Thank you for choosing an Elite Screens fixed frame projection screen! Please read through this user guide before
utilizing the screen. Correct usage and maintenance will ensure a long product life.
Care & Use Instructions
Dust, dirt and scratches on the projection surface will affect the picture quality, please take note of the points below
to prevent that from occurring:
1. Do not touch the projection surface with your hands
2. Do not write or draw on the projection surface
3. Do not use fingers or sharp objects to point on the projection surface; this will damage the screen material.
4. Use a soft-damp cloth to clean the projection surface; do not use chemical cleaning agents or alcohol.
5. Use clean water when dampening the cleaning cloth and do not rub against the material to clean it.
a: Frame parts x 6 pcs
(Springs pre-installed)
e: Tension Rods x 6 pcs
i: Center support bar x 1 pc
m: Center joints x 2 pcs
Rev.V04152023DT (DS0245)
Sable Frame 2/B2 Series
Fixed Frame Projection Screen
User's Guide – H Type
Hardware and Parts List
b:
Elbow Joints x 8 pcs
f: M5*50 wood screws x 8 pcs
j: Gloves x 2 pcs
※
Gloves (j) and Protection sheet (k) may not be included in some specific models.
Note: Please make sure all parts are included in your package before proceeding
to assemble the fixed frame screen.
www.elitescreens.com
c: M5*6 screws x 40 pcs
g: Wall anchor x 8 pcs
k: Protection sheet x 1 pc
d: Springs hook x 2 pcs
h: Wall brackets x 4 pcs
l: Screen Material x 1pc
