FALCON RIDGE AC-WILDCAT-XX-RW01 Instructions For Installation And Care

Arctic cat / textron wildcat xx soft rear window

Download this manual

Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable.

1. Be sure to read these instructions thoroughly before opening and installing the Wildcat

XX Soft Rear Window. The installation is best done when the temperature is 70 degrees

F. or warmer. The temperature affects the adhesive Velcro, if conditions prevent

installing in warmer weather it helps to store the adhesive Velcro at room temperature

prior to installation.

2. Carefully open the carton and remove the enclosure on a large flat surface that is clean

and free of dirt.

3. Check over the parts included in the carton with the parts list shown below:

Adhesive Velcro Hook Strips:

Rear Window

1. Begin by placing the two 17" adhesive strips on the top bar facing upwards on either side of the

center bar. Then hang the Rear Window on the inside as shown in the picture below.

2515 Bypass Rd. Flemingsburg, KY 41041

606-845-7439

Instructions for Installation and Care of

Arctic Cat / Textron Wildcat XX

Soft Rear Window

AC-WILDCAT-XX-RW01

Soft Rear Window

8 each------------3"

2 each------------6"

2 each------------17"

1 each------------18"

Page 1 Arctic Cat / Textron Wildcat XX Soft Rear Window AC-WILDCAT-XX-RW01 Notice: Do not smoke inside the cab or expose the enclosure to direct flames. Cab is Flammable. 1. Be sure to read these instructions thoroughly before opening and installing the Wildcat XX Soft Rear Window.
Page 2 2. Next attach the double-sided strips down each side using the 3” adhesive strips to loch the double-sided strips in place. See photos below.
Page 3 3. Finally attach the two 6” and the one 18” adhesive strips across the bottom of the Rear window behind the seats. See pictures below...
Page 4 Cleaning and Storage Recommendations: Before removing the Over Armour Cab for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
