and-downloads...

  • Page 26: Module Architecture - X4 Configurations

    SECTION 4 - PROGRAMMING GUIDE pickering MODULE ARCHITECTURE - X4 CONFIGURATIONS Versions of the 40-562B with 4 Y connections are high density single or double pole switching matrices constructed from 44x4 sub-matrix cards linked with an analog backplane. Depending upon the mechanical size, (BRIC2, 4, 8 or 12) between 2 and 18 sub-matrix cards can be fitted.

  • Page 27: Module Architecture - X8 Configurations

    SECTION 4 - PROGRAMMING GUIDE pickering MODULE ARCHITECTURE - X8 CONFIGURATIONS Versions of the 40-562B with 8 Y connections are high density single or double pole switching matrices constructed from 22x8 sub-matrix cards linked with an analog backplane. Depending upon the mechanical size, (BRIC2, 4, 8 or 12) between 2 and 18 sub-matrix cards can be fitted.

  • Page 28: Module Architecture - X16 Configurations

    SECTION 4 - PROGRAMMING GUIDE pickering MODULE ARCHITECTURE - x16 CONFIGURATIONS Versions of the 40-562B with 16 Y connections are high density single or double pole switching matrices constructed from 11x16 sub-matrix cards linked with an analog backplane. Depending upon the mechanical size, (BRIC2, 4, 8 or 12) between 2 and 18 sub-matrix cards can be fitted.

  • Page 29: Module Architecture - X32 Configurations

    SECTION 4 - PROGRAMMING GUIDE pickering MODULE ARCHITECTURE - x32 CONFIGURATIONS Versions of the 40-562B with 32 Y connections are high density single pole switching matrices constructed from 5x32 sub-matrix cards linked with an analog backplane. Depending upon the mechanical size, (BRIC2, 4, 8 or 12) between 2 and 18 sub-matrix cards can be fitted.

  • Page 30: Programming The Module - Standard Version

    Once the drivers are installed the manual “Sys40Prg.pdf” and driver help files which fully describes these functions can be found in the Pickering folder(s) or the Pickering entries on your Start Menu. The card must be opened before use and closed after using the following function calls: Direct I/O Driver - Open with PIL_OpenCards or PIL_OpenSpecifiedCard and close with PIL_CloseCards or PIL_CloseSpecifiedCards respectively.

  • Page 31: Programming The Module - Independent Isolation

    Backplane Isolation Switches - 8 for each sub-matrix fitted (144 for a fully populated BRIC12) Setting an X to Y Signal Path Using The Direct I/O Driver or VISA Driver: Using the Pickering Direct I/O driver: DWORD sub_unit = 1; //Matrix PIL_ClearSub(CardNo, sub_unit);...
  • Page 32 SECTION 4 - PROGRAMMING GUIDE pickering SUB-UNIT 2 SUB-UNIT 1 Backplane 396x8 Matrix (X1-Y1 to X396-Y8) Isolation Front Panel Connector Bit 1 Bit 2 Bit 3 Bit 4 Bit 5 Bit 6 Bit 7 Bit 8 Sub-matrix Card #1 Front Panel Connector...
  • Page 33 SECTION 4 - PROGRAMMING GUIDE pickering Using the IVI Driver The IVI driver assigns names to each channel or node. To program the 40-562B BRIC matrix from the IVI driver it is necessary to know the name of these channels. The channel naming for the matrix is shown in Table 4.2 and the channel naming for the isolation switches is shown in Table 4.3.
  • Page 34 SECTION 4 - PROGRAMMING GUIDE pickering TABLE 4.3 - Backplane Y Isolation Switches, IVI Driver Naming (Independent Isolation Versions - Sub-Matrix Cards 1 to 12) Sub- Sub- IVI Channel IVI Channel Matrix Function Matrix Function Name Name Card No. Card No.
  • Page 35 SECTION 4 - PROGRAMMING GUIDE pickering TABLE 4.3- Continued - Backplane Y Isolation Switches, IVI Driver Naming (Independent Isolation Versions - Sub-Matrix Cards 13 to 18) Sub- IVI Channel Matrix Function Name Card No. comB97, chB97 Connects Y1 to backplane “Y1”...
  • Page 36 SECTION 4 - PROGRAMMING GUIDE pickering THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 4.12...

  • Page 37: Connector Information

    SECTION 5 - CONNECTOR INFORMATION pickering SECTION 5 - CONNECTOR INFORMATION The diagrams on the following pages show the connector pinouts for fully populated BRIC modules. Use Tables 5.1, 5.2, 5.3 and 5.4 on the following pages to find the slot numbers used in the connector diagrams for a particular 40-562B BRIC model number.
  • Page 38 SECTION 5 - CONNECTOR INFORMATION pickering TABLE 5.2 - Connector Diagram Look-up Table - x8 Versions MODEL NUMBER / CONNECTOR DIAGRAM LOOK-UP TABLE - X8 CONFIGURATIONS CONNECTOR SLOTS CONNECTOR SLOTS MODEL NUMBER MODEL NUMBER DIAGRAM USED DIAGRAM USED 40-562B-021-44X8 Figure 5.7...
  • Page 39 SECTION 5 - CONNECTOR INFORMATION pickering TABLE 5.3 - Connector Diagram Look-up Table - x16 Versions MODEL NUMBER / CONNECTOR DIAGRAM LOOK-UP TABLE - X16 CONFIGURATIONS CONNECTOR SLOTS CONNECTOR SLOTS MODEL NUMBER MODEL NUMBER DIAGRAM USED DIAGRAM USED 40-562B-021-22X16 Figure 5.13...
  • Page 40 SECTION 5 - CONNECTOR INFORMATION pickering TABLE 5.4 - Connector Diagram Look-up Table - x32 Versions MODEL NUMBER / CONNECTOR DIAGRAM LOOK-UP TABLE - X32 CONFIGURATIONS CONNECTOR SLOTS MODEL NUMBER DIAGRAM USED 40-562B-021-10X32 Figure 5.19 1 and 2 40-562B-021-15X32 Figure 5.19...
  • Page 41 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 X133 X177 X221 X134 X178 X222 X135 X179 X223 X136 X180 X224 X137 X181 X225 X138 X182 X226 X139 X183 X227 X140...
  • Page 42 SECTION 5 - CONNECTOR INFORMATION pickering Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot X221 X265 X309 X353 X397 X441 X485 X222 X266 X310 X354 X398 X442 X486 X223 X267 X311 X355 X399 X443 X487...
  • Page 43 SECTION 5 - CONNECTOR INFORMATION pickering lot 12 Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X485 X529 X573 X617 X661 X705 X749 X486 X530 X574 X618 X662 X706 X750 X487 X531 X575 X619 X663 X707...
  • Page 44 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7 X1.2 X1.1 X45.2 X45.1 X89.2 X89.1 X133.2 X133.1 X177.2 X177.1 X221.2 X221.1 X265.2 X2.2 X2.1 X46.2 X46.1 X90.2 X90.1 X134.2 X134.1...
  • Page 45 SECTION 5 - CONNECTOR INFORMATION pickering Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot 6 X221.1 X265.2 X265.1 X309.2 X309.1 X353.2 X353.1 X397.2 X397.1 X441.2 X441.1 X485.2 X485.1 X529.2 X222.1 X266.2 X266.1 X310.2 X310.1 X354.2 X354.1...
  • Page 46 SECTION 5 - CONNECTOR INFORMATION pickering Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X485.1 X529.2 X529.1 X573.2 X573.1 X617.2 X617.1 X661.2 X661.1 X705.2 X705.1 X749.2 X749.1 X486.1 X530.2 X530.1 X574.2 X574.1 X618.2 X618.1 X662.2 X662.1 X706.2...
  • Page 47 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 X111 X112 X113 X114 X115 X116 X117 X118 X119 X120 X121 X100 X122 X101 X123 X102 X124 X103 X125 X104 X126 X105...
  • Page 48 SECTION 5 - CONNECTOR INFORMATION pickering Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot X133 X155 X177 X199 X221 X243 X111 X134 X156 X178 X200 X222 X244 X112 X113 X135 X157 X179 X201 X223 X245...
  • Page 49 SECTION 5 - CONNECTOR INFORMATION pickering Slot 12 Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X243 X265 X287 X309 X331 X353 X375 X244 X266 X288 X310 X332 X354 X376 X245 X267 X289 X311 X333 X355...
  • Page 50 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot X1.2 X1.1 X111.1 X133.2 X23.2 X23.1 X45.2 X45.1 X67.2 X67.1 X89.2 X89.1 X111.2 X2.2 X2.1 X24.2 X24.1 X112.1 X134.2 X46.2 X46.1 X68.2...
  • Page 51 SECTION 5 - CONNECTOR INFORMATION pickering Slot 6 Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 X111.1 X133.2 X133.1 X155.2 X155.1 X177.2 X177.1 X199.2 X199.1 X221.2 X221.1 X243.2 X243.1 X265.2 X112.1 X134.2 X134.1 X156.2 X156.1 X178.2 X178.1...
  • Page 52 SECTION 5 - CONNECTOR INFORMATION pickering Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X243.1 X265.2 X265.1 X287.2 X287.1 X309.2 X309.1 X331.2 X331.1 X353.2 X353.1 X375.2 X375.1 X244.1 X266.2 X266.1 X288.2 X288.1 X310.2 X310.1 X332.2 X332.1 X354.2...
  • Page 53 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd Figure 5.13 - Single Pole BRIC2 Module 40-562B-221-33x16 (Slots 1 to 3), Single Pole BRIC4 Module 40-562B-021-66x16 (Slots 1 to 6), Single Pole BRIC8 Module 40-562B-121-132x16 (Slots 1 to 6) &...
  • Page 54 SECTION 5 - CONNECTOR INFORMATION pickering Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot X100 X111 X122 X101 X112 X123 X102 X113 X124 X103 X114 X125 X104 X115 X126 X105 X116 X127 X106 X117 X128...
  • Page 55 SECTION 5 - CONNECTOR INFORMATION pickering Slot 12 Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X122 X133 X144 X155 X166 X177 X188 X123 X134 X145 X156 X167 X178 X189 X124 X135 X146 X157 X168 X179...
  • Page 56 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot X1.2 X1.1 X12.2 X12.1 X23.2 X23.1 X34.2 X34.1 X45.2 X45.1 X56.2 X56.1 X67.2 X2.2 X2.1 X13.2 X13.1 X24.2 X24.1 X35.2 X35.1 X46.2...
  • Page 57 SECTION 5 - CONNECTOR INFORMATION pickering Slot 6 Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 X56.1 X67.2 X67.1 X78.2 X78.1 X89.2 X89.1 X100.2 X100.1 X111.2 X111.1 X122.2 X122.1 X133.2 X57.1 X68.2 X68.1 X79.2 X79.1 X90.2 X90.1...
  • Page 58 SECTION 5 - CONNECTOR INFORMATION pickering Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 X122.1 X133.2 X133.1 X144.2 X144.1 X155.2 X155.1 X166.2 X166.1 X177.2 X177.1 X188.2 X188.1 X123.1 X134.2 X134.1 X145.2 X145.1 X156.2 X156.1 X167.2 X167.1 X178.2...
  • Page 59 SECTION 5 - CONNECTOR INFORMATION pickering Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd Figure 5.19 - Single Pole BRIC2 Module 40-562B-221-15x32 (Slots 1 to 3), Single Pole BRIC4 Module 40-562B-021-30x32 (Slots 1 to 6), Single Pole BRIC8 Module 40-562B-121-60x32 (Slots 1 to 6) &...
  • Page 60 SECTION 5 - CONNECTOR INFORMATION pickering Slot 7 Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd Figure 5.20 - Single Pole BRIC8 Module 40-562B-121-60x32 (Slots 7 to 12) &...
  • Page 61 SECTION 5 - CONNECTOR INFORMATION pickering Slot 12 Slot 13 Slot 14 Slot 15 Slot 16 Slot 17 Slot 18 S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd S. Gnd Figure 5.21 - Single Pole BRIC12 Module 40-562B-321-90x32 (Slots 13 to 18): Pinouts BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™...
  • Page 62 SECTION 5 - CONNECTOR INFORMATION pickering THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 5.26...

  • Page 63: Trouble Shooting

    PCI configuration, highlighting any potential configuration problems. Specific details of all installed Pickering switch cards are included. All the installed Pickering switch cards should be listed in the “Pilpxi information” section - if one or more cards is missing it may be possible to determine the reason by referring to the PCI configuration dump contained in the report, but interpretation of this information is far from straightforward, and the best course is to contact Pickering support: support@pickeringtest.com, if possible...
  • Page 64 SECTION 6 - TROUBLE SHOOTING pickering THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 6.2...

  • Page 65: Maintenance Information

    The Pickering Interfaces BIRST (Built-In Relay Self Test) Tool provides a simple means of testing selected Pickering Interfaces switching products, including this model. The tool can be used to find relay faults or to provide confirmation that a product is operating correctly, either as part of the regular system calibration or because a system fault is suspected and the switch system needs to be eliminated from the fault finding procedure.

  • Page 66: Relay Look-Up Tables - X4 Versions

    Replacement of relays should only be carried out by qualified personnel using the correct equipment. If qualified personnel are not available, or the location of a defective relay cannot be positively determined it is recommended that the module is returned to Pickering Interfaces or a replacement daughtercard is ordered.
  • Page 67 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.1 - 44x4 Daughtercard Isolation Relay Look-Up Table BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 7.3...
  • Page 68 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.2 - 44x4 Daughtercard Relay Look-Up TABLE 7.3 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X1/Y1 to X44/Y4 Table - Crosspoints X45/Y1 to X88/Y4 89 23 89 67 90 23 90 67...
  • Page 69 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.4 - 44x4 Daughtercard Relay Look-Up TABLE 7.5 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X89/Y1 to X132/Y4 Table - Crosspoints X133/Y1 to X176/Y4 1 100 1 89 111 1 5 122 1...
  • Page 70 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.6 - 44x4 Daughtercard Relay Look-Up TABLE 7.7 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X177/Y1 to X220/Y4 Table - Crosspoints X221/Y1 to X264/Y4 177 1 1 188 1 89 199 1...
  • Page 71 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.8 - 44x4 Daughtercard Relay Look-Up TABLE 7.9 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X265/Y1 to X308/Y4 Table - Crosspoints X309/Y1 to X352/Y4 265 1 1 276 1 89 287 1...
  • Page 72 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.10 - 44x4 Daughtercard Relay Look-Up TABLE 7.11 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X353/Y1 to X396/Y4 Table - Crosspoints X397/Y1 to X440/Y4 353 1 1 364 1 89 375 1...
  • Page 73 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.12 - 44x8 Daughtercard Relay Look-Up TABLE 7.13 - 44x8 Daughtercard Relay Look-Up Table - Crosspoints X441/Y1 to X484/Y4 Table - Crosspoints X485/Y1 to X528/Y4 441 1 1 452 1 11 89 463 1...
  • Page 74 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.14 - 44x4 Daughtercard Relay Look-Up TABLE 7.15 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X529/Y1 to X572/Y4 Table - Crosspoints X573/Y1 to X616/Y4 529 1 1 540 1 13 89 551 1...
  • Page 75 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.16 - 44x4 Daughtercard Relay Look-Up TABLE 7.17 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X617/Y1 to X660/Y4 Table - Crosspoints X661/Y1 to X704/Y4 617 1 1 628 1 15 89 639 1...
  • Page 76 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.18 - 44x4 Daughtercard Relay Look-Up TABLE 7.19 - 44x4 Daughtercard Relay Look-Up Table - Crosspoints X705/Y1 to X748/Y4 Table - Crosspoints X749/Y1 to X792/Y4 705 1 1 716 1 17 89 727 1...
  • Page 77 SECTION 7 - MAINTENANCE INFORMATION pickering PCB LAYOUT DIAGRAM - x4 VERSIONS RL177 RL10 RL11 RL12 RL13 RL14 RL15 RL178 RL17 RL18 RL19 RL20 RL21 RL22 RL23 RL179 RL25 RL26 RL27 RL28 RL29 RL30 RL31 RL180 RL33 RL34 RL35 RL36...

  • Page 78: Relay Look-Up Tables - X8 Versions

    Replacement of relays should only be carried out by qualified personnel using the correct equipment. If qualified personnel are not available, or the location of a defective relay cannot be positively determined it is recommended that the module is returned to Pickering Interfaces or a replacement daughtercard is ordered.
  • Page 79 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.20 - 22x8 Daughtercard Isolation Relay Look-Up Table BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 7.15...
  • Page 80 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.21 - 22x8 Daughtercard Relay Look-Up TABLE 7.22 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X1/Y1 to X22/Y8 Table - Crosspoints X23/Y1 to X44/Y8 45 12 89 17 1 133 45 34...
  • Page 81 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.23 - 22x8 Daughtercard Relay Look-Up TABLE 7.24 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X45/Y1 to X66/Y8 Table - Crosspoints X67/Y1 to X88/Y8 45 56 89 61 3 133 45 78...
  • Page 82 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.25 - 22x8 Daughtercard Relay Look-Up TABLE 7.26 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X89/Y1 to X110/Y8 Table - Crosspoints X111/Y1 to X132/Y8 45 100 1 89 105 5 5 133...
  • Page 83 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.27 - 22x8 Daughtercard Relay Look-Up TABLE 7.28 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X133/Y1 to X154/Y8 Table - Crosspoints X155/Y1 to X176/Y8 133 1 1 138 5 45 144 1...
  • Page 84 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.29 - 22x8 Daughtercard Relay Look-Up TABLE 7.30 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X177/Y1 to X198/Y8 Table - Crosspoints X199/Y1 to X220/Y8 177 1 1 182 5 45 188 1...
  • Page 85 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.31 - 22x8 Daughtercard Relay Look-Up TABLE 7.32 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X221/Y1 to X242/Y8 Table - Crosspoints X243/Y1 to X264/Y8 221 1 1 226 5 11 45 232 1...
  • Page 86 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.33 - 22x8 Daughtercard Relay Look-Up TABLE 7.34 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X265/Y1 to X286/Y8 Table - Crosspoints X287/Y1 to X308/Y8 265 1 1 270 5 13 45 276 1...
  • Page 87 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.35 - 22x8 Daughtercard Relay Look-Up TABLE 7.36 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X309/Y1 to X330/Y8 Table - Crosspoints X331/Y1 to X352/Y8 309 1 1 314 5 15 45 320 1...
  • Page 88 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.37 - 22x8 Daughtercard Relay Look-Up TABLE 7.38 - 22x8 Daughtercard Relay Look-Up Table - Crosspoints X353/Y1 to X374/Y8 Table - Crosspoints X375/Y1 to X396/Y8 353 1 1 358 5 17 45 364 1...
  • Page 89 SECTION 7 - MAINTENANCE INFORMATION pickering PCB LAYOUT DIAGRAM - x8 VERSIONS RL177 RL10 RL11 RL12 RL13 RL14 RL15 RL178 RL17 RL18 RL19 RL20 RL21 RL22 RL23 RL179 RL25 RL26 RL27 RL28 RL29 RL30 RL31 RL180 RL33 RL34 RL35 RL36...

  • Page 90: Relay Look-Up Tables - X16 Versions

    Replacement of relays should only be carried out by qualified personnel using the correct equipment. If qualified personnel are not available, or the location of a defective relay cannot be positively determined it is recommended that the module is returned to Pickering Interfaces or a replacement daughtercard is ordered.
  • Page 91 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.39 - 11x16 Daughtercard Relay Look-Up TABLE 7.40 - 11x16 Daughtercard Relay Look-Up Table - Crosspoints X1/Y1 to X11/Y16 Table - Crosspoints X12/Y1 to X22/Y16 1 133 14 13 45 17 89 20...
  • Page 92 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.41 - 11x16 Daughtercard Relay Look-Up TABLE 7.42 - 11x16 Daughtercard Relay Look-Up Table - Crosspoints X23/Y1 to X33/Y16 Table - Crosspoints X34/Y1 to X44/Y16 25 13 45 28 89 31 36 13...
  • Page 93 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.43 - 11x16 Daughtercard Relay Look-Up TABLE 7.44 - 11x16 Daughtercard Relay Look-Up Table - Crosspoints X45/Y1 to X55/Y16 Table - Crosspoints X56/Y1 to X66/Y16 47 13 45 50 89 53 58 13...
  • Page 94 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.45 - 11x16 Daughtercard Relay Look-Up TABLE 7.46 - 11x16 Daughtercard Relay Look-Up Table - Crosspoints X67/Y1 to X77/Y16 Table - Crosspoints X78/Y1 to X88/Y16 69 13 45 72 89 75 80 13...
  • Page 95 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.47 - 11x16 Daughtercard Relay Look-Up TABLE 7.48 - 11x16 Daughtercard Relay Look-Up Table - Crosspoints X89/Y1 to X99/Y16 Table - Crosspoints X100/Y1 to X110/Y16 91 13 45 94 89 97 100 1...
  • Page 96 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.49 - 11x16 Daughtercard Relay Look-Up TABLE 7.50 - 11x16 Daughtercard Relay Table - Crosspoints X111/Y1 to X121/Y16 Look-Up Table - Crosspoints X122/Y1 to X132/Y16 111 1 1 113 13 11 45 116 9...
  • Page 97 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.51 - 11x16 Daughtercard Relay Look-Up TABLE 7.52 - 11x16 Daughtercard Relay Table - Crosspoints X133/Y1 to X143/Y16 Look-Up Table - Crosspoints X144/Y1 to X154/Y16 133 1 1 135 13 13 45 138 9...
  • Page 98 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.53 - 11x16 Daughtercard Relay Look-Up TABLE 7.54 - 11x16 Daughtercard Relay Table - Crosspoints X155/Y1 to X165/Y16 Look-Up Table - Crosspoints X166/Y1 to X176/Y16 155 1 1 157 13 15 45 160 9...
  • Page 99 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.55 - 11x16 Daughtercard Relay Look-Up TABLE 7.56 - 11x16 Daughtercard Relay Table - Crosspoints X177/Y1 to X187/Y16 Look-Up Table - Crosspoints X188/Y1 to X198/Y16 177 1 1 179 13 17 45 182 9...
  • Page 100 SECTION 7 - MAINTENANCE INFORMATION pickering PCB LAYOUT DIAGRAM - x16 VERSIONS RL10 RL11 RL12 RL13 RL14 RL15 RL16 RL17 RL18 RL19 RL20 RL21 RL22 RL23 RL24 RL25 RL26 RL27 RL28 RL29 RL30 RL31 RL32 RL33 RL34 RL35 RL36 RL37...

  • Page 101: Relay Look-Up Tables - X32 Versions

    Replacement of relays should only be carried out by qualified personnel using the correct equipment. If qualified personnel are not available, or the location of a defective relay cannot be positively determined it is recommended that the module is returned to Pickering Interfaces or a replacement daughtercard is ordered.
  • Page 102 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.57 - 5x32 Daughtercard Relay Look-Up TABLE 7.58 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X1/Y1 to X5/Y32 Table - Crosspoints X6/Y1 to X10/Y32 1 121 2 121 1 122 2 122...
  • Page 103 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.59 - 5x32 Daughtercard Relay Look-Up TABLE 7.60 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X11/Y1 to X15/Y32 Table - Crosspoints X16/Y1 to X20/Y32 41 13 17 81 14 25 3 121...
  • Page 104 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.61 - 5x32 Daughtercard Relay Look-Up TABLE 7.62 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X21/Y1 to X25/Y32 Table - Crosspoints X26/Y1 to X30/Y32 41 23 17 81 24 25 5 121...
  • Page 105 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.63 - 5x32 Daughtercard Relay Look-Up TABLE 7.64 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X31/Y1 to X35/Y32 Table - Crosspoints X36/Y1 to X40/Y32 41 33 17 81 34 25 7 121...
  • Page 106 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.65 - 5x32 Daughtercard Relay Look-Up TABLE 7.66 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X41/Y1 to X45/Y32 Table - Crosspoints X46/Y1 to X50/Y32 41 43 17 81 44 25 9 121...
  • Page 107 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.67 - 5x32 Daughtercard Relay Look-Up TABLE 7.68 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X51/Y1 to X55/Y32 Table - Crosspoints X56/Y1 to X60/Y32 11 41 53 17 11 81 54 25 11 121...
  • Page 108 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.69 - 5x32 Daughtercard Relay Look-Up TABLE 7.70 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X61/Y1 to X65/Y32 Table - Crosspoints X66/Y1 to X70/Y32 13 41 63 17 13 81 64 25 13 121...
  • Page 109 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.71 - 5x32 Daughtercard Relay Look-Up TABLE 7.72 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X71/Y1 to X75/Y32 Table - Crosspoints X76/Y1 to X80/Y32 15 41 73 17 15 81 74 25 15 121...
  • Page 110 SECTION 7 - MAINTENANCE INFORMATION pickering TABLE 7.73 - 5x32 Daughtercard Relay Look-Up TABLE 7.74 - 5x32 Daughtercard Relay Look-Up Table - Crosspoints X81/Y1 to X85/Y32 Table - Crosspoints X86/Y1 to X90/Y32 17 41 83 17 17 81 84 25 17 121...
  • Page 111 SECTION 7 - MAINTENANCE INFORMATION pickering PCB LAYOUT DIAGRAM - x32 VERSIONS SPARE Figure 7.4 - 5x32 Matrix Daughtercard: Component Layout BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 7.47...

  • Page 112: Daughtercard Removal/Replacement

    SECTION 7 - MAINTENANCE INFORMATION pickering DAUGHTERCARD REMOVAL/REPLACEMENT CAUTION WHEN REMOVING DAUGHTERCARDS FROM THE CHASSIS IT IS IMPORTANT THAT THE FOLLOWING PROCEDURE IS FOLLOWED. Tools Required • Small Cross-Head Screwdriver • Bric Extraction Tool 44-999-001 Removal Procedure NOTE If blanking plates are fitted, remove these first. If more than one daughtercard is to be removed, remove the daughtercard that is furthest to the LEFT, i.e.
  • Page 113 SECTION 7 - MAINTENANCE INFORMATION pickering To remove the Daughtercard in slot 1 or 2: Remove the cross-head screw securing the ejector handle to daughtercards 1 and 2. Remove the ejector handle. Remove the remaining three cross-head screws securing daughtercards 1 and 2 to the BRIC Chassis.
  • Page 114 SECTION 7 - MAINTENANCE INFORMATION pickering Release the two securing screws to the front of both side panels. (Note: On some earlier units complete removal of the side covers may be advisable to ease replacement) Clip the removal tool over the daughtercard front panel connector.
  • Page 115 SECTION 7 - MAINTENANCE INFORMATION pickering CAUTION THE BACKPLANE CONNECTORS ARE NOT PROVIDED WITH LOCATING GUIDES. IN THE FOLLOWING PROCEDURE IS IT IMPORTANT THAT THE DAUGHTERCARD CONNECTOR IS ALIGNED WITH THE BACKPLANE CONNECTOR BEFORE THE MODULE IS PUSHED FULLY HOME.
  • Page 116 SECTION 7 - MAINTENANCE INFORMATION pickering THIS PAGE INTENTIONALLY BLANK BRIC INTEGRATED PXI MATRIX SYSTEM WITH BIRST™ (40-562B) Page 7.52...
