Service Manual
SERVICE PARTS & DIAGRAMS
BENDPAK
10APX
PRODUCT SKU
5175306
DRAWING Nº
5260700
CATEGORY
Two Post Lift
VER. C
Rev. B
DATE
06.07.2023
This guide is a troubleshooting reference used for maintaining and
servicing your Bend Pak product. It provides comprehensive information
on identifying serviceable parts and components and assists in
troubleshooting problems and performing assembly /disassembly
procedures.
BendPak, Inc. Corporate Office
1645 Lemonwood Drive
Santa Paula, CA 93060 USA
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
info@bendpak.com
Customer Service Desk / Warranty
Customer Service Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
customerservice@bendpak.com
Parts Orders
Customer Service Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
parts@bendpak.com
Domestic Sales & Service
USA Sales Representatives
Office Tel: 1-805-933-9970
Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
sales@bendpak.com
International Sales & Service
Office Tel: 1-805-933-9970
Exports Dept: 1-805-933-9970 EXT. 192
Ext. Toll Free US/Canada: 1-800-253-2363
Fax: 1-805-933-9160
bpkexports@bendpak.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the 10APX and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BendPak 10APX

Summary of Contents for BendPak 10APX

  • Page 1 Bend Pak product. It provides comprehensive information on identifying serviceable parts and components and assists in troubleshooting problems and performing assembly /disassembly procedures. BendPak, Inc. Corporate Office Customer Service Desk / Warranty Parts Orders Domestic Sales & Service International Sales &...
  • Page 2 5260700 PROPRIETARY AND CONFIDENTIAL SEE COLORS & GRAPHICS FOR LABEL PLACEMENT THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING SCALE: 1:30 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 3 PROPRIETARY AND CONFIDENTIAL REFER TO MODEL FOR ADDITIONAL INFORMATION THE INFORMATION CONTAINED IN THIS DRAWING IS 5260700 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING SCALE: 1:30 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 4 5216130 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 5 5216131 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY ASSEMBLE ITEMS AS SHOWN REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:25 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 6 NEXT ASSEMBLY 5216182 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5245246 THE SOLE PROPERTY OF BENDPAK INC. ANY NOTE ORIENTATION OF HARDWARE REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 7 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER WELDING AND PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS 5260700 THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 8 PROPRIETARY AND CONFIDENTIAL APPLY LOCTITE BLUE 242 AND CURE PER MANUFACTURE THE INFORMATION CONTAINED IN THIS DRAWING IS 5260700 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SPECIFICATION SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 9 PROPRIETARY AND CONFIDENTIAL APPLY LOCTITE BLUE 242 AND CURE PER MANUFACTURE THE INFORMATION CONTAINED IN THIS DRAWING IS 5260700 THE SOLE PROPERTY OF BENDPAK INC. ANY SPECIFICATION REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 10 PROPRIETARY AND CONFIDENTIAL INSERT PARTS BAG INTO PARTS BOX FOR SHIPMENT THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY HOSES AND CABLES SHOWN REPRESENTATIONAL FORM REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:20 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 11 5174047 NOTE: UNLESS OTHERWISE SPECIFIED. PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS 5250346 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING SCALE: 1:16 THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 12 5215704 PROPRIETARY AND CONFIDENTIAL 5250346 SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE PROPERTY OF BENDPAK INC. ANY 5250347 REPRODUCTION IN PART OR AS A WHOLE WITHOUT ASSEMBLE ITEMS AS SHOWN SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 13 5216181 PROPRIETARY AND CONFIDENTIAL SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING THE INFORMATION CONTAINED IN THIS DRAWING IS 5216130 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT ASSEMBLE ITEMS AS SHOWN SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC. IS...

  • Page 14: Hose Assembly

    PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS 5250346 THE SOLE PROPERTY OF BENDPAK INC. ANY (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 15 17100PSI OR 1179 BAR MINIMUM BURST PRESSURE MINIMUM 3” / 80mm MIN BEND RADIUS COLOR: BLACK ADDITIONAL CONTACT INFORMATION: 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # AUTHORIZED COMPONENT PROVIDER 5570129 OR BENDPAK ENGINEERING APPROVED EQUIVALENT...

  • Page 16: Hydraulic Hose Assembly

    PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS 5250346 THE SOLE PROPERTY OF BENDPAK INC. ANY (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 17 PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS 5250346 THE SOLE PROPERTY OF BENDPAK INC. ANY (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 18 FOR ITEM 1 SPECIFICATIONS REFER TO PART SPECIFICATION FORM THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY (*)ITEM 1 QTY FOR REFERENCE ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 19 PROPRIETARY AND CONFIDENTIAL ITEM 1 QTY FOR REFERENCE ONLY THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY THREAD 5535358 WITH 5545342 ONTO CABLES FOR SHIPMENT REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.

  • Page 20: Safety Cable

    PROPRIETARY AND CONFIDENTIAL FOR ITEM 1 AND 2 SPECIFICATIONS REFER TO PART THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SPECIFICATION FORM SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 21 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 22 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS 5216217 THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 23 5601753 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5216217 THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 5216218 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 24 UNLESS OTHERWISE SPECIFIED 5601853 PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY 10mm CUT TO LOWER 5620676 2PL ONLY REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 25 DIMENSIONS SHOWN ARE AFTER PAINTING PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 26 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT GRAY (RAL-7024) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 27 BREAK AND DEBURR ALL SHARP EDGES 0.3mm PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 28 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 29 PROPRIETARY AND CONFIDENTIAL DIMENSIONS SHOWN ARE AFTER WELDING AND PAINTING THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:10 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 30 DIMENSIONS SHOWN ARE AFTER WELDING AND PAINTING PROPRIETARY AND CONFIDENTIAL THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY PAINT YELLOW (RAL-1018) 20% GLOSS REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE:...
  • Page 31 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 32 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5601852 THE SOLE PROPERTY OF BENDPAK INC. ANY REPRODUCTION IN PART OR AS A WHOLE WITHOUT REMOVE ALL WELD SPLATTER SCALE: THE WRITTEN PERMISSION OF BENDPAK INC. IS...
  • Page 33 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS NEXT ASSEMBLY THE SOLE PROPERTY OF BENDPAK INC. ANY REMOVE ALL WELD SPLATTER REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: 1:12 THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 34 PROPRIETARY AND CONFIDENTIAL BREAK AND DEBURR ALL SHARP EDGES 0.3mm THE INFORMATION CONTAINED IN THIS DRAWING IS 5601850 THE SOLE PROPERTY OF BENDPAK INC. ANY MATERIAL: HR ASTM A36 OR Q235 GB/T 700 REPRODUCTION IN PART OR AS A WHOLE WITHOUT SCALE: THE WRITTEN PERMISSION OF BENDPAK INC.
  • Page 35 (216 to 279 mm), or between Color: Black and White Binding: Saddle Stitched Paper: 100 to 120 gsm (27 to 32 pound), uncoated 2. Vendor Information (Or for Reference) Approved Vendor Vendor Part # Contact # Preferred Vendor OR BENDPAK ENGINEERING APPROVED EQUIVALENT...
