- Page 1 Dough Rounder Pre-installation and installation manual LLKBR280 LLKBR800 Ed. 0522 - 70702601 REV02 Rounding machine - Preinstallation...
-
Page 2: Table Of Contents
Wiring diagrams ..................12 installation. Do not hesitate to contact him in case of doubt. FINAL OPERATIONS ..............14 CUPPONE 1963 Cuppone F.lli S.r.l. Via Sile, 36 31057 Silea (TV) - ITALY T +39 0422 361143 F +39 0422 360993 info@cuppone.com - www.cuppone.com... -
Page 3: Checks Before Purchasing
CHECKS BEFORE PURCHASING Before purchasing the product and installing it, check the adequate ventilation • there is according to the reg- Fig. 1 following conditions, necessary for the correct installation, ulations in force in the Country of installation. If this is operation and maintenance of the product. - Page 4 4x1.5 work near the product. AC 230V/50Hz 0.37 kW 3x1.5 have the connection cable • single-phase machines LLKBR800 AC 3 N 400V/50Hz 0.37 kW 4x1.5 and plug already fitted; have the power cable • three-phase machines already installed; a plug (not supplied) must be fitted to it of suitable capacity.
-
Page 5: Technical Data
TECHNICAL DATA Knowing the appliance Fig. 3 Knowing the appliance This appliance has been designed and built for food use only, for the cold processing of cereal flour-based doughs; its main use is therefore in pizzerias, bakeries and pastry shops. The purpose of the machine is to round portions of already portioned dough to the desired weight, while maintaining the basic characteristics of the dough unaltered;... -
Page 6: Rnd280 Rounding Machine Technical Data
BR280 rounding machine technical data BR800 rounding machine technical data rounding machine weight 55 kg [121.2 lb] rounding machine weight 86 kg [189.5 lb] weight of packaging + rounding machine 64 kg [141 lb] weight of packaging + rounding machine 95 kg [209.4 lb] 500 x 750 x 1000 mm 500 x 750 x 1000 mm... -
Page 7: Safety Instructions
INSTALLATION Symbols used in the manual and on Safety instructions room in which this equipment is installed. the labels applied to the machine Do not obstruct the ventilation and exhaust • Read this guide carefully before installing the holes of this or other equipment. appliance, and keep it with care in an accessible Indicates that caution is required when performing •... -
Page 8: Symbols Applied To The Machine
Installation Symbols applied to the machine Attention, moving mechanical parts Attention, hand crushing risk It is FORBIDDEN to remove the safety devices IT IS FORBIDDEN to clean, lubricate and adjust the elements of the machine when they are moving Main regulations and directives complied with and to be complied with Directive 2014/35/EU “Concerning the approximation of the laws of the Member States relating to electrical equipment intended for use within certain voltage limits”. -
Page 9: Transport
Installation Transport Fig. 4 Fitted with personal protection equipment, transport the appliance to the installation location. Use suitable equipment, capable of dealing with its weight: persons not involved with the appliance installation may not pass through or stand in the work area during the appliance assembly. -
Page 10: Serial Number Plate Reading
Installation Serial number plate reading Model Fig. 7 Electrical parameters The serial number is on the back of the appliance. It provides important technical information that is vital in case of a request for maintenance or repair of the appliance: please Year of production do not remove, damage or modify it. -
Page 11: Electrical Connection
Model draw n x mm AC 230V/50Hz 0.37 kW 3x1.5 LLKBR280 AC 3 N 400V/50Hz 0.37 kW 4x1.5 AC 230V/50Hz 0.37 kW 3x1.5 LLKBR800 AC 3 N 400V/50Hz 0.37 kW 4x1.5 Ed. 0522 - 70702601 REV02 Rounding machine - Preinstallation... -
Page 12: Wiring Diagrams
Wiring diagrams AC 230V/50Hz Abbreviation Description Semiconductor diode Power relay LED1 Light emitting diode Resistor NC limit switch START NO control or button STOP NC control or button Transformer Limit switch faston terminal... - Page 13 Wiring diagrams AC 3 N 400V/50Hz Abbreviation Description Power relay Motor NC emergency limit switch NC stop button NO start/stop button Transformer Bulb 0,37 kW Ed. 0522 - 70702601 REV02 Rounding machine - Preinstallation...
-
Page 14: Final Operations
FINAL OPERATIONS Pre-testing and final inspection The product is checked and tested in the Manufacturer’s plant before being delivered to the customer. each The “production process check sheet” enclosed with it guarantees that step in the production process, from assembly to packaging, was carefully checked from both the operating and safety standpoints. - Page 15 20 g [0.044 lb / 0.70 ounces] 300 gr [0.66 lb / 10.58 ounces] from 50% to 65% find it difficult to get back up LLKBR800 20 g [0.044 lb / 0.70 ounces] 900 gr [1.9 lb / 31.7 ounces]...
- Page 16 Units 3 - 5 Belgrave Ind Estate, Honeywell Lane, Oldham, OL8 2JP 01616335797 sales@llkpizzapros.co.uk www.llkpizzapros.co.uk CUPPONE 1963 Cuppone F.lli S.r.l. Via Sile, 36 31057 Silea (TV) - ITALY T +39 0422 361143 F +39 0422 360993 info@cuppone.com - www.cuppone.com...
