5. Pull the rack rails' telescopic extensions all the way to the rack's opposite side, and insert the
latches at the rails' free edges to the rack's slots. A click should be heard as the spring latches
are fully inserted and locking occurs.
Ins
ert
ing
the
Spr
ing
Lat
ch
es
to
the
Ra
ck'
s
Slo
ts
To mount the system into the rack:

Two people are required to safely mount the system in the rack.
While your installation partner is supporting the system's weight, perform the following
steps:
Rack Rails Fully Inserted and Locked in the Rack Assembly
